UC50e
Quick Setup
Instructions
WARNING: Electrical and
plumbing connections need
to be made by a qualified
service person who will
comply with all available
Federal, State and Local
Health, Electrical, Plumbing
and Safety codes.
RINSE
TEMPERATURE
STEP
5
START
Push the power button to turn on the dishmachine.
Wash tank will fill automatically. Wait for 15-20
minutes before wash temperature reaches
155F-160F (check wash temp gauge).
STEP
8
At the end of the day, push the power button
(STEP 5) to turn power off. When draining the
dishmachine, remove overflow tube located inside
the wash tank.
UC50e FRONT VIEW
START
STEP
6
START
Push button to change time cycle. Push to the "IN"
position to run for 120 seconds and the "OUT"
position for 180 second run.
800-854-6417
5
POWER
7
START
9
DRAIN
6
PROGRAM
8
OVERFLOW
TUBE
WASH
TEMPERATURE
FINAL RINSE
PRESSURE
STEP
7
START
Push the "START" button to activate the
dishmachine.
STEP
9
START
With the overflow tube removed, push drain button
to empty dishmachine. Reinstall overflow tube when
drain cycle is complete.
DISHMACHINES
4-2013
