Software Interface

Main Menu
Status Bar
Display the statsu
of printer and
software.
1 2 3 4
1. Load:Load a model.
2. Save:Save the model into .UP3, a propritory 3D model file for UP printers.
3. Unload:Unload the selected model.
4. Print:Print the current print plate.
5. About:Display software version, printer model, firmware version and etc.
6. View Perspective: A variety of pre-set of perspective.
7. Adjustments:Move, Rotate, Scale.
8. Set the value of adjustments.
9. Set the orientation of ajustments.
10. Place: Place the model to the center of the print plate. If more than one model
exist software will optimize their positions and distance to each other.
11. Stop: If connected to printer, click this will stop the print.(cannot be resumed)
5 6 7
17
Quick functional Buttons
Print Plate
- left mouse click and hold, moving
mouse to adjust camera angle.
- Right mouse click and hold, moving
mouse to move print plate.
-Mouse wheel could scale the print
plate view.
- The print plate size depend on
the printer model connected to
computer.
8 9
10 11
