R
OUTES
Routes link two or more waypoints together to create a path for navigation. A route represents your intended navigation and shows
the shortest path from each data point to the next. The distance between each waypoint is a route leg. You can save 47 routes (with
50 waypoints each) to the control head.
WARNING! You should always be aware of your surroundings and watch for any potential obstacles.
Create a Route and Start Navigation
Use the instructions in this section to connect waypoints and start navigation immediately. To create a route from the Waypoint
Management dialog box, see Manage your Navigation Data.
1. Use the Cursor Control key to move the cursor to a waypoint or position on the chart.
2. Press the GOTO key.
3. Repeat steps 1 and 2 to add more waypoints to the route.
2nd waypoint
course
projection
line
1st waypoint
Creating and Navigating a Route
Move the Cursor
121
Start Navigation
route leg
route start
point
current
track
north up
indicator
chart orientation

Routes
