NetSure ™ 9500 120kW 400V DC Power System
Operation Manual, UM584001200 (Issue AA, April 14, 2014)

Customer Documentation Package

This document (UM584001200) provides Operation Instructions for
NetSure™ 9500 120kW 400V DC Power System Model 9500, Spec.
No. 584001200.
The complete Customer Documentation Package consists of...
™
NetSure 9500 120kW 400V DC Power System Installation
Manual
•
Power System Installation Instructions: IM584001200
NetSure ™ 9500 120kW 400V DC Power System Operation
Manual
•
Power System Operation Instructions: UM584001200
•
Rectifier Instructions: UM1R40015000e
•
Power System "System Application Guide":
SAG584001200
NetSure ™ 9500 400V DC Battery Cabinet Installation and
Operation Manual
•
Battery Cabinet Installation and Operation Instructions:
IM58400120090
NetSure ™ ACU+ Controller User Manual
• ACU+ Controller User Instructions: UM1M820NNB-2
USB Drive with All Customer Documentation
•
Power System Installation Instructions: IM584001200
•
Power System Operation Instructions: UM584001200
•
Battery Cabinet Installation and Operation Instructions:
IM58400120090
• Rectifier Instructions: UM1R40015000e
• Power System "System Application Guide":
SAG584001200
•
ACU+ Controller User Instructions: UM1M820NNB-2
•
Engineering Drawings
•
Also provided on the USB drive is an ACU+ configuration
drawing and the ACU+ configuration files loaded into the
ACU+ as shipped.
Spec. No: 584001200
Model No: 9500

System Description

400V DC Output @ up to 120kW Power System
The NetSure™ 9500 120kW DC Power System is a complete
integrated power system containing rectifiers, intelligent control,
metering, monitoring, and distribution.
A system can consist of a Power Module/Bay, optional Distribution
Module/Bay, and Battery Cabinets.
This power system is capable of operating either with or without
batteries online.

Power Module/Bay (List 01)

The Power Module/Bay consists of the following components. All
Power Module/Bay components are factory installed in the
selected rack.
Power and Control Section
The power and control section houses up to eight (8) rectifiers and
the system control and monitoring components.
• Rectifier
The system contains one (1) to eight (8) rectifiers, which
provide load power, battery float current, and battery
recharge current during normal operating conditions.
Refer to the rectifier instructions (UM1R40015000e) for
more information.
•
AC Input Distribution
A main AC input circuit breaker (250A) is provided, along
with individual AC input circuit breakers (40A) for each
rectifier.
•
Controls
ACU+ (Advanced Control Unit Plus) Controller
The system controller provides power system control,
rectifier control (including a charge control function),
metering functions, monitoring functions, and
local/remote alarm functions. Power system control
includes battery low voltage disconnect (BLVD)
functionality to remotely trip battery circuit breakers
which protects batteries against over-discharge. The
system can also be equipped with one (1) to six (6)
temperature probe(s). Any combination of the six (6)
temperature probes can be programmed to monitor
ambient air temperature and/or battery temperature. A
temperature probe set to monitor battery temperature
can also be used for the rectifier battery charge
temperature compensation feature and/or BTRM
(battery thermal runaway management) feature. The
[1 of 13]
Code: UM584001200
Issue AA, April 14, 2014
