Summary of Contents for NEC NP-PH1201QL
- Page 1 Projector NP-PH1201QL Important Information...
- Page 2 Telephone: +81 465 85 2369 Email: infomail@nec-displays.com NEC Solutions (China) Co.,Ltd. In North America Address: Rm 1903, Shining Building,35 Xueyuan NEC Display Solutions of America, Inc. Rd, Haidian District Beijing 100191, P.R.C. Address: 500 Park Boulevard, Suite 1100 Telephone: +8610 59342706 Itasca, Illinois NEC Hong Kong Ltd.
-
Page 3: Important Information
Assicuratevi di leggere il manuale dell’utente contenuto all’interno del CD-ROM in dotazione, che fornisce in- formazioni dettagliate sul prodotto e sul suo utilizzo, note generali e risoluzione dei problemi per il proiettore NEC. • Este documento (Important Information) proporciona exclusivamente información sobre la seguridad del proyec- tor y precauciones. -
Page 4: Table Of Contents
Important Information Contents Symbols used in the User Manual ....................5 Electrical and physical specifications ..................5 Non-accessible laser parameters ....................5 Labels ..............................6 Product Label ..........................6 Other labels ............................7 Label locations ..........................7 Location of laser aperture ......................8 Interlock switches ..........................8 Location ............................8 Interlock switch control block diagram ..................8 Important safeguards ........................9... -
Page 5: Symbols Used In The User Manual
Important Information Symbols used in the User Manual LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the instructions are closely followed. ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely followed. -
Page 6: Labels
Laser Notice No. 50, dated June 24, 2007 NEC Display Solutions, Ltd. Contact address for EMEA 4-28, Mita 1-chome, Minato-ku, Tokyo, Japan NEC Display Solutions Europe GmbH Landshuter Allee 12-14 80637 Munich, Germany 115-364C Within the Product Label: Manufacturer’s Identification Manufacturer’s name, address and projector model name... -
Page 7: Other Labels
Laser Notice No. 50, dated June 24, 2007 NEC Display Solutions, Ltd. Contact address for EMEA 4-28, Mita 1-chome, Minato-ku, Tokyo, Japan NEC Display Solutions Europe GmbH 115-364C Landshuter Allee 12-14 80637 Munich, Germany Product Label Protective Housing Label... -
Page 8: Location Of Laser Aperture
Important Information Location of laser aperture Laser aperture Interlock switches Five interlock switches installed at the main frame, inside the cover, will power-off the system individually when activated. Location Will be activated when the top cover is removed. Will be activated when the lens is removed. -
Page 9: Important Safeguards
Important Information Important safeguards These safety instructions are to ensure the long life of your projector and to prevent fire, shock, damage and injury. Please read them carefully and heed all warnings. Laser precautions This product is classified as Class 3R of IEC60825-1 and 21 CFR Part 1040.10 Safety Standards. CAUTION Visible Laser Light Do Not Stare into Beam... -
Page 10: Installation And Handling
Important Information The unit is never to be operated if the unit is defective or the cover or seal is damaged. The end user is not allowed to open or modify the product. No maintenance allowed by end user. Do not open the cabinet. There are no user serviceable parts inside. No service is allowed except by authorized personnel. - Page 11 Important Information Do not place the projector in direct sunlight, near heaters or heat radiating appliances. Exposure to direct sunlight, smoke or steam could harm internal components. Do not expose the projector to rain or moisture, and do not place any liquids on top of the projector. Do not expose the projector to dust.
- Page 12 Portrait mode installation requires fitting a safety guard underneath the projector (as shown in the illustration below). Unauthorised personnel should not attempt to carry out portrait mode installation. Please contact NEC or a dealer if you wish to use the projector in portrait mode. Page 12...
-
Page 13: Power Supply
Important Information Projectors are not designed to be stacked on top of each other unless a rigging frame is used. When stacking projectors, the stack MUST be vertical, to ensure that the stresses are distributed to all four chassis corners. Power supply The projector is so designed that it operates with the power supply voltage described below. -
Page 14: Fire And Shock Precautions
Important Information Fire and shock precautions Ensure that there is sufficient ventilation and that vents are unobstructed to prevent potentially dangerous concentrations of ozone and the build-up of heat inside your projector. Allow at least 12 inches (30cm) of space between your projector and a wall. In particular, clear a space of 27.6 inches (70 cm) or more in front of the air outlet on the rear surface and 19.8 inches (50 cm) or more in front of the air outlet on the Laser side. -
Page 15: Light Module
Always double-check your settings before applyinjg any changes to your networking configuration. Always keep a written note of the original settings, and any changes you have made. Software update should NOT be carried out except by, or with the supervision of, NEC Service personnel. Page 15... -
Page 16: Compliance With International Standards
NEC is fully committed to minimising Waste Electrical and Electronic Equipment. Our products are designed with reuse, recycling and recovery of all components in mind. To this end, at end of life, your projector may be returned to NEC or its agent so that the environmental impact can be minimised. -
Page 17: Ukrainian Rohs Information Relevant For Ukrainian Market
4. Hexavalent chromium (Cr6+) – not over 0,1wt % or 1000wt ppm; 5. Polybrominated biphenyls (PBBs) – not over 0,1wt % or 1000wt ppm; 6. Polybrominated diphenyl ethers (PBDEs) – not over 0,1wt % or 1000wt ppm. NEC Display Solutions, Ltd. Ukrainian Декларація про Відповідність... -
Page 18: What's In The Box
Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Please save the original box and packing materials if you ever need to ship your projector. User Manual CD x 1 NP-PH1201QL projector (without lens) x 1 Important Information x 1 service keys x 2... -
Page 19: Basic Setup And Operation Instructions
Important Information Basic setup and operation instructions Positioning the screen and projector Install the screen, ensuring that it is in the best position for viewing by your audience. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to fill the screen. -
Page 20: Selecting A Power Cable
Important Information Selecting a power cable The power cable is not included with the projector. Refer to the AC power work specifications section below and provide the necessary power cable. Carefully read the contents described in this section before connection and connect the cables according to the proper procedure. - Page 21 Important Information Germany Plug: CEE7 Cable: H05VV-F 3G1.5 Connector: IEC 320 C19 Plug: NEMA 6-15P Cable: SJT 3 x AWG 14 Connector: IEC 320 C19 Japan Plug: JIS C 8303 Cable: VCTF 3 x 2.0mm Connector: IEC 320 C19 China Plug: GB2099 Cable: RVV 300/500 Connector: GB17465.1...
-
Page 22: Connecting The Power Supply
Important Information Connecting the power supply When the projector is viewed from the back, the AC mains inlet is located on the right hand side, toward the rear. Make sure the power switch above the inlet is in the OFF position, then push the mains connector in firmly. -
Page 23: Switching The Projector Off
Important Information Switching the projector off Press the button for three seconds or POWER longer. The light source switches off and the projector begins cooling down. During the cooling down process, the status indicator flashes SYSTEM amber. The fan continues to work and a message is displayed on the LCD screen to show that the projector is still not switched off. -
Page 24: Selecting A Test Pattern
Important Information When is displayed, press Title Select DOWN Press to go through the list of Title Select LEFT RIGHT available titles until you reach the title you wish to display. Title Name Press to confirm your choice. The ENTER projector begins displaying the title. - Page 25 Important Information When is displayed, press Title Select DOWN Press until is set to LEFT RIGHT Title Select TEST Pattern Title Select TEST Pattern Press again, then press DOWN LEFT RIGHT cycle through the list of test patterns. Alignment ...
-
Page 26: Adjusting The Lens
Important Information Adjusting the lens Title Select Press to access the menus. MENU Configuration Press the arrow button repeatedly LEFT RIGHT until the menu is displayed. Configuration Press the arrow button once to access DOWN Configuration ... -
Page 27: Assembling The Lens
Important Information Assembling the lens Detach the retaining plates from the lens holder. Use a 2.5 mm Allen key to remove the M3 socket head screws Insert the lens into the lens holder. Align the notches on the lens with the notch on the holder Page 27... - Page 28 Important Information Keeping the lens and holder aligned, secure the retaining plates removed earlier. Attach the motor cover using the two M2 socket head screws provided. Ensure the connector cable is not trapped. Page 28...
-
Page 29: Inserting A New Lens
Important Information Inserting a new lens Before changing the lens, always make sure the projector is switched off and fully disconnected from its power supply. When changing the lens, avoid using excessive force as this may damage the equipment. Take care to preserve the original lens packaging and protective caps for future use. The projector will not power on without the lens fitted. - Page 30 Important Information As you fit the lens inside the aperture, insert the remote lock connector in the socket Once inside the aperture, rotate the lens clockwise to lock it into position, then tighten the two captive screws Close the remote lock cover, making sure the excess cable is not trapped. Tighten the two captive screws and the lock using the provided key.
-
Page 31: Removing The Lens
Important Information Removing the lens Before changing the lens, always make sure the projector is switched off and fully disconnected from its power supply. When changing the lens, avoid using excessive force as this may damage the equipment. Take care to preserve the original lens packaging and protective caps for future use. The projector will not power on without the lens and lens hood fitted. Loosen the two captive screws on the lens remote lock cover, then release the lock using the provided key. - Page 32 Important Information Loosen the two captive screws on the lens and rotate the lens counterclockwise until it stops. Unplug the remote lock connector and pull the lens out of its socket. Page 32...
-
Page 33: Cleaning And Replacing The Rear Air Filters
Important Information Cleaning and replacing the rear air filters Before changing the filters, always make sure the projector is switched off and fully disconnected from its power supply. When changing the filters, avoid using excessive force as this may damage the equipment. Loosen the two knobs holding the filter cover by turning them counterclockwise. - Page 34 Important Information If you are replacing the filters, skip this step. To clean the filters, use a vacuum cleaner brush attachment to vacuum away dust from the air filters. Avoid making direct contact without an attachment or using a nozzle attachment. Mount the air filters to the projector.
-
Page 35: Cleaning And Replacing The Front Air Filter
Important Information Cleaning and replacing the front air filter Loosen the two captive screws on the filter cover and remove the cover. Remove the air filter. If you are replacing the filter, skip this step. To clean the filter, use a vacuum cleaner brush attachment to vacuum away dust from the air filter. - Page 36 Important Information Mount the air filter to the projector. Look for an arrow indicating the installation direction on the side of the air filter. Point the arrow towards the projector. Mount the filter cover to the projector. Tighten the two captive screws to secure the cover. Page 36...
-
Page 37: Control Panel Reference
Important Information Control panel reference LCD display not used in this configuration KEY LOCK button (with indicator) POWER button (with indicator) Arrow buttons EXIT button MENU button DOUSER button (with indicator) ENTER button LIGHT ON / OFF button (with indicator) not used in this configuration not used in this configuration (except for entering...
