Important Information
3.
As you fit the lens inside the aperture, insert the remote lock connector
4.
Once inside the aperture, rotate the lens clockwise to lock it into position, then tighten the two
captive screws
5.
Close the remote lock cover, making sure the excess cable is not trapped.
Tighten the two captive screws
Page 30
.
7
and the lock
8
using the provided key.
9
in the socket
5
6
5
6
7
7
8
8
9
.
