  • Page 1 FLAT-TOP RANGE ARDOX S2, S4, S6, Tabletop, Drop-In Accessories CHEF 200, CHEF 220, CHEF 240, height adjustment, cupboard Installation and Operation Manual Original instructions Valid from 01.08.2011 Rev.: 5.0 (17.4.2019) 4210016, 4210023, 4210143, 4210048, 4210168, 4210104, 4210111, 4210129, 4210136, 3752018, 3752015, 3752019, 3752017 ,...
  • Page 2 Rev. 5.0 (from 01.08.2011) Metos ARDOX S CAUTION: Read the instructions before using the machine. Manufacturer: Metos AS Saha tee 18, Loo 74201 Harju maakond www.metos.ee...

  • Page 3: Table Of Contents

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S CONTENTS General ...............................4 1.1. Symbols used in the manual ........................4 1.2. Symbols used on the appliance ........................4 1.3. Checking the relationship of the appliance and the manual ...............4 Safety .................................5 2.1. Safe use of the appliance ..........................5 2.2.

  • Page 4: General

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S General Carefully read the instructions in this manual as they contain important information regarding proper, effi cient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance.

  • Page 5: Safety

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Safety 2.1. Safe use of the appliance Because the range is a heated appliance that has hot surfaces during normal use, the following warnings and instructions must be followed in order to avoid burns: •...

  • Page 6: Functional Description

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Functional description 3.1. Application of the appliance The Ardox S solid fl at top cooking units are intended for cooking of food directly on the hot surface of the solid fl at top and also for preparing different kind of food staff using cookware.
  • Page 7 Rev. 5.0 (from 01.08.2011) Metos ARDOX S Control panel, Ardox S Tabletop Appliance is equipped with removable grease box. (1). Left cooking zone 2. Pilot light, power on 3. Power regulator Right cooking zone 4. Power regulator 5. Pilot light, power on...

  • Page 8: Operation Instructions

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Operation instructions 4.1. Before use There is a slight smell of metal and thermal insulation when the range is heated for the fi rst time. This is completely normal and disappears by heating the range. Before using the range for the fi rst time, heat it at maximum temperature until the smell disappears.

  • Page 9: Height Adjustable Stand

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Applies to the Tabletop model: Make sure that the overfl ow grease box is in place during cooking. Otherwise, grease, oil or liquids may leak inside the device. Check the overfl ow vessel from time to time and empty if necessary.

  • Page 10: Service

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Sugar and mixes containing much sugar must be removed immediately, because later removing will be laborious. A clean cooking top ensures effi cient heat transfer to the cookware. Cooking is then fast and the operating life of the heating elements is extended.

  • Page 11: Installation

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Installation 5.1. General The installation of the appliance must be carried out in accordance with the manufacturer’s instructions and in compliance with local rules and regulations. These instructions must be used together with the installation drawing.

  • Page 12: Positioning The Ardox S Drop-In Range

    Max. recommended thickness of table top ( external stainless steel surface+ plywood underneath) 30mm. Dimensions of drop-in hole in table top must be as follows: • Ardox S2 Drop-in Solid Top Cooking Unit 453mmx753mm • Ardox S4 Drop-in Solid Top Cooking Unit 753mmx753mm Please refer to the installation drawings and other drawings in chapter “Technical specifi...

  • Page 13: Height Adjustable Stand

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Ardox S2 Solid Top Cooking Unit The supply cable inlet is in the back right-hand corner of the range and the connection point inside the range. The top deck needs to be opened to connect the range to the mains. Raise the deck up.

  • Page 14: Test-Run

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S 5.5. Test-run Please read the safety and operation instructions as well as the functional description of the appliance before testing the range. Test the range once it has been connected to the mains electricity.

  • Page 15: Troubleshooting

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Troubleshooting If the appliance fails to work, check to ensure thata • it has been used according to the instructions • all removable parts are in place • the main power switch (usually on a wall or in the immediate vicinity of the appliance) is in the ON position •...

  • Page 16: Technical Specifi Cations

    Rev. 5.0 (from 01.08.2011) Metos ARDOX S Technical specifi cations • Installation drawings • Technical specifi cations...
  • Page 29 Rev. 5.0 (from 01.08.2011) Metos ARDOX S Item Type Accessory Voltage Specifi cation External dimensions WxDxH Tabletop 804x530x190 External dimensions WxDxH 500 x 800 x 900 External dimensions WxDxH 800 x 800 x 900 mm External dimensions WxDxH 1200 x 800 x 900 mm...
  • Page 30 Rev. 5.0 (from 01.08.2011) Metos ARDOX S Item Type Accessory Voltage Specifi cation Package dimensions WxDxH Tabletop 960x600x400 Package dimensions WxDxH Table model 560 x 920 x 400 mm Package dimensions WxDxH Height adj. stand 560 x 920 x 1050 mm...
  • Page 31 Rev. 5.0 (from 01.08.2011) Metos ARDOX S...
