CanyCom CMX 224 Operator's Manual page 63

5
5321M-0506-020E
Oil Filler Cap
5332M-0506-030E
5332M-0506-040E
Maintenance
Upper Limit
Lower Limit
Drain Plug
5. Visually inspect oil level. Make sure oil level
is between upper and lower limits. If it is
below lower limit, add oil.
6. Visually inspect condition of oil. If it is too
dirty or viscosity is not normal, change oil.
7. Put dipstick back in place.
8. Close engine hood.
Filling
1. Open engine hood.
2. Remove oil filler cap.
3. Fill specified amount of correct oil into filler.
4. Check oil level. Make sure oil level is
between upper and lower limits.
5. Put oil filler cap back in place.
6. Close engine hood.
Changing
1. Have an appropriate oil drain pan.
2. Open engine hood.
3. Remove oil filler cap.
4. Remove drain plug to drain oil.
5. Put drain plug back in place.
6. Fill oil.
7. Check oil level and to make sure oil level is
appropriate.
8. Put oil filler cap back in place.
9. Close engine hood.
-54-
