- Page 1 PL500 24V DC MOTOR SLIDING GATE OPENERS FOR RESIDENTIAL USER MANUAL...
-
Page 2: Declaration Of Conformity
Declaration of Conformity Applicant: Powertech Automation Inc. Manufacturer: Timotion Technology Co., Ltd. Address: Shiyong Minying Industrial Zone, Hengli Town, DongGuan City, GuangDong, China Model: PL500, PR-1 1. Certificate of conformity of a product with the essential requirements art. 3.2 of the R&TTE Directive 1999/5/EC. - Page 3 P.11 4.5 PRB-1 External Receiver Box Data Sheet P.11 5. Additional Information P.12 5.1 Wire Connection of PH-1 Photocell (Safety Beam) P.12 5.2 Wire Connection and Setting Of PRB-1 External Reciever Box P.13 INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL...
- Page 4 If there is a failure that cannot be solved and is not mentioned in this manual, please contact qualified Keep all the components of PL500 system and this manual installation personnel. for further consultation. Do not use the gate-automated system before all the...
-
Page 5: Installation
3. Safety photo sensor 4. Flashing light 2.2 Description of Device a. Operation gear e. Release device b. Limit switch device f. Control panel c. 24Vdc motor g. Terminals of devices d. Back-up batteries (Optional) INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... -
Page 6: Dimension Of Device
2.3 Dimension of Device 2.4 Installation of Motor Gear and Gear Rack INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... -
Page 7: Checking For Installation
Step2. Insert the key and turn counterclockwise to unlock the device. Step3. Turn counter-clockwise of the bar to release the motor To restore the automation, simply reverse the above procedure. Step1. Step2. Step3. INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... - Page 8 If the LED display is in normal performing refer to “4.2.1”, you can control the gate by either transmitters or the button on the board: “UP”-clockwise moving, “SET”- stop and “DOWN”- Counterclockwise moving. PF-1 PF-1 PPB-1 PKS-1 PPB-1, PKS-1: LED1 Photocells LED2 Photocells LED3 RF Learn INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL...
-
Page 9: Transmitter Memorizing And Erasing Process
LED Display Programmable Functions LED Display Programmable Functions “N-L”: The PL500 system learning is not done. “LEA”: Enter learning mode and then wait for learning instructions. “RUN”: The PL500 system is in normal “ARN”: The system learning is in progress. -
Page 10: Programmable Function Settings
1. The factory setting is “FA-3”. FA-1 1 second Auto - Reverse when object impacted FA-2 3 seconds FA-3 Reverse to the end *Note: System learning/ starting midway speed is roughly 20% slower than normal operation. INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... -
Page 11: Testing And Checking
● Check the devices one by one (photocells, flashing light, key selector, etc.) and confirm the control unit recognizes each device. INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... - Page 12 LED1 will be on when the first pair of the photocells are activated. LED2 Photocells LED2 will be on when the second pair of the photocells are activated. LED3 RF Learning LED3 will be on when RF-learn button is pressed. INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL...
-
Page 13: Technical Characteristics
85mm * 60.5mm * 40.5mm 4.5 PRB-1 External Receiver Box Data Sheet Power Supply 12V ~ 24V ac/dc Radio Frequency 433.92Mhz Max. remote memorized 200pcs Dimensions 106mm* 53mm* 20mm (L*W*H) Output terminals Output 1 & Output 2 INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... -
Page 14: Additional Information
And use an extra wire to connect terminals 2 and 5 on the receiver as a bridge. Figure 4(2) Lens Beam Alignmnet N.C. Indicator N.O. Power Led Indicator DC (12~24V) Terminal Block Power Terminal Block DC (12~24V) Figure 4(3) INSTRUCTIONS PL500 SLIDING GATE OPENER USER MANUAL... - Page 15 In order to use one 4 channel remote to operate with additional device besides the original gate automation system. Install a receiver box to connect with the 2nd device (such as another Powertech Slider) or the 3rd device (Such as garage automation system) Original gate automation: Using Button A &...
- Page 16 Press and hold learn button on the receiver box Output 2 operation LED Light for 10 seconds. Single-gate Dual-gate operation operation for Powertech 5. 4 Channel Transmitter Operation for Powertech gate openers gate openers Please refer to figure 5.2.1 Output 1 operation 34100-095-B Powertech Automation Inc.
