This Quick Start Guide will guide you how to install and configure the TeleEye MX151E-HD Network
Camera for remote video monitoring.

1. Camera Installation

After mounting the camera on the wall or ceiling, connect the Ethernet cable to the
Step 1
LAN adapter. If PoE is not available, connect the 12VDC power supply to the power cable.
[Reference] Please refer to the section 2 for connecting the cable to RJ45 plug.
Power Cable (12V DC)
12V DC Power Adapter
Step 2
Start sureSIGHT or a web browser to start a remote video monitoring in order to adjust
the camera.
[Reference] Please refer to the following sections to understand how to start video monitoring.
Step 3
Loosen the bolts to adjust the vertical angle and rotational view of the camera
Rotational View
Vertical Angle

Quick Start Guide

TeleEye MX151E-HD Network Camera
(Optional)
Alarm Cable
Ethernet Cable
Network switch / Router
1

Advertisement

loading

Related Manuals for TeleEye MX151E-HD

Summary of Contents for TeleEye MX151E-HD

  • Page 1: Quick Start Guide

    Quick Start Guide TeleEye MX151E-HD Network Camera This Quick Start Guide will guide you how to install and configure the TeleEye MX151E-HD Network Camera for remote video monitoring. 1. Camera Installation After mounting the camera on the wall or ceiling, connect the Ethernet cable to the Step 1 LAN adapter.

  • Page 2: Default Username And Password

    2. RJ45 Wiring Step 1 Make sure whether Type A or Type B wiring scheme is used for the Ethernet cable (Type B is more common). Step 2 The two colour codes indicated on the plug represent the wiring scheme for Type A and Type B cables.

  • Page 3: Ip Setup Utility

    4. IP Setup Utility Step 1 After installing sureSIGHT and turning on the Network Camera, select “Run TeleEye IP Setup Utility” from the windows start menu. Step 2 Search the target camera by its serial number, highlight the corresponding row from the list on the left side of the window to select it.

  • Page 4: Live Monitoring With Suresight

    6. Live Monitoring with sureSIGHT Step 1 After installing sureSIGHT and turning on the Network Camera, select “Run sureSIGHT Lite” from the windows start menu. Input the user name and password to log-in to the sureSIGHT. [Reference] Please refer to section 3 for the default user name and password. Step 2 Click the [ ] button on the top of the sureSIGHT.
  • Page 5 Step 4 [Next] Input the user name and the password. Then, click [Reference] Please refer to section 3 for the default user name and password. Step 5 [Details] You may click to change the site name and IP/sureLINK. After setting, click [Finish] Step 6 The video will be displayed on sureSIGHT by double clicking the site on the left panel.
