CONVECTION OVEN
CHEF 240
Installation and Operation Manual
Translation of the original documentation
S/N: 095323/02
Valid from: 01.06.2009
Rev. 4.0
(9.1.2023)
3751956, 3751957, 3751958, 3751960, 3751978, 3752953

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHEF 240 and is the answer not in the manual?

Questions and answers

Related Manuals for Metos CHEF 240

Summary of Contents for Metos CHEF 240

  • Page 1 CONVECTION OVEN CHEF 240 Installation and Operation Manual Translation of the original documentation S/N: 095323/02 Valid from: 01.06.2009 Rev. 4.0 (9.1.2023) 3751956, 3751957, 3751958, 3751960, 3751978, 3752953...

  • Page 2: Table Of Contents

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN General ...............................3 1.1. Symbols used in the manual ................................3 1.2. Symbols used on the appliance ...............................3 1.3. Checking the relationship of the appliance and the manual ......................3 Safety................................4 2.1. Safe use of the appliance ................................4 2.1.1.

  • Page 3: General

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN General Carefully read the instructions in this manual as they contain important information regarding proper, ef- ficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance.

  • Page 4: Safety

    One or two convection ovens can also be replaced by a Chef 220 roasting- baking oven or a Chef 200 proving cabinet. This manual covers the Chef 240 convection ovens, while Chef 220 and Chef 200 have their own manu- als.

  • Page 5: Control Panel Switches

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 3.3.1. Control panel switches Control panel switches Chef 240 1. Steam exhaust valve. The steam exhaust valve can be used to remove excess steam and moisture from inside the oven. 2. Thermostat lamp. The orange lamp is on when the heating elements are on.

  • Page 6: Operation Instructions

    STOP or the cooking plates. In unclear cases contact our technical support: technical.support@metos.com There is a slight smell of metal and thermal insulation when the oven is heated for the first time. This is completely normal and disappears by heating the oven. Before using the oven for the first time, heat it to a temperature of +250ºC until the smell disappears.

  • Page 7: Operation Procedures

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 4.2. Operation procedures 4.2.1. Before cooking, The oven must be preheated to cooking temperature before actual cooking begins. This is to heat the whole oven to the correct temperature so as to ensure the best possible cooking results.

  • Page 8: Moistening Function

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN In the event of uneven cooking check that • the oven has been installed horizontally • the oven has been preheated as instructed • the cooking temperature is correct • the cooking pan is correct •...

  • Page 9: Use Of The Moistening Function

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 4.2.6. Use of the moistening function Switch the moistening function on by turning the switch in a clockwise direction (see Figure “Control panel switches”). If needed, the factory setting of the moistening device can be adjusted by authorised service personnel.

  • Page 10: After Use

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 4.3. After use 4.3.1. Cleaning Use of a hose or pressure washer to clean the appliance is forbidden. STOP Before cleaning the oven, please remember that it remains hot for a long time after use.

  • Page 11: How To Change The Oven Bulb

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Cleaning of external surfaces of the door The external glass of the door can be opened for cleaning. Unscrew the two screws shown in the picture and turn the external glass carefully downward until it stays fully open. Spray diluted detergent solution onto the door’s metal surfaces between the glasses and onto the glass surfaces.

  • Page 12: Installation

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation 5.1. General Please read these instructions carefully as they contain important information regarding installation. The installation of this appliance must be carried out in accordance with the manufacturer’s instructions and in compliance with local rules and regulations. These instructions must be used together with the installation drawings.

  • Page 13: Installation Of A Chef Oven Group

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 5.2.2. Installation of a Chef oven group The appliances can be assembled to form combinations of two or three units by stacking them on top of each other. The stand height for two units is 660 mm and for three units 200 mm. For assembly of the oven group a special spare parts kit is necessary.

  • Page 14: Electrical Connections

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 5.4. Electrical connections Should maintenance require the appliance to be tested before all the protective coverings are in place, please be particularly careful of the moving parts inside the casing as well as of live parts.

  • Page 15: Test-Run

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN 5.8. Test-run Please read the safety and operation instructions as well as the functional description before testing the oven. As for other appliances possibly included in the baking station, see separate manuals.

  • Page 16: Technical Specifications

    9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Technical specifications Main and control circuit T04571D1 Main and control circuit T04571D2 Main and control circuit T04572B Main and control circuit T04573D Connection diagram T01702B Connection diagram T01916F Connection diagram T03768E Connection diagram T01703D...
  • Page 17 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Main and control circuit T04571D1...
  • Page 18 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Main and control circuit T04571D2...
  • Page 19 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Main and control circuit T04572B...
  • Page 20 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Main and control circuit T04573D...
  • Page 21 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Connection diagram T01702B...
  • Page 22 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Connection diagram T01916F...
  • Page 23 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Connection diagram T03768E...
  • Page 24 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Connection diagram T01703D...
  • Page 25 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01570C3...
  • Page 26 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01587C3...
  • Page 27 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01590D3...
  • Page 28 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01874D3...
  • Page 29 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01591D3...
  • Page 30 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01592D3...
  • Page 31 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Installation drawing T01879D3...
  • Page 32 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN Määre Malli Arvo Overall dimensions WxDxH, table model oven 800x900x460(+20) mm Overall dimensions WxDxH, oven with stand 800x900x1360 mm Overall dimensions WxDxH, two ovens with stand 800x900x1600 mm Overall dimensions WxDxH, three ovens with stand...
  • Page 33 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN...
  • Page 34 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN...
  • Page 35 9.1.2023 Rev. 4.0 METOS CHEF 240 -CONVECTION OVEN...
  • Page 36 Metos Oy Ab Ahjonkaarre FI-04220 Kerava, Finland tel. +358 204 3913 www.metos.com...
