INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room
Visit www.townandcountryfireplaces.com for the most recent version of this manual
091418-41
INSTALLATION INSTRUCTIONS
TC36STD2
SEE THRU
INSTALLATION
INSTRUCTIONS
MODEL
TC36ST
SERIES D2
MODULAR DIRECT VENT
SEE-THRU FIREPLACE
TC36STD2
100000438-50
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC36STD2
Summary of Contents for Town & Country Fireplaces TC36STD2
- Page 1 FOR YOUR SAFETY Do not store or use gasoline or other TC36STD2 flammable vapors and liquids in the vicinity of this or any other appliance. SEE THRU INSTALLATION...
-
Page 2: Table Of Contents
NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is provided with the appliance and shall be installed for the protection of children and other at-risk individuals. TC36STD2 100000438-50 091418-41... -
Page 3: Caution
This appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. 100000438-50 091418-41 TC36STD2... -
Page 4: Important Note For The Commonwealth Of Massachusetts
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. TC36STD2 100000438-50 091418-41... -
Page 5: Fireplace Dimensions
Vertical vent pipe ..........1 3/4" in. (45 mm) Horizontal Vent pipe (Top, sides and bottom) ... 1 3/4" in. (45 mm) UNIT MAY BE RECESSED UP TO 4 1/2” WITH NON-CUMBUSTIBLE MASONRY Figure 3: TC36ST Mantel. TYPE MATERIAL 100000438-50 091418-41 TC36STD2... -
Page 6: Installation Requirements
Under moderate pressure it should pull forward and return to original position evenly on both sides. Figure 6: Handle. Figure 4: Safety barrier Figure 5: Accessing screen. handle. TC36STD2 100000438-50 091418-41... -
Page 7: Top Standoffs
(Figure 8). Due to high temperatures, do not locate this fireplace in areas of high traffic or near furniture or draperies. The minimum clearances from the fireplace to combustible surfaces must be adhered to as described in Figure 2 & Figure 3. Figure 8: TC36ST Possible locations. 100000438-50 091418-41 TC36STD2... -
Page 8: Framing And Finishing
KIT ATTACHED. BOTH FACES RECOMMENDED THAT MUST BE FRAMED WITH A FULL HEADER BE THE STEEL STUD FRAMING INSTALLED ABOVE THE KIT SUPPLIED WITH THE METAL FRAMING KIT FIREPLACE. 48 1/2” Figure 9: TC36ST With supplied steel frame. TC36STD2 100000438-50 091418-41... -
Page 9: Minimum Combustible Framing Dimensions
Figure 12: Non-combustible calcium silicate board.. 1/2" MINIMUM COMBUSTIBLE For nishing FRAMING DIMENSIONS material RANGE 28 1/4" 23 3/4" 27 1/4" 48 1/2" FRAMING 1/2" For nishing LINTEL material 59 1/2" INCLUDING SHEETROCK Figure 13: TC36ST Minimum combustible framing dimensions. 100000438-50 091418-41 TC36STD2... -
Page 10: Tc36 Steel Stud Framing Kit
STUD, HEADER 59 1/2 SCREW, TEKS #8 x 1/2 HORIZONTAL (Not shown) STUD PLATE 41 1/4” SIDE STUD, VERTICAL INNER HORIZONTAL 48 1/4” BASE PLATE SIDE STUD, VERTICAL OUTER 48 1/4” FRAMING PLATE STUD, CENTER 15 1/2” VERTICAL SHORT TC36STD2 100000438-50 091418-41... - Page 11 9) in order to accomodate varying wall depths from 23 3/4” to 27 1/4”. If the frames are postioned to their furthest extent, there will still be enough room (1/2”) to mount finishing material up to the fixed lintel (Figure 16). 100000438-50 091418-41 TC36STD2...
- Page 12 FROM THE FIREPLACE. framing through the horizontal top stud (5) and the base plates (7). Figure 18: TC36ST With cement board. Install Non-combustible Board Use drywall screws to install the concrete board. TC36STD2 100000438-50 091418-41...
-
Page 13: Fixed Lintel
The thickness of the facing material, wether 1/2 inch calcium silicate board or a rock facing must be taken into consideration before settling on a final position of the fireplace. See See “Fireplace Facing Allowance” on page 14. 100000438-50 091418-41 TC36STD2... -
Page 14: Hearth Extension
1” above the bottom of the fireplace. If thicker, fireplace must be raised accordingly. Caution: Hearth extensions thicker than 1” will interfere with the safety screen and window frame when opening. TC36STD2 100000438-50 091418-41... -
Page 15: Electrical
“ON” position. The Power vent igniter will start to spark. After switch a short delay, the pilot will light followed by the main burner. Wall switch Module connector Figure 24: Interface board Junction box Valve assembly components. 100000438-50 091418-41 TC36STD2... -
Page 16: Wall Switch And Remote Control
Important Note: When switching between PV and NV, both the electrical power supply to the fireplace must be turned off and the backup batteries removed to properly re-set the module. Figure 28: Vent mode selection switch. TC36STD2 100000438-50 091418-41... -
Page 17: Home Automation
Figure 30: Home automation wiring diagram. NOTE: • Digital I/O must be connected to a dry contact relay. • Analog flame and light input through 0 - 10 volt DC signal scaled as follows: Low = 1 volt High = 10 volts 100000438-50 091418-41 TC36STD2... -
Page 18: Gas Supply
Natural Gas Propane MANIFOLD Min. Pressure 5.0" WC 12.5" WC PRESSURE (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.5" WC 10" WC Minimum 1.6" WC 6.4" WC Figure 31: Test ports. TC36STD2 100000438-50 091418-41... -
Page 19: Venting
The rise and run must be constrained to the boundaries of the chart shown in Figure 35. The horizontal run of vent must have a 1/4" rise for every 1 ft. of run towards the termination. 100000438-50 091418-41 TC36STD2... - Page 20 Wall/Offset Support ............TCVT.811XOS Wall Termination Kit ............TCVT.WTA Roof Termination Kit ............TCVT.RTA Wall Shield/Ceiling Firestop ..........TCVT.THIMA Roof Flashing, Adjustable .........TCVT.811FLADJ Roof Flashing, Flat .............TCVT.811FLFLT Roof Flashing, Steep ..........TCVT.811FLSTP or any flashing that fits 11" pipe TC36STD2 100000438-50 091418-41...
- Page 21 32 1/2" from the center of the flue outlet to the outside face of the outer wall. The height will need to be increased with longer horizontal pipe. Figure 34: TC36ST Wall vent terminal framing. 100000438-50 091418-41 TC36STD2...
-
Page 22: Wall Termination Venting Chart
90° can be used without reducing horizontal run. For each additional 90° elbow, or an equal combi- nation of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. Figure 35: TC36ST Horizontal rise - run chart. TC36STD2 100000438-50 091418-41... -
Page 23: Roof Termination Venting Chart
For each addi- tional 90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. Figure 36: TC36ST Vertical rise - run chart. 100000438-50 091418-41 TC36STD2... - Page 24 2. Attach the brackets to the roof joists with nails or building screws. ROOF SUPPORT BRACKET (TCVT.93915) 3. Tighten the band around the vent pipe and secure in place with screws. Figure 38: Roof support bracket. TC36STD2 100000438-50 091418-41...
- Page 25 VERTICAL TERMINATION CAP (TCVT.9365) Note: VENT PIPE Adjustable for various roof pitches, from flat roof to 12/12 MASTIC STORM COLLAR pitch roof. (TC42.90665) FLASHING Figure 39: Roof vent terminal. 100000438-50 091418-41 TC36STD2...
-
Page 26: Vent Terminal Clearance
** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the floor* * as specified in CGA B149 Installation Codes, Note: local Codes or Regulation may require different clearances * for U.S.A. Installations follow the current National Fuel Gas Code, ANSI Z223.1 TC36STD2 100000438-50 091418-41... -
Page 27: Vent Pipe Sealant
Figure 42: TC36ST Sealing vent joints. All outer joints of the vent pipe must be sealed with the approved "High Temperature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press firmly in place. 100000438-50 091418-41 TC36STD2... -
Page 28: Vent Restrictor Adjustment
Loosen the screws holding the restrictor plates. • Move the restrictor plates to its intended opening. Opening • Retighten the screws. Vent CAUTION: The vent restrictor must be fully open when using the restrictor power vent Figure 44: Vent restrictor. TC36STD2 100000438-50 091418-41... -
Page 29: Wall Shield Ceiling Firestop Thimble
Figure 45: Ceiling fire-stop Figure 46: Wall termination kit. thimble. Roof Termination Kit 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 WALL SHIELD / CEILING FIRESTOP ROOF SUPPORT TCVT.THIMA BRACKET TCVT.93915 Figure 47: Roof termination kit. 100000438-50 091418-41 TC36STD2... -
Page 30: Vent Pipe Dimensions
48" Pipe ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16" 1 5/16" 13 1/8" 7/16" 10 5/16" TCVT.811XLB45 15 7/8" TCVT.811XLB90 Figure 48: Vent pipe dimensions. TC36STD2 100000438-50 091418-41... -
Page 31: Vent Offset Chart
20" 1 1/4” 1 1/4” 18 3/4” 12” PIPE 29” ADDING AN ADJUSTABLE 18” PIPE 35” SECTION TO PIPE WILL INCREASE OFFSET BY 3" TO 9 1/2" 24” PIPE 41” 48” PIPE 65” Figure 49: Vent offsets. 100000438-50 091418-41 TC36STD2... -
Page 32: Firebox Panels Installation
5. Install the Right Side Panel. 6. Reinstall Panel Retainers. (HERRINGBONE PANEL SET SHOWN) RIGHT SIDE PANEL REAR RIGHT FLOOR PANEL REAR LEFT FLOOR PANEL LEFT SIDE PANEL LEFT FLOOR PANEL RIGHT FLOOR PANEL Figure 50: TC36ST Panels. TC36STD2 100000438-50 091418-41... -
Page 33: Finishing Touch Trim Kit Instructions
3. Attach the side rails. Even the ends up with the door frame. 4. Attach the top and bottom rails and adjust so mitres are even at the corners. LARGER MAGNETS TOP OR BOTTOM RAIL SIDE RAILS Figure 51: TC36ST Trim kit. 100000438-50 091418-41 TC36STD2... -
Page 34: Lighting Instructions
Serveiller les enfants. Garder les vêtements, le meubles, l'essence ou autres liquides produisant des vapeurs infl ammables loin de l'appareil. S'assurer que le brûleur et le compartiment des commandes sont propres. Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil. 090713 5051.185 GBWY TC36STD2 100000438-50 091418-41... -
Page 35: Maintenance
Viewing glass may be cleaned as necessary with fireplace glass cleaner. b) Exterior finish may be cleaned with mild soap and water. CAUTION: Do not use abrasive cleaners on glass or any other part of the fireplace. Do not clean glass when hot. 100000438-50 091418-41 TC36STD2... -
Page 36: Tc36.Dst Replacement Parts
4a ..........PANEL, LEFT SIDE ....BRICK PANEL RETAINER (not shown) 4b ........PANEL, RIGHT BASE 4c ......... PANEL, RIGHT SIDE #2 GLASS ASSEMBLY 4d .......... PANEL, LEFT BASE 2a ....REPLACEMENT GLASS (c/w gasket) Figure 53: TC36ST Replacement parts. TC36STD2 100000438-50 091418-41... -
Page 37: Replacement Parts - Control System
2e .........1/4” BULKHEAD FITTING (not shown) 1g ..........TRANSFORMER 2f ........ELEC BULKHEAD FITTING 1h ......PRESSURE TEST ASSEMBLY 1i ........REGULATOR BOARD #3 COMMUNICATION CABLE KIT 1j ......... PRESSURE SWITCH #4 TEST FITTING Figure 54: TC36ST Control system. 100000438-50 091418-41 TC36STD2... -
Page 38: Wiring Diagram
Wiring Diagram Figure 55: TC36ST Wiring diagram. TC36STD2 100000438-50 091418-41... -
Page 39: Rating Label Location
SEP OCT NOV DEC 2016 des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui accompgne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez un installateur, un technicien agréé ou le fournisseur de gaz. 030914 5050.7207D 1-TC36-D 100000438-50 091418-41 TC36STD2... - Page 40 © 2018 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, contact your retailer. Web site: www.townandcountryfireplaces.com 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
