NEC NP-PH1201QL User Manual page 21

Germany
Plug: CEE7
USA
Plug: NEMA 6-15P
Japan
Plug: JIS C 8303
China
Plug: GB2099
Connector
Dimensions of the connector of the power cable are shown below.
+0,5
2,5
6,0
-0
Unit: mm
Cable: H05VV-F 3G1.5
Cable: SJT 3 x AWG 14
Cable: VCTF 3 x 2.0mm
Cable: RVV 300/500
13
±
0,2
+0,5
R3.5 min
-0
+0,5
7
-0
Connector: IEC 320 C19
Connector: IEC 320 C19
Connector: IEC 320 C19
Connector: GB17465.1
+0
28
-0,9
Important Information
+0
20
-0,7
Page 21
