- Page 1 FLAT-TOP RANGE ARDOX S4, S6 Accessories CHEF 200 CHEF 220 CHEF 240 Installation and Operation Manual S/N: 095524/07 Valid from:. 01.06. 2009 Rev.: 3.0...
- Page 3 2.11.2010 Rev. 3.0 Dear Customer, Congratulations on deciding to choose our appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied customer like thou- sands of customers we have around the world. Please read this manual carefully.
- Page 4 2.11.2010 Rev. 3.0...
-
Page 5: Table Of Contents
2.11.2010 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 1 2. Safety ......................2 2.1 Safe use of the appliance ....................2 2.2 Disposal of the appliance .................... - Page 6 2.11.2010 Rev.
-
Page 7: General
2.11.2010 Rev. 3.0 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Safety
2.11.2010 Rev. 3.0 Safety 2. Safety 2.1 Safe use of the appliance Because the range is a heated appliance that has hot surfaces during normal use, the fol- lowing warnings and instructions must be followed in order to avoid burns: During long-time operation even the frame surrounding the flat top gets hot. -
Page 9: Functional Description
In addition to a single range, there are combinations of a range and an oven (Chef 220 or Chef 240) or a range and a proving cabinet (Chef 200). This manual covers the Ardox range, while Chef 220, Chef 240 and Chef 200 have their own manuals. - Page 10 2.11.2010 Rev. 3.0 Functional description Operating panel Front cooking zone Power regulator Symbol of cooking zone Pilot light, power on Rear cooking zone Pilot light, power on Symbol of cooking zone Power regulator...
-
Page 11: Operation Instructions
2.11.2010 Rev. 3.0 Operation instructions 4. Operation instructions 4.1 Before use There is a slight smell of metal and thermal insulation when the range is heated for the first time. This is completely normal and disappears by heating the range. Before using the range for the first time, heat it at maximum temperature until the smell disappears. -
Page 12: After Use
2.11.2010 Rev. 3.0 Operation instructions If there are longer interruptions in the electricity distribution, all power regulators of the range should be set to the 0 position. This should be done in order to prevent unexpected start-up of the range when the electricity distribution is restored. 4.3 After use 4.3.1 Cleaning Use of a hose or pressure washer to clean the range is forbidden. -
Page 13: Installation
2.11.2010 Rev. 3.0 Installation 5. Installation 5.1 General The installation of the appliance must be carried out in accordance with the manufactur- er’s instructions and in compliance with local rules and regulations. These instructions must be used together with the installation drawing. This appliance may be connected to the mains electricity by qualified persons only. -
Page 14: Electricity Connections
2.11.2010 Rev. 3.0 Installation 5.4 Electricity connections Should maintenance require the appliance to be tested before all the protective coverings are in place, please be particularly careful of the moving parts inside the casing as well as of live parts. To facilitate future maintenance and to increase safety, install a separate disconnection switch for the range in the immediate vicinity of the appliance. -
Page 15: Troubleshooting
2.11.2010 Rev. 3.0 Troubleshooting 6. Troubleshooting If the appliance fails to work, check to ensure that • it has been used according to the instructions • all removable parts are in place • the main power switch (usually on a wall or in the immediate vicinity of the appli- ance) is in the ON position •... - Page 16 2.11.2010 Rev. 3.0 Troubleshooting...
- Page 17 2.11.2010 Rev. 3.0 Technical specifications 8. Technical specifications Main and control circuit T02113 A3 Main and control circuit T02114 A3 Main and control circuit T02115 A3 Main and control circuit T02116 A3 Main and control circuit T02117 A3 Main and control circuit T02118 A3 Main and control circuit T02127 A3 Main and control circuit T02128 A3 Main and control circuit T02129 A3...
- Page 18 Main and control circuit T02113 A3...
- Page 19 Main and control circuit T02114 A3...
- Page 20 Main and control circuit T02115 A3...
- Page 21 Main and control circuit T02116 A3...
- Page 22 Main and control circuit T02117 A3...
- Page 23 Main and control circuit T02118 A3...
- Page 24 Main and control circuit T02127 A3...
- Page 25 Main and control circuit T02128 A3...
- Page 26 Main and control circuit T02129 A3...
-
Page 27: Technical Specifications
Installation drawing T02018 B3... - Page 28 Installation drawing T02019 B3...
- Page 29 Installation drawing T02020 B3...
- Page 30 Installation drawing T02021 B3...
- Page 31 Installation drawing T02206 A3...
- Page 32 Installation drawing T02207 A3...
- Page 33 Accessories I,J,K,L,M Sous-shelves, height adjustable stand, oven, cabinet, drawer, kettle supports, guard rail S=ARDOX S 4=4, 6=6 200=CHEF 200, 220=CHEF 220, 240=CHEF 240 A=3/N/PE∼400/230V 50Hz, G=3/N/PE∼415/240V 50Hz, H=3/PE∼230V 50Hz, I=3/PE∼220V 60Hz, J=3/PE∼380 50Hz, K=3/PE∼400V 50Hz, L=3/PE∼415V 50Hz, M=3/PE∼440V 60Hz...
