NEC NP-PH1000U Specification

PH Series
PH1000U digital projector
Powerful installation projector that delivers quality, larger-than-life images
under virtually any operating condition. Capable of taking on even the
most demanding integration projects, it is ideal for large venues or high
ambient lighting conditions.
FLEXIBILITY ENABLES PERFORMANCE
° Integrated Device Technology HQV™ is a high-performance video processing/
scaling system designed for computer signals as well as standard or high-
definition video. The technology produces superior video processing using pixel-
based, motion-adaptive de-interlacing to remove undesirable motion artifacts
typical of interlaced signals. This processing creates life-like images in
applications such as video conferencing.
° Powered by a unique 3-chip 0.96" DLP system, this 11,000-lumen projector
features a sleek, compact design with WUXGA resolution and dual UHP lamps
° Geometric correction tool allows you to project on spheres, cylinders and more
° VIDI technology, a Phillips innovation designed to work in conjunction with the color wheel, uses a brilliant pulse to increase the brightness of the
image and a dark pulse to increase the contrast ratio
INTEGRATED NETWORKING AND ASSET MANAGEMENT
° Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability)
° Optional high-speed wireless LAN IEEE 802.11b/g/n
° Desktop control allows you to securely transmit information wirelessly to the projector from a docking station or PC in another room
° Image Express Utility (IEU 2.0; compatible with Windows or Mac operating systems) dedicated projector software provides wired and wireless data
transmission via peer-to-peer or over the network
• Broadcast mode allows you to send information from one
computer to several projectors
° Windows Network Projector function within Windows Vista connects
directly to networked projectors without the need for additional
proprietary software
° Windows Remote Desktop function allows you to control a networked
computer by connecting a USB mouse and keyboard directly to the
projector's USB input
° Windows Network Drive Function displays multimedia files (.jpeg,
.bmp, .png, .mpeg2 or .wmv9) in the Windows shared folder on a
local network using the Viewer function—all without bringing your
PC into the conference room
° Windows Media Connection Function displays multimedia files
(.mpeg2, .jpeg or .wmv9) stored on the Windows Media Connect
server or a local network using the Viewer function—all without
bringing your PC into the conference room
° Crestron Roomview Connected™
SECURITY FEATURES PROVIDE PEACE OF MIND
° Cabinet control lock setting enables user to deactivate buttons on
cabinet to prevent unwanted changes to projector settings
° Logo lock restricts changes to logo saved in projector memory
° Password protection restricts unauthorized use of projector
° Email notification informs the system administrator when the lamp
approaches the end of its useful life
www.necdisplay.com
Lens Shift
Enjoy greater installation
flexibility with +55%/-
40% vertical lens shift
and +/- 20% horizontal
lens shift. Ships lensless
with a complete line of
optional bayonet style
lenses (6) for quick and
easy exchange. Lens
throw distances range
from 2.6 to 179.8 feet.
Professional Installation
Projectors
