PRODUCT OVERVIEW & INSTALLATION
1 DESCRIPTION
The Wireless ON/OFF control is for resistive and infrared heaters. The controller allows the power output of the
heater to be turned on/off. The wireless control can be used with 110 - 230VAC supply voltages.
1.1 FEATURES
• Controls TWO 3000W heaters at 230VAC (1500W at 110VAC).
• ON/OFF function with dual output control
1.2 KIT CONTENTS
• Wireless controller enclosed in a protective box.
• 4-channel remote
2.1 INSTALLATION
Study the WIRING DIAGRAM at the end of this document before starting installation.
WARNING: Isolate mains before installing. Use only on with a properly secured heater.
PLUG AND SUPPLY CORD: Use an appropriately rated plug and supply cord - check the power
requirements of the connected loads. Socket outlet used must be near the equipment.
OVERCURRENT DEVICE: The outputs are NOT protected against short circuits or extra-currents which
can damage the electronic board. Evaluate the characteristics of the connected loads and apply the
appropriate safety devices to the power line.
The wireless control must be mounted using the following guidelines:
• It must be fixed on surfaces which cannot be damaged by high temperature.
• It must be placed in a well-ventilated location.
• It must be fixed vertically, with cable glands downward.
• Connection cables must be protected against any accidental impacts, using proper pipes.
• Do not cover the product.
• Do not use or store flammable materials close to the product.
1. Open cover to the box.
2. Wire in power and heater as per the wiring diagram.
3. Power on the wireless control.
4. Program the wireless control as per 'OPERATION' section.
5. Refit cover to the box.
2.2 OPERATION
Before programming, select the output L1 or L2, using the switch as outlined in the 'WIRING DIAGRAM'.
The following programming will be ONLY applied to the selected output.
It is possible to associate a single or double channel function to both of the outputs by repeating the procedure.
!
WARNING: The receiver automatically saves the setting 5 seconds after button release.
!
IMPORTANT: The included 4-channel remote functions as a 4 x single channel remote OR a 2 x double channel remote
(paired Ch1 with Ch2 and Ch3 with Ch4). Functions are:
Single Channel Functions – On/Off with the same button
Double Channel Functions – On with Ch1 or Ch3. Off with Ch2 or Ch4
