11). Release the gearmotor by using the release key if necessary.
12). Fully open the gate and place the first piece of the rack on the pinion so that it projects from the axis of the pinion
by distance followed as
13). To keep the rack level with the pinion, mark the hole for fixing when the slot matches the axis of the pinion.
Repeat this operation for each fixing point
14). Keep 1~2 mm space as
gearmotor. Continually install the other pieces of the rack until the racks are sufficient for work.
Figure 21
15). After fixing the last piece, cut away the unnecessary parts of racks by a hacksaw if necessary.
16). Open and close the gate several times manually and make sure that the rack goes with the pinion smoothly
within a maximum tolerance of 5mm.
17). Fix the two limit switch brackets with the relative dowels as the
Slide the gate in the open position keeping at least 2~3 cm from the mechanical stop. And then slide the bracket
along the rack in the opening direction until the limit switch cuts-in. The brackets should be located at a sufficient
distance from mechanical stops in order to keep the gate from crashing.
Operate the same steps for the limit switch in the closed position.
E
18). For electrically connections of the various devices, please see
10
INSTRUCTIONS PL600/PL1000
Figure 14 Figure 15
or
Figure 21
Figure 22
between the rack and pinion so that the gate does not weigh on the
Figure 23
, which means, the space reserved for the limit switch brackets.
.
Figure 23
E part in
"4.1.1 Design of PL600/PL1000 control unit"
Figure 22
.
.
