Bromic Heating TUNGSTEN SMART-HEAT User Manual page 6

OPERATION
2.2.1 Setting relay function - ON/OFF
ON/OFF Function
Press the 'SET' button twice and hold it down until the
'ON-OFF' LED turns on. Wait until the LED turns off to
confirm the memorisation of the data.
Before starting select the output L1 or L2, using the switch (see picture at page 9). The following memorization/deletion
will be applied only to the selected output. Anyway it's possible to associate a double channel to both of the output, re-
peating the procedure.
2.2.2 Programming of a double channel
1. Press the 'MEM' button two times and hold the button on the second time. There will be 2 beeps and followed by a
continuous sound.
2. While holding 'MEM' the button (during continuous sound), press the button on the remote that will be programmed.
The programming is confirmed by an intermittent sound.
Note: in case of commanding an output with TIMER function, it's possible to stop the counter before the set time using
buttons CH2, CH4 or CH7.
2.2.3 Copying a function of remote to a new remote. See remote manual for detail on P3 button.
1. Press the P3 button inside the already programmed remote. The active receiver will sound continuously. If there is no
sound, the remote is not programmed into the receiver.
2. Within 5 seconds, press a button of the already programmed remote, relative to the function to copy. The sound will
be interrupted, and continue for another 5 seconds.
3. During the sound, press a button of the new remote that requires to be programmed. The programming is indicated by
an intermittent sound.
2.2.4 Deleting a double channel function from the receiver
1. Press the P2 button once and hold it down. There will be a slow and intermittent sound.
2. During the sound, press the button of the remote that will be deleted. The deletion is indicted by a continuous sound.
6
www.bromicheating.com
