INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fi re or
explosion may result causing property damage,
personal injury or death.
DANGER: If you smell gas:
1. Shut off gas to the
appliance
2. Extinguish any open fl ame.
3. If odor continues, keep away from the ap-
pliance and immediately call your gas supplier
or fi re department.
WARNING: Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity of
this or any other appliance.
An LP-cylinder not conected for use shall not
be stored
WARNING: Improper installation, adjusment,
alteration, service or maintenance can cause
injury or property damage. Read the installa-
tion, operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
61114-40
CARBON MONOXIDE HAZARD
This appliance can produce carbon mon-
oxide which has no odor.
using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
TC36.CODE
TC36 OUTDOOR GAS
FIREPLACE INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL:
TC36.OD
SERIES C
MODULAR DIRECT VENT
FIREPLACE
WARNING: For Outdoor Use Only
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
SERIAL #
5055.3601-A
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC36.OD
Summary of Contents for Town & Country Fireplaces TC36.OD
- Page 1 WARNING: Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance. MODEL: An LP-cylinder not conected for use shall not TC36.OD be stored SERIES C WARNING: Improper installation, adjusment, MODULAR DIRECT VENT...
-
Page 2: Table Of Contents
Table of Contents Caution ................... 3 Safety ..................... 3 This Fireplace Intended For Outdoor Use Only ......5 Propane Conversion ............... 6 Fireplace Dimensions ..............7 Minimum Clearances to Combustible Material ....... 7 Installation Requirements ............... 8 Manufactured (Mobile) Home ............8 Window Frame Removal .............. -
Page 3: Caution
Caution FOR YOUR SAFETY - Do not install or operate your Town & Country fi replace without fi rst reading and understanding this manual. Any installation or operational deviation from the fol- lowing instructions voids the Town & Country Fireplaces Warranty and may prove hazardous. -
Page 4: Important Note For The Commonwealth Of Massachusetts
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above fi nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfi ed. -
Page 5: This Fireplace Intended For Outdoor Use Only
This Fireplace Is Intended For Outdoor Use Only! - The fi replace must be located inside of a weatherproof enclosure. - Flashing must be installed around the fi replace opening in accordance with local building codes in order to prevent moisture from entering the enclosure. - A drip pan (not supplied with the unit) must be installed under the fi replace and be provided with a means of draining. -
Page 6: Propane Conversion
Propane Conversion Note: This fireplace comes with a Fig. #2 preinstalled Honeywell pilot. When installing the burner assembly, remove the pilot that came attached to the burner and discard. DO NOT USE ANY OTHER PILOT WITH YOUR OUTDOOR UNIT OTHER THAN ORIFICE HOUSING THE HONEYWELL PILOT THAT CAME... -
Page 7: Fireplace Dimensions
Fireplace Dimensions Fig. #5 11 1/8 11 11/16 STEEL STUD FRAMING KIT 48 9/16 IS WIDER THAN UNIT 47 7/8 36 1/8 32 1/2 38 1/2 38 1/2 Minimum Clearances to Combustible Material Fig. #6 NON-COMBUSTIBLE ZONE. STEEL FRAMING COMBUSTIBLE FRAMING AND DO NOT INSTALL ANY COMBUSTIBLE MATERI- AL, ELECTRICAL WIRING OR GAS PLUMBING IN FINISH WALL ABOVE STANDOFFS... -
Page 8: Installation Requirements
Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only qualifi ed (licensed or trained) personnel should install this product. -
Page 9: Top Standoffs
Top Standoffs Fig. #10 The top standoffs are shipped loose inside TOP STANDOFFS the fi replace and must be installed on top of the fi replace as shown in Fig #10. Do this once the fi replace is on site and in position. Locating The Fireplace In planning the installation for the fi replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed. -
Page 10: Framing And Finishing
Framing and Finishing Note: The fi replace should be in place position. Secure the steel frame to the framing and venting installed before framing in or brackets on each side of the unit. Ensure that Note: Installing unit without fl ashing building an enclosure around the unit. - Page 11 Fig. #13 Fig. #13a NON-COMBUSTIBLE BOARD DETAIL IF FINISHING THE WALL ABOVE THE UNIT WITH PAINT, THE FRAMING KIT SHIPPED WITH THE UNIT SHOULD BE DISCARDED. IT IS RECOMMENDED TO USE FULL NON-COMBUSTIBLE SHEETS OF CALCIUM SILICATE BOARD 12” BOARD OR ITS EQUIVALENT AND FULL LENGTH METAL STUDS TO FINISH AND FRAME AROUND THE UNIT.
-
Page 12: Tc36 Steel Stud Framing Kit
TC36 Steel Stud Framing Kit TC36.BFRKITA Each Kit Contains: Item Part # Description Qty. 5049.9912 SCREW, TEKS #8 x 1/2” 9794.2 STUD, SIDES, 48”L 9794.5 STUD, OUTER SIDES, 48”L 9093.22 STUD, CENTER, 15 7/16”L 9193.501 STUD, HEADER, 49 7/8”L 9393.001 STUD, PLATE, 41 1/4”L 9194.5... - Page 13 Fig. #17 2. Attach Side Studs (Legs) • Attach the outer side studs (3) to the top of the header stud (5). (Fig #17) • Fasten the outer side studs (3) at the bottom using the base plates (7). 3. Attach the Assembled Frame to Fig.
-
Page 14: Adjustable Lintel
Adjustable Lintel The adjustable lintel assembly has two Fig. #20 orientations for desired fi nishing. A fl anged edge and a hemmed edge. The lintel comes factory installed with the fl ange edge out. If the desired edge is different from the factory setting, use the following steps to change it(Fig.#20). -
Page 15: Hearth Extension
Hearth Extension Fig. #23 WINDOW FRAME 1" 1/4" SUB- HEARTH FLOOR EXTENSION WINDOW TRACK Caution: While a hearth extension is not required and combustible fl ooring materials may be brought directly up to the fi replace, many materials (such as wood fl ooring) may not tolerate the radiant heat from this fi replace, resulting in discoloration, shrinking and cracking. -
Page 16: Honeywell Control Valve
Honeywell Control Valve Plumbing and Electrical ACCESS PANEL Fig. #25 The gas control system is located on the right hand side of the fi rebox behind an access panel and the decorative fi rebox panel (if installed). The fi replace is operated via a wall switch. The wall control is connected to the fi replace by a 14-2 AWG wire, not supplied with the fi replace. -
Page 17: Gas Supply
Gas Supply Caution: The gas line should be installed by a qualifi ed service person in accordance with all building codes. This section is intended as a guide for qualifi ed technicians installing this appliance. Consult local and / or national building codes before proceeding. •... -
Page 18: Venting
Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent confi guration has been selected. Use only Town and Country Termination kits #: TCVT.WTA - Wall Termination Kit TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown in Fig. - Page 19 Fig. #30 Fig. #31 TRIM TO LENGTH WALL THIMBLE AND VENT MUST NOT PROTRUDE BEYOND SIDING Wall thimble: Where a vent pipe passes through a combustible wall, a wall thimble/shield must be used to retain insulation and maintain proper clearances. The wall thimble may be cut to length for various wall thicknesses up to 12"...
- Page 20 Vent pipe: Install vent pipe through the wall thimble and attach to fl ue outlet collar on top of the fi replace. Secure all joints with screws and seal with approved "High Temp." self-adhesive aluminum tape provided. Adjust the fi replace position so that the vent pipe does not protrude beyond the outer wall.
-
Page 21: Wall Termination Venting Chart
Wall Termination Venting Chart Fig. #34 Pipe length Minimum rise Pipe length Maximum run Max. 68 1/2” 1-24” 20 1/2" 1-12" 72 3/4” 1-12” 1-18" 75 3/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24”... -
Page 22: Roof Termination Venting Chart
Roof Termination Venting Chart Fig. #35 Pipe length Minimum rise Pipe length Maximum run Maximum 68 1/2” 1-24” 29" 1-12" 72 3/4” 1-12” 1-18" 75 1/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 1 1/2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24"... - Page 23 Fig. #36 Ceiling Opening: Determine the exact position of the fi replace so that the vent pipe is centered (if possible) between two building framing members. Lay out the vent system path, minimizing the 14 1/2" number of elbows and length of vent. Consult your local building codes prior to proceed- ing.
- Page 24 Roof Vent Terminal: 1. Place the roof fl ashing over the vent pipe, secure and seal it to the roof using the methods and materials appropriate for the type of roof on the building. Shingle roof example shown (Fig #38). Place the storm collar down over the vent pipe until it is level.
-
Page 25: Vent Terminal Clearance
Vent Terminal Clearance Fig. #40 Minimum clearances to the vent terminal must be maintained as shown VENT TERMINAL MINIMUM CLEARANCES in fi gure #40 & 41. Measure clearances to the nearest edge of termina- TO ADJACENT STRUCTURES tion hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE... -
Page 26: Vent Pipe Sealant
Vent Pipe Sealant Fig. #42 APPROVED “HIGH TEMP.” SELF-ADHESIVE TAPE VENT PIPE All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press fi rmly in place. -
Page 27: Vent Restrictor Adjustment
Vent Restrictor Adjustment The vent restrictor is located on the underside of the fi rebox top. The unit leaves the fac- Fig. #44 tory with the vent restrictor open. The restrictor is built into the appliance for secondary air WALL AND ROOF fl ow adjustment. -
Page 28: Firebox Panels Installation
Firebox Panels Installation (See Porcelain panel instruction manual for specifi c instructions for these panels) Before proceeding see burner instructions. Fig. #46 HEAT SHIELD FIREBOX LIP Fig. #45 SIDE PANEL RETAINER A Firebox Panel Set must be installed for safe operation. Do not use the fi replace without panels. - Page 29 Fig. #48 3. Install the Right Side Panel by inserting the bottom of the panel in fi rst and then angling it up into position. It may be necessary to push the fi rebox shield up to allow panel to move freely into place.
-
Page 30: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING - Do not touch any electric switch; do not use any phone in your WARNING: If you do not follow these instructions building. - Immediately call your gas supplier from a neighbour's phone. exactly, a fire or explosion may result causing Follow the gas supplier's instructions. -
Page 31: Maintenance
APPENDIX Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing appliance. It is recommended that the fi replace and its venting should be inspected at least once a year by a qualifi ed service person. Glass Panel: Warning: Do not operate fi replace with glass panel removed, cracked or broken. -
Page 32: Tc36.Ce3 Replacement Parts
TC36.CODE Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. PANEL SETS TC36 OUTDOOR BODY ASSM..TC36.CODE PARK AVE. BEIGE HERRINGBONE ....TCPN.36PAC MT.VERNON RED HERRINGBONE ....TCPN.36VRC GLASS ASSM........GLAS.2087ASSY MANHATTAN BEIGE STACKED BRICK ....TCPN.36MNC BLACK PORCELAIN .........TCPN.757031.C FRAMIMG KIT ........TC36.BFRKITA CB BROWN PORCELAIN .........TCPN.757031CB.C... -
Page 33: Replacement Parts - Honeywell Control System
Replacement Parts – Honeywell Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. #1..CONTROL ASSEMBLY KIT ....TCRP.9000 #2..BULKHEAD ASSEMBLY KIT ....TCRP.8133 #3..CONTROL BOX KIT ........ TCRP.92762WLD #4..TEST FITTING ......... 5019.104 KIT CONTENTS: #1.. -
Page 34: Wiring Diagram
Wiring Diagram Fig. #50 TC36.CODE 102513-40... -
Page 35: Light Wiring Diagram
TC36.COD 102513-40... -
Page 36: Wall Termination Kit
Wall Termination Kit Wall Shield/ TCVT.WTA Ceiling Firestop Fig. #53 Thimble TCVT.THIMA WALL Fig. #54 16 1/2" TERMINAL TCVT.9360 16 1/2" WALLSHIELD/CEILING FIRESTOP THIMBLE TCVT.THIMA 9 5/8" Roof Termination Kit TCVT.RTA Fig. #55 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 WALL SHIELD / CEILING FIRESTOP... -
Page 37: Vent Pipe Dimensions
Vent Pipe Dimensions Fig. #56 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16"... -
Page 38: Vent Offset Chart
Vent Offset Chart Fig. #57 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 10 7/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4” 11 3/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"... -
Page 39: Safety Label Location
Safety Label Location NOTE: The Safety Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the lintel with a cable. TC36.COD 102513-40... - Page 40 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
