KIT CONTENTS: We have organized the parts as they come out of the box for
better identification during assembly. We recommend that you regroup the
parts in the same manner. This will ensure you have all of parts required before
you begin assembly.
AIR FRAME ASSEMBLIES
(2) Wing halves with ailerons
(1) Fuselage
(1) Horizontal stabilizer
with elevator halves
(1) Vertical stabilizer with rudder
NOSE GEAR
(1) Nose gear
(1) 65mm wheel
(1) Collar
(1) 3mm x 4mm screw
(1) Steering arm
MAIN GEAR
(1) Main gear aluminum
(2) 65mm wheel
(4) Collar
(3) 4mm x 20mm screw
(1) Set of axles
(3) 8mm washer
(3) 4mm washer

KIT CONTENTS

ELEVATOR CONTROL SYSTEM
(2) 1,7mm x 800mm metal rod
(2) Nylon control horn
(4) 2mm x 1,6mm screw
(2) Metal connector
(1) 1,7mm x 100mm metal rod
(2) Metal clevis
(1) Snap keeper
RUDDER CONTROL SYSTEM
(1) 1,7mm x 800mm metal rod
(1) Nylon control horn
(2) 2mm x 16mm screw
(1) Metal clevis
(1) Snap keeper
(1) 4mm x 20mm screw
(2) 8mm washer
(1) 4mm x 25mm screw
AILERON CONTROL SYSTEM
(2) M2 clevises
(2) Silicone
(2) Control horn
(2) 2mm x 16mm wood screw
(2) 1,7mm x 180mm metal pushrod
(8) 2mm x 10mm wood screw
1
DOMINO
ENGINE MOUNT
(4) 3mm x 20mm screw
(4) 3mm lock washer
THROTTLE CONTROL
SYSTEM
(2) Metal connector
(2) 4mm x 4mm screw
FUEL TANK
(1) Fuel tank
(1) Metal clunk
(1) Silicon tube
(1) Stopper
(1) Foam
MISCELLANEOUS ITEMS
(1) Wing joiner
(4) Screw
(4) Nylon plate
(1) Spinner
(1) Manual
