Appliance Dimensions - AGA TOTAL CONTROL TC3 Installation Manual

REAR OVEN VENT
PIPE POSITION
RH SIDE
OVEN VENT
OPTION
RH SIDE VIEW
Fig. 1
MINIMUM WALL POSITION
A B C
mm 987 948 910 680 1388 760 1145 698 116
Cooker Dimensions
When surveying for a cooker installation the actual clearance required for the 'body' of the
appliance should be increased by 10mm beyond the figures quoted above. This allows safe
margin to take into account the natural dimensional variations found in major castings. In
particular the width across the appliance recess could be critical.
APPLIANCE WEIGHT
Model: AGA Total Control (TC3) - 370kg

APPLIANCE DIMENSIONS

FRONT VIEW
PLAN VIEW
D E F G H
4
REAR OVEN VENT
PIPE POSITION
LH SIDE
OVEN VENT
OPTION
LH SIDE VIEW
MINIMUM WALL POSITION
J K L M
10 536 813 30 634 448 824
DESN 516358 A
N P Q R
