Important Information
The projector can be operated in numerous positions, as described below.
PITCH
The projector can be positioned at any angle around the pitch axis. Please consider the following:
•
When the projector is within 15° to either side of the vertical plane, the temperature of the
operating environment needs to be between 0 and 30°C.
•
In every other position, the operating temperature is between 0 and 35°C.
ROLL
The projector can be positioned in numerous positions around the roll axis. Please consider the
following:
•
The projector cannot be positioned within 15° to either side of the vertical plane (in portrait
mode) with the inputs pointing downward.
•
When the projector is within 15° to either side of the vertical plane (in portrait mode) with the
inputs pointing upward, the temperature of the operating environment needs to be 0 to 30°C.
•
In every other position, the operating temperature is between 0 and 35°C.
Portrait mode installation requires fitting a safety guard underneath the projector (as shown in the
illustration below). Unauthorised personnel should not attempt to carry out portrait mode
installation. Please contact NEC or a dealer if you wish to use the projector in portrait mode.
Page 12
±15°
0-30°C
0-30°C
±15°
Pitch
±15°
0-30°C
±15°
Roll
