WIRING DIAGRAM
L
Power
supply
(110/230Vac - 28A)
LIVE
NEUTRAL
EARTH
Power supply
110/230Vac
8
Box opening
N T T1 T2
EARTH
L N
OUT L1
(110/230Vac - 13A)
3000W max. at 230Vac
1500W max. at 110Vac
L1
www.bromicheating.com
hours LED
minutes LED
seconds LED
ON/OFF LED
Impulsive LED
L N
OUT L2
(110/230Vac - 13A)
3000W max. at 230Vac
1500W max. at 110Vac
Mount the product vertically
with the cable glands downward
L2
Switch
for output
selection
Out L1 ↑
Out L2 ↓
Aerial
connection
N
L2
L
110/230Vac
E
3000W max. (at 230Vac)
1500W max. (at 110Vac)
N
L1
L
110/230Vac
3000W max. (at 230Vac)
E
1500W max. (at 110Vac)
