tURninG on MeRlin lcD

#2
#1
Merlin lcD power Button
The Power button on your Merlin LCD is located on the far right of
the control panel (item #1 above).
• Press the Power button. Notice the green light will illuminate on the
Control Panel, indicating the power is ON (item #2 above).
• The screen should automatically come on in a few seconds.
If the green light does not illuminate or if an image does not
appear on the LCD monitor, please check the power supply
connections (review steps 2-4 on page 10 for details).
NOTE: If your Merlin LCD is plugged into a power strip/surge
protector (recommended), make sure its power switch is turned
on before attempting to turn on Merlin LCD. If the power strip/
surge protector comes with a circuit breaker, make sure the
circuit breaker has been reset before attempting to turn on Merlin
LCD.
