- Page 1 USER MANUAL IP day/night camera with motor zoom lens in weather-proof housing Model SNC-565IR/W Version 1.2 /0610/engl/A6...
- Page 2 Please follow all instructions and observe the warnings contained in this manual. Please contact your local dealer or use the SANTEC Service Hotline if you have any questions or if you wish to claim for a service or warranty.
-
Page 3: Table Of Contents
User manual SNC-565IR/W Table of contents Safety precautions Safety instructions About this user manual Items included in the delivery 1. Installation 1.1 Lens 1.2 Camera installation 1.3 Power supply 1.4 Camera housing 1.5 Adjustment of the analogue camera module 1.6 Sun shield installation 1.7 Safety note for IR-LEDs... - Page 4 User manual SNC-565IR/W 4.5 Network 4.5.1 IP-address 4.5.2 SNTP (time server for time synchronization) 4.5.3 FTP 4.5.4 SMTP 4.5.5 DDNS (dynamic domain name system) 4.5.6 Event protocol 4.6 Video settings 4.6.1 Encoding 4.6.2 Camera settings 4.7 Audio settings 4.8 Extended settings 4.8.1 Motion detection...
-
Page 5: Safety Precautions
User manual SNC-565IR/W Safety precautions Caution Description of symbols Danger: This symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to a person. -
Page 6: Safety Instructions
User manual SNC-565IR/W Safety instructions Before operating the appliance, please read this manual carefully and retain it for further reference. Before cleaning the appliance, it has to be switched off and unplugged from the power outlet. Wipe the appliance with a soft damp cloth. -
Page 7: About This User Manual
About this user manual This manual aims at assisting the user on how to operate camera SNC-565IR/W. This manual is subject to rigid quality control. However, no guarantee can be given that mistakes are not present. We reserve the right to make changes to the manual without prior notice. -
Page 8: Installation
User manual SNC-565IR/W 1. Installation (also see the pictures on the following pages) This camera is a day/night IP colour camera. You will find the technical data at the end of the manual. 1.1. Lens The camera is equipped with a motor zoom lens which can be controlled either via the network using the camera’s web interface or via the SanView software. -
Page 9: Sun Shield Installation
User manual SNC-565IR/W In order to navigate through the OSD menu, please use the arrow buttons. To confirm your selection, press the button. The SanView software also enables access to the camera OSD menu via the network. To call up the OSD menu, press the OSD button on the PTZ tab. -
Page 10: Camera Overview
User manual SNC-565IR/W 1.9 Camera overview Picture 1: Adjustments for service purposes DIP switch to set the reset button Baud rate and the ID video test joystick for auto focus button connector OSD control Picture 2: Attaching the sun shield... - Page 11 User manual SNC-565IR/W Picture 3: Connections Ethernet connection Voltage 12 V DC Audio input/output Alarm input/output _________________________________________________________________________________ - 11 -...
-
Page 12: Osd Menu
User manual SNC-565IR/W 2. OSD menu 2.1. Menu overview Cam Title White Balance AWC Set Manual Backlight Middle High Motion Det Focus Mode Zoom TRK Zoom Speed D-Zoom Disp Zoom Mag Zoom Pos Init Lens Init Exposure Brightness Iris Shutter... -
Page 13: General
User manual SNC-565IR/W 2.2. OSD menu: General All camera adjustments are done via an OSD menu. On the camera there is a mini-joystick. Press onto the joystick and a menu pops up in the video picture. You can now move the joystick left/right/up/down in order to get to the desired menu item. -
Page 14: White Bal
User manual SNC-565IR/W 5. Display the camera name on the screen. Move the cursor to „POS“ and press SET. By default, the camera name is displayed in the upper left corner of the screen. Use the 4 direction arrows to move the position of the camera name. Confirm the new position by pressing SET. -
Page 15: Backlight
User manual SNC-565IR/W INDOOR: For indoor applications of colour temperatures of 3000°K to 10500°K. AWC (Auto White Balance Control): Automatic white balance if you hold a white sheet of paper infront of the camera and press SET (sufficient light conditions required). -
Page 16: Motion Detection
User manual SNC-565IR/W 2.6. Motion detection The camera allows you to detect motions in four different areas. The note „MOTION DETECTION“ is displayed on the screen once a movement has been discovered. Hence a single person is able to efficiently monitor an area. The camera detects a motion by difference in contour, brightness and colour. -
Page 17: Focus
User manual SNC-565IR/W 2.7. Focus 1. Press SET to call up the main menu. Use the up/down buttons to select „FOCUS“. 2. Press SET to access the FOCUS sub-menu: MODE: Select the suitable zoom mode. Use the up/down buttons to select “MODE“. - Page 18 User manual SNC-565IR/W ONE PUSH: The focus automatically adapts to changing zooms. Select „ONE PUSH“ and then press SET to confirm. Increase or decrease the position of the optical zoom (ZOOM) or of the digital zoom (D-ZOOM) by using the direction arrows. You will see the changes on the screen.
- Page 19 User manual SNC-565IR/W D-ZOOM: Setting of 2x to 10x magnification. Use the up/down buttons to select „D- ZOOM“. Select option „ON“ and press SET. Use the left/right buttons to adjust the „ZOOM LIMIT. DISP ZOOM MAG: The current zoom magnification is displayed on the screen. Use the up/down buttons to select „DISP ZOOM MAG“.
-
Page 20: Exposure
User manual SNC-565IR/W LENS INIT: Initialisation of the lens (1x, WIDE). Use the up/down buttons to select “LENS INIT“ and press SET to confirm. END: Return to main menu. 2.8. Exposure 1. Press SET to call up the main menu. Use the up/down buttons to select „EXPOSURE“. - Page 21 User manual SNC-565IR/W AUTO: The aperture is automatically adjusted to the light conditions. MANUAL: Manual aperture setting. Use the lefr/right buttons to select „MANUAL“ and press SET. Increase or decrease the aperture value by using the left/right buttons. You will see the changes on the screen.
- Page 22 User manual SNC-565IR/W NOTE:If you change the AGC mode from „NORMAL“ to „HIGH“, the picture sensitivity and noise will increase. If you put the AGC mode to „OFF“, the SSNR setting will be blocked. SSNR (Super Noise Reduction):Use the up/down buttons to select „SSNR“. Use the left/right buttons to select the desired SSNR mode.
-
Page 23: Specialj
User manual SNC-565IR/W 2.9. SPECIAL 1. Press SET to call up the main menu. Use the up/down buttons to select „SPECIAL“. 2. Press SET to access the SPECIAL sub-menu.: USER PRESET: Use the up/down buttons to select „USER PRESET“. Use the left/right buttons to select „ON“. - Page 24 User manual SNC-565IR/W PRESET SAVE: Save the preset settings. PRESET CLEAR: Delete the preset settings. USER PRESET SETUP PRESET NO. NO.1 PRESET MODE PRESET SAVE PRESET CLEAR PRESET DEFINED END: Return to SPECIAL SETUP menu. USER PRESET SETUP PRESET NO.
- Page 25 User manual SNC-565IR/W PRIVACY: Privacy zones are not displayed. SPECIAL SETUP USER PRESET PRIVACY ON DAY/NIGHT COLOR SYNC COMM ADJ IMAGE ADJ PRIVACY SETUP GROUP SEL GROUP1 AREA SEL AREA1 AREA MODE MASK TONE BOTTOM...
- Page 26 User manual SNC-565IR/W DAY/NIGHT: In day/night mode, you can choose between COLOR, BW (black-white) and AUTO. SPECIAL SETUP USER PRESET PRIVACY DAY/NIGHT COLOR SYNC COMM ADJ IMAGE ADJ COLOR: colour mode BW: black-white mode AUTO 1, 2: The camera automatically detects the light conditions and goes into the respective mode.
- Page 27 User manual SNC-565IR/W COMM ADJ: Selection oft he communication protocol. Use the up/down buttons to select „COMMUNICATION“. SPECIAL SETUP USER PRESET PRIVACY DAY/NIGHT COLOR SYNC COMM ADJ IMAGE ADJ Press SET to access the COMMUNICATION sub-menu.
- Page 28 User manual SNC-565IR/W IMAGE ADJ: Adjustment of picture quality and special characteristics. FREEZE: Freeze image H-REV: Horizontal turn of screen view V-REV: Vertical turn of screen view SHARPNESS: By increasing the sharpness, the object’s contours become clearer. However, if the sharpness is set too high, noise may occur and the picture may get jittered.
-
Page 29: Ip Settings
User manual SNC-565IR/W 3. IP settings The SANTEC IP cameras come with the following default settings: IP-address 192.168.1.168 Subnet mask : 255.255.255.0 Gateway 0.0.0.0 DNS-server 0.0.0.0 User ID admin Password 9999 To retain the default settings, press the reset button. - Page 30 User manual SNC-565IR/W c. SanView software Every SANTEC IP camera comes with the SanView-Lite software. In order to change the network settings, open the device adjustment page via the context menu (also see brief instructions on SanView software). You will find the respective control elements on the network parameter tab. To copy the parameters, click on Apply.
-
Page 31: Web Interface
User manual SNC-565IR/W 4. Web interface 4.1. Calling-up the camera web interface Open the Microsoft Internet Explorer and start the connection of the network camera as follows: Click on the URL field. Type in the URL address of the network camera and press the ENTER key. You will then access the web interface of the camera. -
Page 32: Live-View
User manual SNC-565IR/W 4.2. Live-View Page for camera adjustments Page for Live-View Live-View with 50% resolution Live-View with defined resolution PTZ-control: tilt confirmation/ OSD menu PTZ speed: S = slow, F = fast Zoom in Zoom out... - Page 33 User manual SNC-565IR/W Start autoscan Digital output (relay) on Digital output (relay) off Audio on (camera -> web interface) Audio off (camera -> web interface) Audio on (web interface -> camera) Audio off (web interface -> camera) Storage location for snapshots and video sequences...
-
Page 34: Setting Overview
User manual SNC-565IR/W 4.3. Setting overview _________________________________________________________________________________ - 34 -... -
Page 35: System Settings
User manual SNC-565IR/W 4.4. System settings 4.4.1. Time / date Local time: The local time is the one as set in the camera. Desired time: You can change the time which is set in the camera as follows: o Set manually: Select the desired time and date from the drop-down list. -
Page 36: Time Stamp
User manual SNC-565IR/W 4.4.2. Time stamp Enable time stamp: The time stamp is displayed. Time stamp position: o UPPER LEFT o UPPER RIGHT o BOTTOM LEFT o BOTTOM RIGHT Time stamp format: o YY/MM/DD o MM/DD/YY o DD/MM/YY... -
Page 37: Language
User manual SNC-565IR/W User list: This list displays the user(s) and their respective authorisations. Delete user: Select a user from the list to be deleted and click this button. User name: Enter the user name here which is to be added or modified. -
Page 38: Update Firmware
User manual SNC-565IR/W 4.4.6. Update firmware This page displays information on the installed firmware version and the ActiveX components. Search: Select the firmware file from your PC. Update: Start the update process. Restart: Restart the camera. _________________________________________________________________________________... -
Page 39: Network
User manual SNC-565IR/W 4.5 Network 4.5.1 IP-address IP-address: Enter the 4-Byte IP-address (value from 0 to 255). Every network camera has to have its own IP-address which can be identified in the network. Netmask: Enter the 4-Byte subnet-mask (value from 0 to 255). By this, the netmask can be identified in which the network camera is located. -
Page 40: Sntp (Time Server For Time Synchronization)
User manual SNC-565IR/W 4.5.2. SNTP (time server for time synchronisation) SNTP server: IP-address of the SNTP server. Can be entered as 4-Byte IP-address or as domain name. Submit: Click here to apply the new network settings to the network camera. -
Page 41: Smtp
User manual SNC-565IR/W 4.5.4. SMTP If necessary, enable the option „My server requires authentication”. Account name: Account on e-mail server. Password: Password of account on e-mail server. Sender: This information is displayed as e-mail sender. SMTP server: IP-address of SMTP server. Can be entered as 4-Byte IP-address or as domain name. -
Page 42: Ddns (Dynamic Domain Name System)
User manual SNC-565IR/W 4.5.5. DDNS (dynamic domain name system) DDNS host name: IP-address of DDNS server. Can be entered as 4-Byte IP-address or as domain name. DDNS account: Account on DDNS server. DDNS password: Password of account on e-mail server. -
Page 43: Video Settings
User manual SNC-565IR/W 4.6 Video settings 4.6.1 Encoding Compression: Setting of the video streaming mode o Single MPEG4 o MPEG4 Half D1 o MPEG4 + MPEG4 o MPEG4 + JPEG: Pre-set mode. This mode is used in the SanView software. -
Page 44: Camera Settings
User manual SNC-565IR/W MPEG4_1 setting o Bit rate: 200 - 4000 Kbit/sec o Bild rate: 25 / 13 / 6 / 3 fps MPEG4_2 setting o Bitrate: 200 - 4000 Kbit/sec o Bildrate: 25 / 13 / 6 / 3 fps ... -
Page 45: Audio Settings
User manual SNC-565IR/W 4.7. Audio settings Audio: Set the audio mode to: o OFF: audio is turned off o one-way: audio only from camera to PC o two-way: audio in both directions Audio out volume: 0 - 4 ... -
Page 46: Extended Settings
User manual SNC-565IR/W 4.8. Extended settings 4.8.1. Motion detection Motion detection: Activation/deactivation of motion detection Sensitivity: Set the sensitivity level of the motion detection o Lowest o Low o Medium o High o Highest CCD reference: CCD reference (20 - 50) ... -
Page 47: Alarm Settings
User manual SNC-565IR/W 4.8.2. Alarm settings Alarm in (sensor): Activate/deactivate the alarm input o Active type “low”: This means 0 V. The camera will trigger an alarm if the alarm input has 0 V. To achieve 0 V at the alarm input, the contacts are closed. -
Page 48: Sd-Card
User manual SNC-565IR/W 4.8.3. SD-card 4.8.3.1 SD-card settings SD-card enable: Activate/deactivate the SD-card. SD-card rewrite: Activate/deactivate the rewriting of the SD-card. Format: The SD-card is being formatted. Submit: Click here to save the new SD-card settings. -
Page 49: Recording
User manual SNC-565IR/W 4.8.4. Recording 4.8.4.1 Recording settings On this page you can set the recording modes: o Schedule record – upload via FTP o Schedule record – save into SD-card o Alarm record – upload via FTP o Alarm record – save into SD-card o Alarm record –... -
Page 50: Recording Schedules
User manual SNC-565IR/W 4.8.4.2 Recording schedules You can set up to 7 schedules in the camera. Submit: Click here to save the new schedule settings. Remove all schedules: All existing schedules are deleted. _________________________________________________________________________________ - 50 -... -
Page 51: Technical Specifications
User manual SNC-565IR/W 5. Technical specifications Camera SNC-565IR/W Camera type Day/night IP compact camera Housing Weather-proof, IP-66 IR-LEDs 10x, range: up to 80 m * Split-glass technology Sensor 1/4" Interline Transfer CCD 540 TVL Day/night mode adjustment Auto, colour, black/white... - Page 52 Your local distributor: __________________________________________________________________________ www.santec-video.com...
