Town & Country Fireplaces TC36ST Installation Instructions Manual

Tc36 see thru series d modular direct vent see-thru fireplace
Hide thumbs Also See for TC36ST:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
ammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier call
the re department.
Installation and service must be performed by
a quali ed installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room
Visit www.townandcountryfireplaces.com for the most up-to-date version of this manual
070617-40

INSTALLATION INSTRUCTIONS

TC36 SEE THRU
INSTALLATION
INSTRUCTIONS
MODEL
TC36ST
SERIES D
MODULAR DIRECT VENT
SEE-THRU FIREPLACE
TC36D_ST
5056.42801D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36ST and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC36ST

Summary of Contents for Town & Country Fireplaces TC36ST

  • Page 1: Installation Instructions

    This appliance is only for use with the type of gas MODEL indicated on the rating plate. This appliance is TC36ST not convertible for use with other gases, unless a certi ed kit is used. SERIES D MODULAR DIRECT VENT...

  • Page 2: Table Of Contents

    Table of Contents Caution ................3 Venting ................19 Safety ................3 Wall Termination Venting ..........19 Important Note for the Wall Termination Venting Chart ........22 Commonwealth of Massachusetts: ........4 Roof Termination Venting Chart ........23 Fireplace Dimensions ............5 Vent Terminal Clearance ..........

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country replace without rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous. This appliance and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed.

  • Page 5: Fireplace Dimensions

    32 1/2" 32 1/2" 3 9/16" 46 7/16" 55 15/16" 28 7/16" 38 1/2" Figure 1: TC36ST Overall dimensions. Minimum Clearances to Combustible Material NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATERIAL, STANDOFFS ELECTRICAL WIRING OR GAS PLUMBING IN THIS FINISH WALL ABOVE STANDOFFS AREA.

  • Page 6: Installation Requirements

    Installation Requirements The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only quali ed (licensed or trained) personnel should install this product.

  • Page 7: Top Standoffs

    (Figure 8). Due to high temperatures, do not locate this replace in areas of high traf c or near furniture or draperies. The minimum clearances from the fireplace to combustible surfaces must be adhered to as described in Figure 2 & Figure 3. Figure 8: TC36ST Possible locations. 5056.42801D_070617-40 TC36D_ST...

  • Page 8: Framing And Finishing

    KIT ATTACHED. BOTH FACES RECOMMENDED THAT MUST BE FRAMED WITH A FULL HEADER BE THE STEEL STUD FRAMING INSTALLED ABOVE THE KIT SUPPLIED WITH THE METAL FRAMING KIT FIREPLACE. 48 1/2” Figure 9: TC36ST With supplied steel frame. TC36D_ST 5056.42801D_070617-40...

  • Page 9: Minimum Combustible Framing Dimensions

    Figure 12: Non-combustible calcium silicate board.. 1/2" MINIMUM COMBUSTIBLE For nishing FRAMING DIMENSIONS material RANGE 28 1/4" 23 3/4" 27 1/4" 48 1/2" FRAMING 1/2" For nishing LINTEL material 59 1/2" INCLUDING SHEETROCK Figure 13: TC36ST Minimum combustible framing dimensions. 5056.42801D_070617-40 TC36D_ST...

  • Page 10: Tc36 Steel Stud Framing Kit

    TC36 Steel Stud Framing Kit Figure 14: TC36ST Steel frame parts. Each Kit Contains: Item Description Qty. Item Description Qty. STUD, HEADER 59 1/2 SCREW, TEKS #8 x 1/2 HORIZONTAL (Not shown) STUD PLATE 41 1/4” SIDE STUD, VERTICAL INNER HORIZONTAL 48 1/4”...
  • Page 11 Figure 16: Steel frame extent of movement. The two steel frames have a range of adjustment (See “Figure 13: TC36ST Minimum combustible framing dimensions.” on page 9) in order to accomodate varying wall depths from 23 3/4” to 27 1/4”. If the frames are postioned to their furthest extent, there will still be enough room (1/2”) to mount nishing material up to the xed lintel (Figure 16).
  • Page 12 (5). The side stud should attach to, and be perpendicular to the 41 1/4” stud plate (6). Fasten with the screws provided. Figure 17: TC36ST With steel frame. Fasten the vertical outer side studs (3) to the ends of the horizontal header stud (5).

  • Page 13: Fixed Lintel

    Fixed Lintel Framing Kit Adjustment The lintel on the TC42D2 is in a xed position on the replace and there is no adjustment to move the lintel toward you or away from you once the replace has been located in its nal position.

  • Page 14: Hearth Extension

    Fireplace Facing Allowance This replace may be recessed up NON-COMBUSTIBLE BUILDING MATERIAL MAY NOT to a maximum depth of 4 1/2”, this EXTEND PAST THIS POINT Area between lintel and recess must be constructed from glass door frame must non-combustible material. The space remain free of obstructions between the outside framing edge and the rebox must be completely free...

  • Page 15: Electrical

    Electrical The gas control system is located on the right hand side of the rebox behind an access panel and the decorative rebox panel (if installed). The replace is FIREBOX ACCESS PANEL operated via a wall control and a hand held remote control unit. The wall control is connected to the replace by a 40 ft.

  • Page 16: Wall Switch And Remote Control

    Wall Switch and Remote Control to replace Figure 29: Wall switch - battery side. Figure 28: Wall switch - interface side. Figure 27: Town and Country Insert a straightened paper clip 4. Press the ON/OFF button of the Wall switch. into the “PROGRAM”...

  • Page 17: Home Automation

    Home Automation The home automation feature supplied with this replace is capable of controlling the ame and light on/off function with the use of a dry contact relay common to home automation systems. Furthermore, the ame and light level may be modulated from high to low using the 0 - 10 volt analog output available on most home automation systems.

  • Page 18: Gas Supply

    Gas Supply CAUTION: The gas line should be installed by a quali ed service person in accordance with all building codes. This section is intended as a guide for quali ed technicians installing this appliance. Consult local and / or national building codes before proceeding.

  • Page 19: Venting

    Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent con guration has been selected. Use only Town and Country Termination kits #: TCVT.WTA - Wall Termination Kit TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace.
  • Page 20 Figure 34: Wall vent terminal. TRIM TO LENGTH WALL THIMBLE AND VENT MUST NOT PROTRUDE BEYOND SIDING Wall thimble: Where a vent pipe passes through a combustible wall, a wall thimble/shield must be used to retain insulation and maintain proper clearances. The wall thimble may be cut to length for various wall thicknesses up to 12"...
  • Page 21 32 1/2" from the center of the flue outlet to the outside face of the outer wall. The height will need to be increased with longer horizontal pipe. Figure 36: TC36ST Wall vent terminal framing. 5056.42801D_070617-40 TC36D_ST...

  • Page 22: Wall Termination Venting Chart

    90° can be used without reducing horizontal run. For each additional 90° elbow, or an equal combi- nation of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. Figure 37: TC36ST Horizontal rise - run chart. TC36D_ST 5056.42801D_070617-40...

  • Page 23: Roof Termination Venting Chart

    For each addi- tional 90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. Figure 38: TC36ST Vertical rise - run chart. 5056.42801D_070617-40 TC36D_ST...
  • Page 24 - See “Roof Pitch Table” on page 26 for precise lengths. Seal the vent pipe as per “Figure 44: TC36ST Sealing vent joints.” on page Roof Support Bracket: 1. Slip the roof support bracket down over the vent pipe. Rotate the 90°...
  • Page 25 Roof Vent Terminal: 1. Place the roof ashing over the vent pipe, secure and seal it to the roof using the methods and materials appropriate for the type of roof on the building. Shingle roof example shown (Figure 41). 2. Place the storm collar down over the vent pipe until it is level. Tighten storm collar for a snug t. Apply a thick horizontal ring of mastic around the pipe at top of the storm collar (Figure 41).

  • Page 26: Vent Terminal Clearance

    Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as shown in Figure 43. Measure clearances to the nearest VENT TERMINAL MINIMUM edge of termination hood. CLEARANCES TO ADJACENT STRUCTURES NOTE: Vent terminal must not be recessed. 36”...

  • Page 27: Vent Pipe Sealant

    APPROVED “HIGH TEMP.” SELF-ADHESIVE TAPE VENT PIPE Figure 44: TC36ST Sealing vent joints. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place.

  • Page 28: Vent Restrictor Adjustment

    Vent Restrictor Adjustment The vent restrictor is located on the underside of the rebox top. The WALL AND ROOF unit leaves the factory with the vent restrictor open. The restrictor is TERMINATION built into the appliance for secondary air ow adjustment. Adjustment RESTRICTOR POSITION enables tuning the air ow for optimum ame appearance and perfor- mance for a wide variety of vent con gurations.

  • Page 29: Wall Shield Ceiling Firestop Thimble

    Wall Shield Wall Termination Kit Ceiling Firestop Thimble WALL 16 1/2" TERMINAL TCVT.9360 16 1/2" WALLSHIELD/ CEILING WALL SHIELD / CEILING FIRESTOP THIMBLE FIRESTOP 9 5/8" TCVT.THIMA - OPTIONAL TCVT.THIMA Figure 47: Ceiling re-stop Figure 48: Wall termination kit. thimble. Roof Termination Kit 16 1/2"...

  • Page 30: Vent Pipe Dimensions

    Vent Pipe Dimensions 11" 12" Pipe ..10 1/4" 18" Pipe ..16 1/4" 24" Pipe ..22 1/4" 48" Pipe ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16" 1 5/16"...

  • Page 31: Vent Offset Chart

    Vent Offset Chart 12" PIPE 18 5/8" 18" 10 7/8” 18" PIPE 22 7/8" 22 3/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4” 11 3/8” ADDING AN ADJUSTABLE 1 1/4” SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"...

  • Page 32: Firebox Panels Installation

    5. Install the Right Side Panel. 6. Reinstall Panel Retainers. (HERRINGBONE PANEL SET SHOWN) RIGHT SIDE PANEL REAR RIGHT FLOOR PANEL REAR LEFT FLOOR PANEL LEFT SIDE PANEL LEFT FLOOR PANEL RIGHT FLOOR PANEL Figure 52: TC36ST Panels. TC36D_ST 5056.42801D_070617-40...

  • Page 33: Finishing Touch Trim Kit Instructions

    3. Attach the side rails. Even the ends up with the door frame. 4. Attach the top and bottom rails and adjust so mitres are even at the corners. LARGER MAGNETS TOP OR BOTTOM RAIL SIDE RAILS Figure 53: TC36ST Trim kit. 5056.42801D_070617-40 TC36D_ST...

  • Page 34: Lighting Instructions

    Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: - Immediately call your gas supplier from a neighbour's phone. Follow If you do not follow these instructions exactly, a the gas supplier's instructions. fire or explosion may result causing property damage, - If you cannot reach your gas supplier, call the fire department.

  • Page 35: Maintenance

    Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for PILOT unit to cool before servicing appliance. It is recommended that the replace and its venting should be inspected at least once a year by a quali ed service person. Glass Panel: FLAME PILOT...

  • Page 36: Tc36.Dst Replacement Parts

    DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #4 PANEL SETS #1 TC36ST BODY ASSY .......... TC36.DST PARK AVE. BEIGE HERRINGBONE ....TCPN.STPAC2 MT.VERNON RED HERRINGBONE ...TCPN.36STVRC2 #2 GLASS ASSY .............GLAS.2087 MANHATTAN BEIGE STACKED BRICK ...TCPN.36STMNC2 #3 FRAMING KIT ..........TC36. 9367-A BLACK PORCELAIN ........TCPN.757253.C...

  • Page 37: Replacement Parts - Control System

    1f ..........WIRING HARNESS 2e .........1/4” BULKHEAD FITTING (not shown) 1g ..........TRANSFORMER 2f ........ELEC BULKHEAD FITTING 1h ......PRESSURE TEST ASSEMBLY 1i ........REGULATOR BOARD #3 COMMUNICATION CABLE KIT 1j ......... PRESSURE SWITCH #4 TEST FITTING Figure 56: TC36ST Control system. 5056.42801D_070617-40 TC36D_ST...

  • Page 38: Wiring Diagram

    Wiring Diagram Figure 57: TC36ST Wiring diagram. TC36D_ST 5056.42801D_070617-40...

  • Page 39: Rating Label Location

    MODEL/ Minimum supply pressure / Pression minimum d’alimentation: 5.0 in/wc / 5.0 po/c.e. 12.5 in/wc / 12.5 po/c.e. MODELE: TC36ST (1.25 kPa) (3.11 kPa) (For the purpose of input adjustment / dans le but de régler l’alimenation) Maximum supply pressure / Pression maximum d’alimentation: 13.9 in/wc / 13.9 po/c.e.
  • Page 40 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, contact your retailer. Web site: www.townandcountry replaces.com 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
