Installing the Print Head
There are 3
magnets for holding
the print head in
place.
After fitting the print
head, plug in the
cable to connector
residing on the print
head.
Correct installation.
1
3
Incorrect installation, note the magnet
under the print head is not in contact
with the motor.
06
During installation
m a k e s u r e t h e
magnets are aligned
to the metal plates
on the print head's
stepper motor.
2
