- Page 1 Ishida 3000 Series Scales and Printers Ethernet Configuration Manual 69867...
-
Page 2: Table Of Contents
Private IP Networks and the Internet ..........8 Ishida 3000 Series Ethernet Option Limited Warranty ................9 Copyright © 2001 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America. Specifications subject to change without notice. -
Page 3: About This Manual
Rice Lake Weighing Systems distributor site at option in Ishida 3000 Series scales and printers. www.ishidaretail.com Introduction If the ethernet option is ordered at the time the scale is •... -
Page 4: Ethernet Installation
Figure 1-7. Apply Ethernet Address Sticker 7. Snap power cord pins back into connector. Refer to Figure 1-4 for correct orientation. 8. Assemble ethernet board and DB-25 board as pictured below. (See Figure 1-6). 9. Attach to ethernet bracket. Ishida 3000 Series Ethernet Configuration Manual... -
Page 5: Configuring Ethernet Card
Configuring Ethernet Card Basic Parameters The following section covers the configuration procedure of the ethernet card for the Ishida 3000 To change the basic parameters, press “0”. The Series. following values can be set/changed: Assigning an IP Address to your IP Address The IP address must be set to a unique value in your Ishida Scale... -
Page 6: Parameters
Netmask: Number of Bits for Host Part UDP protocol” in “TCP/IP Settings” in the ScaleLink (0=default) (00) Pro (version 2.1 or later) under <Setup><Comms Change Telnet config password (N) N (ID-EnQ)><TCP/IP link>. Baudrate (38400) I/F Mode (78)? Flow (00)? Ishida 3000 Series Ethernet Configuration Manual... -
Page 7: Ending The Telnet Session
Port No (03001)? Channel 1 ***************** ***************** ConnectMode (C2) ?0c Baudrate 38400, I/F Mode 78, Flow 00 Datagram Type (00) ?01 Port 03001 Remote IP Address: (000) .(000) .(000) .(000) Datagram Type 01 Remote Port (00000)? Pack Cntrl: 10 Pack Cntrl (00) ?10 SendChars 06 04 SendChar 1 (06)? Remote IP Adr: ---none---, Port 00000... -
Page 8: Replacement Parts List
68422 Nylon tube OD 1/8, board spacer, .5 length, ID .064, RAF, 0 n 0 64839 RS232 TTL level converter 64853 10 Base-T Ethernet server 15773 Retainer screws and clips Table 3-1. Replacement Parts Ishida 3000 Series Ethernet Configuration Manual... -
Page 9: Appendix
Appendix Broadcast Address The following section covers IP addressing and netmasks for Ishida 3000 Series scales and printers. The address with the host portion bits set to “1” is the broadcast address, meaning “for every station”. IP Addressing Network and broadcast addresses must not be used as An IP address is a 32-bit value, divided into four a host address (i.e. -
Page 10: Private Ip Networks And The Internet
255.255.255.192 numbers. If you have any questions about IP assignment consult your Network Administrator. 255.255.255.128 Class A: 10.x.x.x 255.255.255.0 Class B: 172.16.x.x 255.255.254.0 Class C: 192.168.0.x 255.255.252.0 255.255.248.0 255.128.0.0 255.0.0.0 Table 4-2. Netmask Examples Ishida 3000 Series Ethernet Configuration Manual... -
Page 11: Ishida 3000 Series Ethernet Option Limited Warranty
Ishida 3000 Series Ethernet Option Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems manufactured and sold by RLWS and properly installed by an authorized RLWS Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for one year.
