INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
091014-16
TC36ST See-Thru
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART#
FOR TC36 SEE-THRU
SERIES D Fireplaces
TC36ST_NGST04D
TC36ST.NGST04D
5056.42801D4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36ST.NGST04D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC36ST.NGST04D

Summary of Contents for Town & Country Fireplaces TC36ST.NGST04D

  • Page 1 Operating Instructions supplied with the replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC36ST See-Thru TRANQUILITY BURNER KIT INSTRUCTIONS TC36ST.NGST04D PART# FOR TC36 SEE-THRU SERIES D Fireplaces 091014-16 TC36ST_NGST04D 5056.42801D4...

  • Page 2: Package Contents

    Package Contents lbs. Sand 5096.9935 Bag tapered plugs TC36.503152 Burner assembly TC36.9410 Line covers TC36.9699PBKA Pebble assembly TC42.9499 Instruction pack 5056.42801.C4 Tranquility Burner Installation Fig #1 In these instructions the right and left sides of the replace are referenced during the installation process.
  • Page 3 Tranquility Burner Installation Fig #3 If converting to propane see conversion instructions on page #9 before proceeding. Set shutter according to fuel used. Fully open for propane, closed for natural gas. 4. Place burner assembly into center of porcelain base panels. (Fig #3) 5.
  • Page 4 2 SCREWS Fig #5 6. Secure the electrical bulkhead plate and gasket to the rebox. (2 screws) Attach the ignition and sensor wires to the module. Red end to the connector marked by the red dot, white end to the connector marked by the white dot(Fig.
  • Page 5 7. Place second line cover over lines and Fig #7 attach to right side of rebox using top bulkhead screw. (Fig #7) 8. Install right porcelain panel and re-install panel retainer clips. (Fig #8) Fig #8 TC36ST_NGST04D_ 091014-16...
  • Page 6 9. Insert tapered plugs into raised burner ports Fig #9 to prevent sand from entering ports. (Fig #9) 10. Place sand in tray. Brush sand smooth and level to just below top of raised burner ports. Gently remove excess sand from around ports.
  • Page 7 11. Remove tapered plugs from ports. Fig #12 (Fig #12) 12. Gently place pebble assembly onto sand base using pins to locate position. (Fig #13) NOTE: Do not lift pebble assembly by the top rocks. Fig #13 TC36ST_NGST04D_ 091014-16...
  • Page 8 Fig #14 13. The three loose rocks may be placed anywhere in the sand around the pebble assembly (Fig #14) NOTE: Do not place on top of the main pebble assembly as sooting and poor performance could occur. 14. Install the door. Unit is ready for lighting. TC36ST_NGST04D_ 091014-16...

  • Page 9: Propane Conversion

    Propane Conversion Fig #15 This kit for use with model: / TC36STNG03.D WARNING Pour utilise avec du modèle: / TC36STNG04.D TC42 Date: ______________________ Series D This conversion kit By / Par: ___________________ shall be installed by a LP GAS/ This appliance was converted quali ed service agency to PROPANE GAS with DU GAZ LP...
  • Page 10 With a 7/16” wrench loosen the pilot head Fig #19 on the pilot assembly using a wrench to hold the bracket steady. (Fig. #19) 6. Slide the pilot adjustment band over and ensure that the hole in the ori ce band is showing.

  • Page 11: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply SUPPLY before removing the plug from the pressure test port. Verify gas pressures with the replace lit and on the Fig #21 highest setting. 1. Remove the plug from the pressure test port us- ing a 7/16”...

  • Page 12: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air to the gas burner. The shutter should be set to fully closed for natural gas or fully open for propane. ame should be just orange and “lazy” . It should NEVER be set to create sooting on internal parts and window glass.

  • Page 13: Replacement Parts

    Replacement Parts 1..TRANQUILITY CURB ....TC36.9416WLD 8..ORIFICE NG #25 ........5022.12 2..ROCK PAN ..........9416.5 ..ORIFICE LP 3/32 ........5021.31 3..TRANQUILITY LEG ....TC36.9415PBKA 9..TAPPED 1/8-27 NPT ........5019.21 4..FLOOR PAN....... TC36.9418PBKA 10 ..1/4” FLEX COMPRESSION ....5019.225 5..
  • Page 14 TC36ST_NGST04D_ 091014-16...
  • Page 15 TC36ST_NGST04D_ 091014-16...
  • Page 16 © 2014 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
