Town & Country Fireplaces TC36 Installation And Operating Instructions Manual

Series b direct vent fireplace
Hide thumbs Also See for TC36:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Installation Instructions and Operating Manual
IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE
HOMEOWNER
FOR YOUR SAFETY
WARNING:
If the information in this
manual is not followed exactly, a fi re or
explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other
fl ammable vapours and liquids in the
vicinity of this or any other appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fi re department.
--Installation and service must be performed
by a qualifi ed installer, service agency or
the gas supplier.
This appliance may be installed in an
aftermarket permanently located, manu-
factured home (USA only) or mobile home,
where not prohibited by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certifi ed kit is
used.
270904-40
DIRECT VENT FIREPLACE
INSTALLATION
AND OPERATING
INSTRUCTIONS
TC36_B
MODEL
TC36
SERIES B
5056.42712
