Page 1: Installation Guide
NF Series Network Camera NF610 Installation Guide... - Page 2 Notice: Signal Communications Limited reserves the right to make improvements to the product described in this manual at any time and without notice. This manual is copyrighted. All rights are reserved. This manual may not be copied, reproduced or translated in whole or part without prior consent from Signal Communications Limited.
- Page 3 FCC Statement on Class B WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 4: Table Of Contents
Table of Contents PREFACE BEFORE YOU BEGIN SECTION 1 INTRODUCTION • Features SECTION 2 INTERFACE DESCRIPTION • Model: NF610 SECTION 3 FIRST TIME SET UP OF THE NETWORK CAMERA • Network Camera Setup with IP Setup Utility • Network Camera Setup with Crossover Ethernet Cable •... - Page 5 SECTION 6 GENERAL TERMS DISCUSSION • Registration Checking • Video Mode • Built-in Web Server • Site Monitoring Method SECTION A APPENDIX • IP Address Setup for Window 98/ME • IP Address Setup for Window NT/2000/XP • Router Configuration SECTION B SPECIFICATIONS •...
-
Page 6: Before You Begin
Tele III+ Network Camera Installation Guide Page 1 PREFACE BEFORE YOU BEGIN Modification of the Power Adapter The connector of the power adapter might require some modifications before connecting it to the Network Camera. 1. Use a cutting tool to cut off the connector of the adapter 2. - Page 7 Tele III+ Network Camera Installation Guide Page 2 Repositioning of the Mounting Plate At the bottom of the Network Camera is a mounting plate. The mounting plate can also be removed and re-attached to the top of the Network Camera. The following is the procedure for repositioning the mounting plate from the bottom to the top of the Network Camera.
- Page 8 Tele III+ Network Camera Installation Guide Page 3 4. Re-secure the screws just removed to position 1 and 2 at the bottom of the Network Camera. This is to prevent the dismantling of the camera. 5. Remove the screws in position 5 and 6. 6.
-
Page 9: Introduction
Tele III+ Network Camera Installation Guide Page 4 SECTION INTRODUCTION Tele Tele III+ III+ Network Camera NF 610 is a brand new member of the Network CCTV family. It combined the power of high performance imaging technology and swift video transmission into a single module. With the built-in web server, remote video surveillance can readily be conducted with standard web browsers over the Internet or LAN. -
Page 10: Features
Tele III+ Network Camera Installation Guide Page 5 Features • 1/3” colour CCD • Illumination 1 Lux • Back light compensation • Flexible connections – Internet, LAN, ADSL and cable modem • Real time video transmission up to 30 fps over LAN for NTSC; up to 25 fps over LAN for PAL •... -
Page 11: Interface Description
Tele III+ Network Camera Installation Guide Page 6 SECTION INTERFACE DESCRIPTION Model: NF610 Tele Network Camera NF610 is shown below: III+ The rear panel of the Functional Description of NF610 Collision & Link LED Status COL LED: when on, indicates that collision is occurring on the network Tele III+ LINK LED: when on, indicates that... - Page 12 Tele III+ Network Camera Installation Guide Page 7 Signal PIN for alarm device (NC / NO) Common GROUND Dry Contact P2 P1 Dry Contact Power LED PWR LED: when on, indicates that the Network Camera has been power up successfully VIDEO OUT Connector Standard BNC connector for color video A composite video signal should be supplied from this connector...
-
Page 13: First Time Setup Of The Network Camera
Tele III+ Network Camera Installation Guide Page 8 SECTION FIRST TIME SETUP OF THE NETWORK CAMERA Before installing the Network Camera, its IP address must be set so that an Ethernet connection can be established to the Network Camera from a computer. In order to do this, either the IP address of the Network Camera or the IP address of the PC should be modified. - Page 14 Tele III+ Network Camera Installation Guide Page 9 Step 4: Select “NF” and enter Model No. (e.g. NF-610). Step 5: Enter the Network Camera Serial Number and Registration Code to the fields provided. Step 6: Insert a new, valid IP address of your desire to the provided field (e.g. 192.168.0.3). Step 7: Click on Set Transmitter IP button to set the Network Camera to the new IP address.
-
Page 15: Network Camera Setup With Crossover Ethernet Cable
Tele III+ Network Camera Installation Guide Page 10 Network Camera Setup with Crossover Ethernet Cable Your computer is required to change the IP address (e.g. 192.168.0.3). Please refer to Section A Appendix for a detailed descriptions for IP configuration on different operating systems. - Page 16 Tele III+ Network Camera Installation Guide Page 11 Step 2: You can change the connection, sureLINK, transmitter properties and camera control settings. You can reload the configuration by clicking Reload button. Click on Save & Exit button to save the changes. The description of each setting type is listed below: Setting Type Description...
-
Page 17: System Configuration And Installation
Tele III+ Network Camera Installation Guide Page 12 SECTION SYSTEM CONFIGURATION AND INSTALLATION This section will discuss how to setup the Network Camera and modify its settings in details. Installations of the Network Camera with different types of network will also be discussed. Specifically, installations with the following types of network will be discussed. - Page 18 Tele III+ Network Camera Installation Guide Page 13 RJ-45 Network Cable It is a shielded, straight-through RJ-45 network cable. The cable will connect Tele III+ Network Camera to the hub of the LAN for typical application. Crossover Network Cable Used to connect between a router and PC or the Network Camera Software Web-browser A standard web-browser such as IE, and Netscape…etc.
-
Page 19: General Configuration Of Network Camera
Tele III+ Network Camera Installation Guide Page 14 General Configuration of Network Camera After you prepared all the things discussed in previous section, you should be ready to configure the Network Camera. Note: Make sure the computer in use is capable of connecting to the Internet or the Local Area Network (LAN). - Page 20 Tele III+ Network Camera Installation Guide Page 15 The Network Camera’s web-based configuration should already be displayed in your web- browser. It should be similar to the captured screen shown below. Please enter the default administrator password “000000” to login. System Configuration and Installation...
- Page 21 Tele III+ Network Camera Installation Guide Page 16 There are many settings to be configured, such as Video Mode, Gateway, DNS…etc. The camera features can also be configured now. For users who have little knowledge in camera settings, it is advised that users read the section in camera features before making any changes.
-
Page 22: A1. For Internal Lan Access
Tele III+ Network Camera Installation Guide Page 17 A1. For Internal LAN Access Step 1: To continue, configure the Registration Checking and Video Mode settings. Step 2: You can Enable the Built-in Web Server so that you can see video through web browser Step 3: Ensure all settings are correct, then press the Save and Exit button Network Camera Installation RJ-45 Network... -
Page 23: A2. For Broadband Internet Connection With Static Ip
Tele III+ Network Camera Installation Guide Page 18 Tele Step 6: You may now use the web-based graphical user interface or the Eye III+ Reception Software to connect to the Network Camera. For the instructions of using the software, Tele please refer to the Eye III+ Reception Software User Guide. -
Page 24: Normal Operations Of The Network Camera
Web Server feature when configuring the Network Camera. For details please read Network Camera Configuration. In web browser, you can enter your registered sureLINK address (e.g. http://www.network.camera.teleeye.net/) or IP address with port number (e.g. http://192.168.0.3:1024/) to connect your Network Camera. - Page 25 Tele III+ Network Camera Installation Guide Page 20 Step 4: A window should appear. Please enter the password. The default password is 000000. The Tele location name and the password can both be changed with the Eye III+ Reception Software, WRS3-AD.
- Page 26 Tele III+ Network Camera Installation Guide Page 21 The main screen is where most actions take place. Location Name Exit Button Image Quality Clear Alarm Button Maximize Button Switch Control This web-based approach is the simplest way to connect with Network Camera. No other special software is required;...
-
Page 27: General Terms Discussion
No additional procedures or settings are needed and you can just enter your site address (e.g. http://www.hkoffice.teleeye.teleeye.net) at the web browser and view the site immediately. To see how to use this, please read section 5. -
Page 28: Site Monitoring Method
Tele III+ Network Camera Installation Guide Page 23 Site Monitoring Method There are mainly three methods to link up with the Network Camera to see videos: TCP/IP in LAN TCP/IP on the Internet using Broadband and Internet Router TCP/IP on the Internet using Broadband with Dial-up Software You have to choose one of the System Configuration Methods in earlier section to Tele Eye III+ configure... -
Page 29: Appendix
Tele III+ Network Camera Installation Guide Page 24 SECTION APPENDIX IP Address Setup for Windows 98/ME The follow procedures will set your Ethernet Card IP address manually for your local LAN purpose. Note that these procedures will NOT affect your PC to get on the Internet. If you discover that you cannot be able to access on the Internet after applying the settings, you have to undo the settings or re-install the software provided by your ISP and retry the steps again. - Page 30 Tele III+ Network Camera Installation Guide Page 25 Two of them are very important for setup. One of them is used for your local intranet (the field may contain the name of your Ethernet card), the other one is used for your broadband Internet connection.
- Page 31 Tele III+ Network Camera Installation Guide Page 26 Step 7: Select your Ethernet card name on the field, you will see a IP address on the field. Ensure that that is the same as you have set before (i.e. 192.168.0.3). If it is not so, please repeat step 12. Click OK to close the program.
-
Page 32: Ip Address Setup For Window Nt/2000/Xp
Tele III+ Network Camera Installation Guide Page 27 IP Address Setup for Windows NT/2000/XP The follow procedures will set your Ethernet Card IP address manually for your local LAN purpose. Note that these procedures will NOT affect your PC to get on the Internet. If you discover that you cannot be able to access to the Internet after applying the settings, you have to undo the settings or re-install the software provided by your ISP and retry the steps again. -
Page 33: Router Configuration
6.1 Advanced Internet Features → Virtual Servers (Define servers on your LAN, so Internet users can access them)→ E.3 User-defined Virtual Servers Suggested Data for router: Name TeleEye IP Address 192.168.0.2 (Your Network Camera IP address) Protocol Internal Port No. -
Page 34: Specifications
Tele III+ Network Camera Installation Guide Page 29 SECTION SPECIFICATIONS MODEL NF610 IMAGE SENSOR Type 1/3" CCD, 16M colour, interlace Minimum Illumination 1.0 Lux at F/1.2 Electronic shutter (P): 1/50-1/100,000 second (N): 1/60-1/100,000 second on/off switchable Back Light Compensation on/off switchable White Balance automatic Resolution...
