MeRlin lcD at a Glance

take a few moments to familiarize yourself with the
components of your Merlin lcD:
1. Merlin LCD
2. LCD monitor arm
3. LCD Monitor
4. Power button
5. Size (Magnification) dial
6. Viewing Mode button
7. X-Y table
8. X-Y table locking lever
9. Light ON/OFF Switch
10. LCD Brightness Control Level
11. Recessed handles for carrying Merlin LCD
12. Merlin LCD 15V power supply transformer
13. Merlin Base & LCD Monitor "Y" Power Cord
optional accessories (sold separately):
14. Feature Kit Control Box (optional)
15. Extension VGA Cable (optional)
16. Foot Switch Pedal (optional)
(19", 22" or 24")
m lCd
erlin at a
G
lanCe
8
