PANEL DESCRIPTION

I Panel description

q POWER SWITCH [POWER]
Push to toggle the transceiver power ON and OFF.
w VOLUME CONTROL [VOL]
Adjusts the audio level. (p. 8)
e SQUELCH CONTROL [SQL]
Sets the squelch threshold level. (p. 8)
2
r TRANSMIT POWER SWITCH [HI/LO]
➥ Toggles high and low power when pushed. (p. 8)
• Some channels are set to low power only.
➥ While pushing this switch, other switches perform sec-
ondary functions.
t CHANNEL SELECTOR [CHANNEL]
➥ Rotate [CHANNEL] to select the operating channels, set
mode contents, etc. (p. 8)
