AV Receiver
Owner's Manual
Be sure to read "Safety Brochure" (supplied booklet) before using this unit.
English for U.S.A.
1
En

Advertisement

Table of Contents

   Also See for Yamaha RX-A2010

   Related Manuals for Yamaha RX-A2010

   Summary of Contents for Yamaha RX-A2010

  • Page 1 AV Receiver Owner’s Manual Be sure to read “Safety Brochure” (supplied booklet) before using this unit. English for U.S.A.
  • Page 2: Table Of Contents

    CONTENTS Accessories ........... . . 5 7 Connecting the power cable .
  • Page 3 Playing back iPod music/videos ....... . . 70 Configuring various functions (Setup menu) ....106 Connecting an iPod .
  • Page 4 APPENDIX Frequently asked questions ........138 Troubleshooting .
  • Page 5: Accessories

    Accessories Operating range of the remote control Check that the following accessories are supplied with this product. • Aim the remote control directly at the remote control sensor on this unit during operation. ■ ■ Remote control Batteries (AAA, R03, UM-4) (x 4) Within 6 m (20 ft) 30°...
  • Page 6: Features

    FEATURES What you can do with this unit Supports 2 to 9 channel speaker system and up Ready for any kind of contents to 2 subwoofer connections. Allows you to enjoy iPod Network p.70 p.80 to p.83 favorite acoustic spaces in various styles. Bluetooth p.77 p.75...
  • Page 7: Full Of Useful Functions

    ● Full of useful functions! At time like this Creating stereoscopic sound fields (p.57) Connection of presence speakers enables to create a ● natural stereoscopic sound field in your room (CINEMA Connecting various devices (p.35) I want to connect a playback device using HDMI for video DSP 3D).
  • Page 8: Part Names And Functions

    Part names and functions Front panel NATURAL SOUND AV RECEIVER RX-A2010 MAIN ZONE PURE DIRECT INPUT VOLUME SCENE ON SCREEN OPTION TONE/BALANCE STRAIGHT INFO MEMORY PRESET MULTI ZONE PROGRAM CATEGORY TUNING/CH ENTER ZONE 2 ZONE 3 ZONE CONTROL RETURN DISPLAY...
  • Page 9 ■ Inside of the front panel cover SCENE ON SCREEN OPTION TONE/BALANCE STRAIGHT INFO MEMORY PRESET MULTI ZONE PROGRAM CATEGORY TUNING/CH ENTER ZONE 2 ZONE 3 ZONE CONTROL RETURN DISPLAY PHONES VIDEO AUX iPod/iPhone YPAO MIC SILENT CINEMA S VIDEO VIDEO AUDIO OPTICAL...
  • Page 10: Front Display (indicators)

    Front display (indicators) MUTE VOLUME STEREO TUNED PARTY ZONE ZONE ADAPTIVE OUT 1 OUT 2 R PR ENHANCER SLEEP SW2 SR HDMI Information display Speaker indicators Lights up during normal HDMI communication. Displays the current status (input name, sound mode name, Indicate speaker terminals from which signals are output.
  • Page 11: Rear Panel

    (p.64). DOCK jack HDMI (AV1~7) jacks ANTENNA jacks For connecting an optional Yamaha products such as iPod dock (p.71), iPod wireless system (p.71), and Bluetooth For connecting HDMI-compatible playback devices to input For connecting FM and AM antennas (p.39). receiver (p.75).
  • Page 12: Remote Control

    Remote control Remote control signal transmitter MODE Transmits infrared signals. Switches between stereo and monaural for FM radio reception. Switches the iPod operation modes (p.73). SOURCE RECEIVER SOURCE PRESET Turns on/off an external device. Selects a preset FM/AM radio station (p.60). SOURCE/RECEIVER Selects a preset SIRIUS Satellite Radio channel (p.66).
  • Page 13 ■ Inside of the remote control cover Sound mode keys Select a sound mode (p.54). SOURCE RECEIVER INFO Selects the information displayed on the front display (p.94). Numeric keys Enter numerical values such as radio frequencies. ZONE Switches the zones (main, Zone2 or Zone3) to operate with V-AUX the remote control (p.89).
  • Page 14: Setup

    SETUP General setup procedure Connecting speakers (p.15) Basic speaker configuration (p.16) Select the speaker layout and connect the speakers to this unit. Advanced speaker configuration (p.21) Apply bi-amp connections, channel expansion (using an external power amplifier) or multi-zone configurations to enhance the system. Connecting a TV (p.29) Connect a TV to this unit.
  • Page 15: Connecting Speakers

    2 3 4 5 6 7 8 Speaker connections Connecting speakers This unit has 9 built-in amplifiers. You can connect 2 to 11 speakers and up to 2 subwoofers (with built-in amplifier) to create the favorite acoustic space in your room. You can also apply bi-amp connections, channel expansion (using an external power amplifier) or multi-zone configurations to enhance your system (p.21).
  • Page 16: Basic Speaker Configuration

    2 3 4 5 6 7 8 Speaker connections Basic speaker configuration ■ Placing speakers in your room Depending on the number of speakers, place the speakers and subwoofer (with built-in amplifier) in your room. This section describes the representative speaker layout examples. ❑...
  • Page 17 2 3 4 5 6 7 8 Speaker connections ❑ 7.1 channel system (using front presence speakers) ❑ 5.1 channel system This speaker system uses the front presence speakers to produce a natural This speaker system creates Virtual Presence Speaker (VPS) using the front, center and stereoscopic sound field, and is suited for enjoying 5.1-channel contents.
  • Page 18 2 3 4 5 6 7 8 Speaker connections ■ Setting the speaker impedance This unit is configured for 8-ohm speakers at the factory. When connecting 6-ohm speakers, set the speaker impedance to “6 Ω MIN”. In this case, you can also use 4-ohm speakers as the front speakers.
  • Page 19 2 3 4 5 6 7 8 Speaker connections ■ Connecting speakers Cables necessary for connection (commercially available) Speaker cables (x the number of speakers) Connect the speakers placed in your room to this unit. – – Caution Audio pin cable (2 for connecting 2 subwoofers) •...
  • Page 20 2 3 4 5 6 7 8 Speaker connections ❑ Connecting speaker cables Speaker cables have two wires. One is for connecting the negative (-) terminal of the unit and the speaker, and the other is for the positive (+) terminal. If the wires are colored to prevent confusion, connect the black wire to the negative and the other wire to the positive.
  • Page 21: Advanced Speaker Configuration

    2 3 4 5 6 7 8 Speaker connections Advanced speaker configuration In addition to the basic speaker configuration (p.16), this unit also allows you to apply the following speaker configurations to enhance your system. Combining with an external Using the four internal Using the excess internal power amplifier (Hi-Fi amplifiers for front speakers to...
  • Page 22 2 3 4 5 6 7 8 Speaker connections ■ ❑ 7ch BI-AMP Available speaker configurations Bi-amp Main zone Output External power Multi-zone Power Amp Assign (p.109) Page channel Bi-amp amplifier (max) (required) 7ch BI-AMP Front +1 room 7ch +FRONT+1ZONE Front +2 rooms 5ch +FRONT+2ZONE...
  • Page 23 2 3 4 5 6 7 8 Speaker connections ❑ 7ch +FRONT+1ZONE ❑ 5ch +FRONT+2ZONE via external amp via external amp Zone2 Zone3 Main zone Main zone Zone3 Speaker Connect to Speaker Connect to FRONT (PRE OUT) via external power amplifier FRONT (PRE OUT) via external power amplifier CENTER CENTER...
  • Page 24 2 3 4 5 6 7 8 Speaker connections ❑ 7ch +1ZONE ❑ 9ch +1ZONE Zone2 Zone3 Main zone Main zone Speaker Connect to Speaker Connect to FRONT FRONT CENTER CENTER SURROUND SURROUND SURROUND BACK SURROUND BACK (not used) EXTRA SP1 (not used) (not used) SUBWOOFER 1~2...
  • Page 25 2 3 4 5 6 7 8 Speaker connections ❑ 7ch +2ZONE Zone2 Main zone Zone3 Speaker Connect to FRONT CENTER SURROUND SURROUND BACK (not used) (not used) SUBWOOFER 1~2 Zone2 speakers EXTRA SP1 Zone3 speakers EXTRA SP2 • When Zone3 output is enabled (p.89), the surround back speakers in the main zone do not output sound.
  • Page 26 2 3 4 5 6 7 8 Speaker connections ■ ■ Connecting front speakers that support bi-amp connections Connecting Zone2/3 speakers When using front speakers that support bi-amp connections, connect them to the When using Zone2/3 speakers, connect them to the EXTRA SP1~2 jacks. FRONT jacks and EXTRA SP1 jacks.
  • Page 27: Connecting An External Power Amplifier

    2 3 4 5 6 7 8 Speaker connections ■ Connecting an external power amplifier (Example) Connecting front speakers via an external power amplifier When using an external power amplifier to enhance speaker output, connect the input jacks of the power amplifier to the PRE OUT jacks of this unit. The same channel signals PRE OUT (FRONT) jacks are output from the PRE OUT jacks as from their corresponding SPEAKERS terminals.
  • Page 28: Input/output Jacks And Cables

    Input/output jacks and cables ■ ■ ■ Video/audio jacks Video jacks Audio jacks ❑ HDMI jacks ❑ COMPONENT VIDEO jacks ❑ OPTICAL jacks Transmit digital video and digital sound through a single Transmit video signals separated into three Transmit digital audio signals. Use a digital optical jack.
  • Page 29: Connecting A Tv

    3 4 5 6 7 8 TV connection Connecting a TV ■ Connect a TV to this unit so that videos input to this unit can be output to the TV. Connection method 1 (HDMI Control/ARC-compatible You can also enjoy playback of TV audio on this unit. The connection method varies depending on functions and video input jacks available Connect the TV to this unit with an HDMI cable.
  • Page 30 3 4 5 6 7 8 TV connection ❑ Necessary settings Configure the settings for HDMI Control. To use HDMI Control and ARC, you need to configure the following settings. For details on settings and operations of your TV, refer to the instruction manual of the TV. a Enable HDMI Control on the TV and playback devices (HDMI Control-compatible BD/ DVD player, etc).
  • Page 31 3 4 5 6 7 8 TV connection ■ ❑ Necessary settings Connection method 2 (HDMI Control-compatible TV) To use HDMI Control, you need to configure the following settings. Connect the TV to this unit with an HDMI cable and an audio cable (digital optical or For details on settings and operations of your TV, refer to the instruction manual of the stereo pin cable).
  • Page 32 3 4 5 6 7 8 TV connection ■ Connection method 3 (TV with HDMI input jacks) Configure the settings for HDMI Control. Connect the TV to this unit with an HDMI cable and an audio cable (digital optical or a Enable HDMI Control on the TV and playback devices (HDMI Control-compatible BD/ stereo pin cable).
  • Page 33 3 4 5 6 7 8 TV connection ■ Connection method 4 (TV without HDMI input jacks) S VIDEO connection (with an S-video cable) Depending on the video input jacks available on your TV, choose one of the following MONITOR OUT connections.
  • Page 34: Connecting Another Tv Or A Projector

    3 4 5 6 7 8 TV connection ■ Connecting another TV or a projector This unit has 2 HDMI output jacks. If you connect another TV or a projector to this unit with an HDMI cable, you can switch the TVs (or projector) to be used for watching videos with the remote control (p.51).
  • Page 35: Connecting Playback Devices

    1 2 3 4 5 6 7 8 Playback device connections Connecting playback devices ■ This unit is equipped with a variety of input jacks including HDMI input jacks to allow HDMI connection you to connect different types of playback devices. For information on how to connect Connect a video device to this unit with an HDMI cable.
  • Page 36: Component Video Connection

    1 2 3 4 5 6 7 8 Playback device connections ■ ■ Component video connection S-video connection Connect a video device to this unit with a component video cable and an audio cable Connect a video device to this unit with an S-video cable and an audio cable (digital (digital coaxial, digital optical or stereo pin cable).
  • Page 37: Connecting Audio Devices (cd Players, Etc.)

    1 2 3 4 5 6 7 8 Playback device connections ■ Composite video connection Connecting audio devices (CD players, etc.) Connect a video device to this unit with a video pin cable and an audio cable (digital Connect audio devices such as CD players, MD players and a turntable to this unit. coaxial, digital optical or stereo pin cable).
  • Page 38: Connecting To The Jacks On The Front Panel

    1 2 3 4 5 6 7 8 Playback device connections Connecting to the jacks on the front panel Audio output PHONO jacks (PHONO) PHONO Use the VIDEO AUX jacks on the front panel to temporarily connect devices such as a game console and a camcorder to this unit.
  • Page 39: Connecting The Fm/am Antennas

    1 2 3 4 5 6 7 8 FM/AM antenna connections Connecting the FM/AM antennas Connect the supplied FM/AM antennas to this unit. • Unwind the antenna cable from the AM antenna unit only the length needed. FM antenna • The wires of the AM antenna have no polarity. You can connect either wire to the AM jack or GND jack. If AM antenna you connect the GND jack to a commercially-available ground bar or copper plate with a vinyl-covered wire and bury this new attachment in moist ground, you can reduce noise.
  • Page 40: Connecting To The Network

    1 2 3 4 5 6 7 8 Network connections Connecting to the network Connect this unit to your router with a commercially-available STP network cable (CAT-5 or higher straight cable). You can enjoy Internet radio or music files stored on PCs and DLNA servers such as •...
  • Page 41: Connecting Other Devices

    1 2 3 4 5 6 Other connections Connecting a device with analog multi-channel Connecting other devices output Connecting video/audio recording devices You can connect an analog multi-channel output device such as a DVD player and an SACD player to the MULTI CH INPUT jacks. You can connect video/audio recording devices to the AV OUT jacks.
  • Page 42: Connecting A Device Compatible With Scene Link Playback (remote Connection)

    • If you connect a Yamaha product compatible with SCENE link playback to one of the REMOTE (OUT) jacks, you can start playback on the Yamaha product in conjunction with a scene selection (p.52). To enable the SCENE link playback, specify the device type in “Device Control”...
  • Page 43: Connecting The Power Cable

    1 2 3 4 5 6 7 Power cable connection Connecting the power cable After all the connections are complete, connect the supplied power cable to this unit and then to an AC wall outlet. This unit (rear) RS-232C AV 5 AV 6 AV 7 TRIGGER...
  • Page 44: Optimizing The Speaker Settings Automatically (ypao)

    Optimizing the speaker settings automatically (YPAO) RECEIVER RECEIVER By using the Yamaha Parametric room Acoustic Optimizer (YPAO) function, this unit automatically detects speaker connections and Place the YPAO microphone at ear height in your distances from the listening position, and optimizes the speaker...
  • Page 45 1 2 3 4 5 6 7 8 Automatic speaker setup The following screen appears on the TV. SOURCE SOURCE RECEIVER RECEIVER • If you perform the single measure, you will be able to enjoy surround sound at that position with optimized speaker settings. If you perform the multi measure, the speaker settings will be optimized for you to enjoy surround sound in a wider space.
  • Page 46: Measuring At One Listening Position (single Measure)

    1 2 3 4 5 6 7 8 Automatic speaker setup Measuring at one listening position SOURCE SOURCE RECEIVER RECEIVER To save the measurement results, use the cursor (single measure) keys to select “SAVE” and press ENTER. When “Multi Position” is set to “No”, follow the procedure below to make the measurement.
  • Page 47: Measuring At Multiple Listening Positions (multi Measure)

    1 2 3 4 5 6 7 8 Automatic speaker setup Measuring at multiple listening positions SOURCE SOURCE RECEIVER RECEIVER If the measurement at all listening position are (multi measure) made, use the cursor keys to select “CANCEL” and press ENTER. When “Multi Position”...
  • Page 48: Checking The Measurement Results

    1 2 3 4 5 6 7 8 Automatic speaker setup SOURCE SOURCE RECEIVER RECEIVER Size of each speaker (cross-over frequency of the Caution subwoofer) • Since the YPAO microphone is sensitive to heat, do not place the microphone Large: The speaker can reproduce low-frequency Size in any place where it will be subjected to direct sunlight or high temperatures signals effectively.
  • Page 49: Error Messages

    Connect the YPAO microphone to the YPAO MIC jack firmly and follow the on-screen instructions to start the E-8: No Signal The YPAO microphone cannot detect test tones. measurement again. If this error occurs repeatedly, contact the nearest authorized Yamaha dealer or service center. E-9: User Cancel The measurement has been canceled.
  • Page 50: Warning Messages

    1 2 3 4 5 6 7 8 Automatic speaker setup Warning messages Even if any warning message is displayed after the measurement, you can save the measurement results by following on-screen instructions. However, we recommend you perform YPAO again to use this unit with the optimal speaker settings. Warning message Cause Remedy...
  • Page 51: Playback

    PLAYBACK SOURCE SOURCE RECEIVER RECEIVER Basic playback procedure V-AUX AUDIO Selecting an HDMI output jack Input selection keys Turn on external devices (TV, BD/DVD player, etc.) PHONO MULTI connected to this unit. DOCK TUNER SIRIUS [ A ] [ A ] SCENE Press HDMI OUT to select an HDMI OUT jack.
  • Page 52: Selecting The Input Source And Favorite Settings At Once (scene)

    SOURCE SOURCE RECEIVER RECEIVER Selecting the input source and favorite settings at once (SCENE) The SCENE function allows you to select the assigned input source, sound program, HDMI output and various settings at once. You can use up to 12 scenes to register your favorite settings and switch them depending on a playback source. V-AUX V-AUX AUDIO...
  • Page 53: Configuring Scene Assignments

    • You can start playback of external devices connected to this unit via HDMI or a Yamaha product connected to the REMOTE OUT jack, in conjunction with a scene selection (SCENE link playback). To enable the SCENE link playback, specify the device type in “Device Control”...
  • Page 54: Selecting The Sound Mode

    SOURCE RECEIVER Selecting the sound mode SOURCE/RECEIVER This unit is equipped with a variety of sound programs and On-screen sound program/surround decoder selection surround decoders that allow you to enjoy playback sources with a favorite sound mode (sound field effect, stereo playback, etc). V-AUX V-AUX Press ON SCREEN.
  • Page 55: Enjoying Sound Field Effects (cinema Dsp)

    ❑ ENTERTAINMENT This unit is equipped with a variety of sound programs that utilize Yamaha's original DSP technology (CINEMA DSP). It allows you to easily create sound fields like actual This program allows the listeners to enjoy stereo sport broadcasts and movie theaters or concert halls in your room.
  • Page 56 ■ ❑ STEREO Sound programs suitable for music/stereo playback (MUSIC) Use this program to mix down multi-channel sources to 2 channels. When 2ch Stereo multi-channel signals are input, they are down mixed to 2 channels and The following sound programs are optimized for listening to music sources. output from the front speakers (this program does not utilizes CINEMA DSP).
  • Page 57: Enjoying Unprocessed Playback

    ■ Enjoying stereoscopic sound fields Enjoying unprocessed playback SOURCE SOURCE RECEIVER RECEIVER (CINEMA DSP 3D) You can play back input sources without any sound field effect processing. CINEMA DSP 3D enables to create a natural stereoscopic sound V-AUX V-AUX field in your room. ■...
  • Page 58: Enjoying Pure High Fidelity Sound (pure Direct)

    Enjoying compressed music with enhanced PLIIx Music SOURCE SOURCE RECEIVER RECEIVER Uses the Dolby Pro Logic IIx decoder (or Dolby Pro sound (Compressed Music Enhancer) Logic II decoder) suitable for music. PLII Music PLIIx Game Uses the Dolby Pro Logic IIx decoder (or Dolby Pro Logic II decoder) suitable for games.
  • Page 59: Listening To Fm/am Radio

    SOURCE SOURCE RECEIVER RECEIVER Listening to FM/AM radio You can tune into a radio station by specifying its frequency or selecting from registered radio stations. Since this unit supports the HD Radio feature (p.60), you can select • You can switch between “Auto” (stereo) and “Mono” (monaural) for FM radio V-AUX V-AUX AUDIO...
  • Page 60: Hd Radio™ Tuning

    HD Radio™ tuning SOURCE SOURCE RECEIVER RECEIVER • To select a preset number to which the station will be registered, press HD Radio Technology is a new technology that enables FM/AM MEMORY once after tuning into a desired radio station, use PRESET or radio stations to broadcast programs digitally.
  • Page 61: Using Itunes Tagging

    ■ Selecting an HD Radio™ audio program SOURCE SOURCE RECEIVER RECEIVER You can select an audio program when this unit is tuned into an HD • “Insufficient Data” appears when tagging is not currently available. Radio station that provides multiple audio programs (up to 8). Press PRG SELECT repeatedly to select a desired •...
  • Page 62: Operating The Radio On The Tv

    Operating the radio on the TV SOURCE SOURCE RECEIVER RECEIVER Menu Submenu Function You can view the radio information or select a radio station on the TV. Switches to FM/AM. Press TUNER to select “TUNER” as the input Tuning (+/-) Selects a frequency.
  • Page 63 ■ Browse screen SOURCE SOURCE RECEIVER RECEIVER V-AUX V-AUX AUDIO AUDIO PHONO PHONO MULTI MULTI DOCK DOCK TUNER TUNER SIRIUS SIRIUS [ A ] [ A ] SCENE Preset station list PROGRAM MUTE VOLUME Displays the list of preset stations. Use the cursor keys to select a preset station and press ENTER to tune into it.
  • Page 64: Listening To Sirius Satellite Radio

    Listening to SIRIUS Satellite Radio™ To listen to Satellite Radio, you’ll need to connect a SIRIUS Satellite Connecting the SiriusConnect™ tuner Radio tuner (sold separately) to your SIRIUS-Ready receiver. SIRIUS Satellite Radio is available to residents of the US (except Connect the SiriusConnect tuner (sold separately) to the SIRIUS Alaska and Hawaii) and Canada.
  • Page 65: Activating Sirius Satellite Radio™ Subscription

    Activating SIRIUS Satellite Radio™ SOURCE SOURCE RECEIVER RECEIVER subscription • “F/W UPDATE” appears when the SiriusConnect tuner is updating the firmware. Before using the SIRIUS Satellite Radio feature, you need to • “UPDATING” appears when the SiriusConnect tuner is updating the channel list.
  • Page 66: Registering Favorite Channels (preset)

    ■ Selecting a preset channel SOURCE SOURCE RECEIVER RECEIVER Recall a registered channel by selecting the preset number. • This unit skips the following channels during All Channel Search or Category Search. This is not a malfunction. Press SIRIUS to select “SIRIUS” as the input -Channels that are not currently in service.
  • Page 67: Displaying The Sirius Satellite Radio™ Information

    Displaying the SIRIUS Satellite Radio™ Operating SIRIUS Satellite Radio™ on the TV SOURCE SOURCE RECEIVER RECEIVER information You can view the SIRIUS Satellite Radio information or select a channel on the TV. You can switch the SIRIUS Satellite Radio information displayed on the front display.
  • Page 68 ■ Browse screen SOURCE SOURCE RECEIVER RECEIVER Menu Submenu Function Switches the SIRIUS Satellite Radio Channel (+/-) channels (All Channel Search). Hold down the button for quick search. Switches the channel categories. Hold V-AUX V-AUX down the button for quick search. If you AUDIO AUDIO press “Channel (+/-)”...
  • Page 69: Parental Lock

    ■ Restricting access to specific channels SOURCE SOURCE RECEIVER RECEIVER Use the cursor keys to select a channel to be locked (Parental Lock) and press ENTER. You can restrict access to specific SIRIUS Satellite Radio channels Each time you press ENTER, the channel is locked or by setting a Parental Lock code number.
  • Page 70: Playing Back Ipod Music/videos

    Playing back iPod music/videos You can play back iPod music/videos on this unit using a USB cable supplied with iPod, Connecting an iPod an optional Yamaha iPod dock (such as YDS-12) or an optional Yamaha iPod wireless system (YID-W10). ■...
  • Page 71 ■ Using an iPod dock DOCK Refer to the instruction manual of the iPod dock in addition. DOCK NETWORK AV 1 AV 2 AV 3 AV 4 AV OUT MONITOR OUT/ (1 BD/DVD) ZONE OUT Set this unit to standby mode and connect the iPod PHONO dock to the DOCK jack.
  • Page 72: Playback Of Ipod Contents

    ■ Playback of iPod contents Browse screen SOURCE SOURCE RECEIVER RECEIVER When using a USB cable or an iPod dock, you can control the iPod with the menu displayed on the TV. V-AUX V-AUX AUDIO AUDIO • When using an iPod wireless system, you cannot control the iPod from the TV screen.
  • Page 73: Playback Screen

    ■ ■ Playback screen Operating the iPod itself or remote control SOURCE SOURCE RECEIVER RECEIVER (simple play) Press MODE to switch to the simple play mode. V-AUX V-AUX The TV menu screen turns off and iPod operations are AUDIO AUDIO enabled.
  • Page 74 ■ Shuffle/repeat settings SOURCE SOURCE RECEIVER RECEIVER You can configure the shuffle/repeat settings of your iPod. • When using an iPod wireless system, configure the shuffle/repeat settings directly V-AUX V-AUX on your iPod. AUDIO AUDIO • During simple play, configure the shuffle/repeat settings directly on your iPod, or press MODE to display the TV menu screen and then follow the procedure below.
  • Page 75: Playing Back Music Via Bluetooth

    [ A ] SCENE • The Yamaha Bluetooth receiver (YBA-10) can be paired with up to eight Bluetooth • When connecting your Bluetooth component to the Bluetooth receiver for the first components. When the ninth component is paired, the pairing setting for the time, you need to perform “pairing”...
  • Page 76: Establishing A Wireless Connection And Playing Back

    Establishing a wireless connection and SOURCE SOURCE RECEIVER RECEIVER Select the Bluetooth receiver from the device list playing back and enter the pass key “0000”. “Completed” appears when the pairing is complete. When the pairing is complete, follow the procedure below to establish a wireless connection between your Bluetooth component DOCK DOCK...
  • Page 77: Playing Back Music Stored On A Usb Storage Device

    SOURCE SOURCE RECEIVER RECEIVER Playing back music stored on a USB storage device You can play back music files stored on a USB storage device on Playback of USB storage device contents this unit. Refer to the instruction manuals of the USB storage device in addition.
  • Page 78 ■ ■ Browse screen Playback screen SOURCE SOURCE RECEIVER RECEIVER V-AUX V-AUX AUDIO AUDIO PHONO PHONO MULTI MULTI DOCK DOCK TUNER TUNER SIRIUS SIRIUS [ A ] [ A ] SCENE Status indicators Status indicators PROGRAM MUTE VOLUME Display the current shuffle/repeat settings (p.79) and playback status. Display the current shuffle/repeat settings (p.79) and playback status.
  • Page 79 ■ Shuffle/repeat settings SOURCE SOURCE RECEIVER RECEIVER You can configure the shuffle/repeat settings for playback of USB storage device contents. V-AUX V-AUX AUDIO AUDIO • The shuffle/repeat settings are shared by USB and network sources. PHONO PHONO MULTI MULTI When “USB” is selected as the input source, press DOCK DOCK TUNER...
  • Page 80: Playing Back Music Stored On Pcs

    SOURCE SOURCE RECEIVER RECEIVER Playing back music stored on PCs You can play back music files stored on your PC or DLNA- Playback of PC music contents compatible NAS on this unit. V-AUX V-AUX Follow the procedure below to operate the PC music contents and AUDIO AUDIO start playback.
  • Page 81 ■ Playback screen SOURCE SOURCE RECEIVER RECEIVER • To return to the previous screen, press RETURN. • Files not supported by this unit are not listed (or cannot be selected even if listed). • You can register your favorite items as shortcuts (p.91) and access them V-AUX V-AUX directly by selecting the shortcut numbers.
  • Page 82 ■ Shuffle/repeat settings SOURCE SOURCE RECEIVER RECEIVER You can configure the shuffle/repeat settings for playback of PC music contents. V-AUX V-AUX • The shuffle/repeat settings are shared by USB and network sources. AUDIO AUDIO PHONO PHONO MULTI MULTI When “PC” is selected as the input source, press DOCK DOCK TUNER...
  • Page 83: Listening To Internet Radio

    SOURCE SOURCE RECEIVER RECEIVER Listening to Internet radio ■ You can listen to Internet radio stations using the vTuner Internet Browse screen radio station database service particularly customized for this unit, providing a database of numerous radio stations in the world. V-AUX V-AUX AUDIO...
  • Page 84 SOURCE SOURCE RECEIVER RECEIVER • By adding your favorite Internet radio stations to “Bookmarks”, you can access to them quickly from “Bookmarks”. To remove stations from “Bookmarks”, select the station in “Bookmarks” and then “Bookmark Off”. • You can also register your favorite Internet radio stations by accessing the following website with the web browser on your PC.
  • Page 85: Playing Back Music In Multiple Rooms (multi-zone)

    • Since there are many possible ways to use this unit in a multi-zone configuration, speakers or an external amplifier. we recommend that you consult with your nearest authorized Yamaha dealer or • Be careful that the core of the speaker cable does not touch anything or come service center about the multi-zone connections that best meet your into contact with the metal areas of this unit.
  • Page 86: Using An External Amplifier

    ■ Using an external amplifier Connect the external amplifier placed in Zone2 or Zone3 to this unit with a stereo pin cable. This unit (rear) ZONE OUT HDMI (ZONE 2 or ZONE 3) AV 1 AV 2 AV 3 AV 4 AV 5 (1 BD/DVD) jacks...
  • Page 87 ■ Connecting a zone video monitor ZONE OUT jacks (any of COMPONENT VIDEO, Connect a zone video monitor to watch videos at Zone2 or Zone3. VIDEO, S VIDEO) Depending on the video input jacks available on your video monitor, choose one of the video connection methods. MONITOR OUT/ZONE OUT Video input (any of component video,...
  • Page 88 ❑ Remote connections between Yamaha products Operating this unit from another room (remote connection) If you are using Yamaha products that support remote connections like this unit, an infrared signal transmitter is unnecessary. You can By connecting an infrared signal receiver/emitter to the REMOTE1...
  • Page 89: Controlling Zone2 Or Zone3

    Controlling Zone2 or Zone3 SOURCE SOURCE RECEIVER RECEIVER RECEIVER RECEIVER Start playback on the external device, or select a radio station. Press ZONE repeatedly to select a zone. Refer to the instruction manual of the external device. AV1~4 For details on the following operations, see the V-AUX Each time you press the key, the zone to be operated V-AUX...
  • Page 90 ■ ■ Other operations for Zone2 or Zone3 Enjoying main zone sources in all zones SOURCE SOURCE RECEIVER RECEIVER (party mode) The following functions are also available when audio output to the zone you want to operate is enabled. The party mode allows you to enjoy main zone sources in all zones simultaneously.
  • Page 91: Useful Functions

    SOURCE SOURCE RECEIVER RECEIVER Useful functions ■ Registering favorite items (shortcut) Recalling a registered item V-AUX V-AUX Recall a registered item by selecting the shortcut number. AUDIO AUDIO You can register up to 40 favorite USB and network contents as PHONO PHONO MULTI...
  • Page 92: Controlling This Unit From The Web Browser (web Control)

    ■ Controlling this unit from the web browser Top menu screen (web control) You can control this unit with the web control screen displayed in the web browser. Web browser Web control Web control Router This unit CONTROL Moves to the control screen for the selected zone. STATUS •...
  • Page 93: Control Screen

    ■ ■ Control screen Settings screen PLAY INFO Rename Selects an input source or controls playback for the selected zone. Edits the friendly name (name for this unit in the network) or the name of each zone (p.120). Click “APPLY” to apply the changes to this unit. TOP MENU MAC Filter Moves to the top menu screen.
  • Page 94: Viewing The Current Status

    Viewing the current status Song (song title), Artist (artist name), Album (album SOURCE SOURCE RECEIVER RECEIVER name), DSP Program (sound mode name), Audio Decoder (decoder name) DOCK ■ Switching information on the front display * When using iPod wireless system, Bluetooth receiver, or during simple play: DSP Program (sound mode name), Audio Decoder V-AUX...
  • Page 95: Configuring Settings In Accordance With A Playback Source (option Menu)

    Configuring settings in accordance with a playback source (Option menu) You can configure the playback-related settings in accordance with a playback source. Option menu items Since this menu is operational on the front panel (or on the TV screen), you can easily configure the settings during playback.
  • Page 96 ■ ■ Tone Control (Tone Control) CINEMA DSP 3D Mode (CINEMA DSP 3D) Adjusts the high-frequency range (Treble) and low-frequency range (Bass) of speaker Enables/disables CINEMA DSP 3D. If this function is set to “On”, CINEMA DSP 3D sounds. When connecting headphones, you can adjust high-frequency range and low- functions according to the selected sound programs (except 2ch Stereo and 9ch frequency range of sounds output from headphones.
  • Page 97 ■ ■ Extended Surround (EXTD Surround) Enhancer (Enhancer) Selects how to play back 5.1- to 7.1-channel sources when surround back speakers Enables/disables Compressed Music Enhancer (p.58). are used. Settings • This setting is applied separately to each input source. Automatically selects the most suitable decoder if a flag for Settings reproducing surround back channel is present, and reproduces the Auto (Auto) (default)
  • Page 98: Configurations

    CONFIGURATIONS Configuring input sources (Input menu) Use the cursor keys ( / ) to select an item and press ENTER. You can change the input source settings using the TV screen. Press ON SCREEN. Use the cursor keys to select “Input” and press ENTER. •...
  • Page 99 ■ ■ Rename/Icon Select Standby Charge Changes the input source name and icon displayed on the front display or TV screen. Selects whether to charge the iPod connected to the iPod dock or iPod wireless system when this unit is in standby mode. Input sources AV1~7, V-AUX, AUDIO1~4, PHONO, USB, DOCK, MULTI CH Input sources...
  • Page 100: Configuring The Scene Function (scene Menu)

    ■ Video Out Configuring the SCENE function (Scene menu) Selects a video to be output with the audio input source. You can change the settings of the SCENE function (p.52) using the TV screen. Input sources TUNER, Sirius Satellite Radio, (network sources), USB, MULTI CH Press ON SCREEN.
  • Page 101: Scene Menu Items

    Scene menu items ❑ Device Control Enables to start playback of external devices connected to this unit via HDMI or a Yamaha product connected to one of the REMOTE (OUT) jacks, in conjunction with a Item Function Page...
  • Page 102 ❑ Detail ■ Rename/Icon Select Selects items to be included as the scene assignments. You can also view the settings Changes the scene name and icon displayed on the front display or TV screen. currently assigned to the selected scene. ■...
  • Page 103: Configuring Sound Programs/surround Decoders (sound Program Menu)

    Configuring sound programs/surround Use the cursor keys ( / ) to select an item and press ENTER. decoders (Sound Program menu) You can change the settings of the sound programs and surround decoders using the TV screen. Press ON SCREEN. Use the cursor keys to select “Sound Program”...
  • Page 104: Sound Program Menu Items

    Sound Program menu items Item Function Settings Adjusts the delay between the direct 0 ms ~ 250ms Reverb Delay sound and reverberant sound Higher to enhance the delay generation. effect and lower to reduce. • Available items vary depending on the selected sound program or surround decoder. 0% ~ 100% Adjusts the volume of the reverberant Higher to strengthen the...
  • Page 105 ■ Settings for decoders The following items are available when you set “Decode Type” of “Surround Decoder” to “PLIIx Music” or “Neo:6 Music”. Decode Type Item Function Settings Off (default), On Select “On” to wrap front right/left Adjusts the broadening channel sounds around the field Panorama effect of the front sound...
  • Page 106: Configuring Various Functions (setup Menu)

    Configuring various functions (Setup menu) Use the cursor keys to select a setting and press ENTER. You can configure the various functions of this unit using the TV screen. To exit from the menu, press ON SCREEN. Press ON SCREEN. Use the cursor keys to select “Setup”...
  • Page 107: Setup Menu Items

    Setup menu items Menu Item Function Page Auto Setup Optimizes the speaker settings automatically (YPAO). Setting Pattern Registers two speaker setting patterns and switches between them. Setting Data Copy Copies the “Setting Pattern” parameters in the specified direction. Power Amp Assign Selects a speaker system.
  • Page 108 Menu Item Function Page IP Address Configures the network parameters (IP address, etc). Network Network Standby Selects whether or not to turn on this unit by the command from other network devices. MAC Address Filter Sets the MAC address filter to limit access to this unit from other network devices. Volume Enables/disables volume adjustments for Zone2 or Zone3 output.
  • Page 109: Speaker (manual Setup)

    ■ Speaker (Manual Setup) Power Amp Assign Selects a speaker system. Configures the speaker settings manually. This unit has 9 built-in amplifiers. You can connect 2 to 11 speakers and up to 2 subwoofers (with built-in amplifier) to create the favorite acoustic space in your room. You can also apply bi-amp connections, channel expansion (using an external power amplifier) or multi-zone configurations to enhance your system.
  • Page 110 ■ Configuration Select this when no surround speakers are connected. None The front speakers will produce surround channel audio. Virtual Configures the output characteristics of the speakers. CINEMA DSP works when you select a sound program. ❑ Surround Back • When you configure the speaker size, select “Large” if the woofer diameter of your speaker is Selects whether or not surround back speakers are connected and its size.
  • Page 111 ❑ Subwoofer 1, Subwoofer 2 Selects whether or not subwoofer is connected to the SUBWOOFER 1 or • This setting is not available when both “Subwoofer 1” and “Subwoofer 2” are set to “None”, or “Front” is set SUBWOOFER 2 jack and its phase. to “Small”.
  • Page 112: Test Tone

    ■ Parametric EQ Use the cursor keys to adjust parameters and press ENTER. Setting range Adjusts sound quality of tone with an equalizer. Gain: -20.0dB ~ +6.0dB (0.5dB steps) ❑ PEQ Select Center frequency: 31.3Hz ~ 16.0kHz Q factor: 0.500 ~ 10.08 Selects a type of equalizer to be used.
  • Page 113: Sound

    ■ Sound Dynamic Range Selects the dynamic range adjustment method for bitstream audio (Dolby Digital and Configures the audio output settings. DTS signals) playback. Settings Maximum (default) Produces audio without adjusting the dynamic range. Standard Optimizes the dynamic range for regular home use. Sets the dynamic range to make clear sound even at night or at low volumes.
  • Page 114: Video

    ■ ■ Adaptive DSP Level Processing Selects whether to automatically adjust the CINEMA DSP effect level in conjunction with Enables/disables the video signal processing (resolution, aspect ratio and video volume adjustments. adjustments). Settings Settings Does not adjust the effect level automatically. Off (default) Disables the video signal processing.
  • Page 115 ❑ Adjustment Brightness Adjusts the video brightness. Configures the video adjustments when “Processing” is set to “On”. You can register the video adjustments as presets (up to 6). Setting range -100 ~ +100 ■ Setup procedure Default Use the cursor keys ( / ) to select a preset number and press ENTER. Use the cursor keys ( / ) to select an item.
  • Page 116: Hdmi

    ❑ ARC HDMI Enables/disables ARC (p.29) when “HDMI Control” is set to “On”. Configures the settings related to HDMI. Settings Disables ARC. On (default) Enables ARC. • You do not need to change this setting normally. In case noises are produced from the speakers connected to this unit because TV audio signals input to this unit via ARC are not supported by this unit, set “ARC”...
  • Page 117: Network

    ■ Audio Output Network Selects a device to output audio. Configures the network settings. • The “Amp” and “HDMI OUT1” settings are available only when “HDMI Control” is set to “Off”. ❑ Amp Enables/disables the audio output from the speakers connected to this unit. Settings Disables the audio output from the speakers.
  • Page 118: Multi Zone

    ■ Network Standby Multi Zone Selects whether to turn on this unit by the command from other network devices Configures the multi zone settings. (network standby). Settings Off (default) Disables the network standby function. Enables the network standby function. (This unit consumes approximately 5 W of power.) ■...
  • Page 119: Zone Scene Rename

    ❑ Mono ■ Zone Scene Rename Switches between stereo and monaural for Zone2 or Zone3 output. Changes the scene names (for Zone2 or Zone3) displayed on the front display or TV screen. Settings ■ Setup procedure Off (default) Produces stereo sounds in Zone2 or Zone3. Use the cursor keys to select a zone and press ENTER.
  • Page 120: Function

    ■ ■ Zone Rename Auto Power Down Changes the zone names displayed on the front display or TV screen. Sets the amount of time for auto-standby. If you do not operate this unit for the specified time, this unit will automatically go into standby mode. ■...
  • Page 121: Display Set

    ■ ■ Display Set Trigger Output1, Trigger Output2 Configures the settings related to the front display and TV screen display. Sets the TRIGGER OUT 1~2 jacks to function synchronized with power status of each zone or input switching. ❑ Front Panel Display ❑...
  • Page 122: Language

    ❑ Target Source Language Specifies the output level of the electronic signal transmitted with each input switching Select an on-screen menu language. when “Trigger Mode” is set to “Source”. Choices AV1~7, V-AUX, AUDIO1~4, PHONO, TUNER, Sirius Satellite Radio, (network sources), USB, DOCK, MULTI CH Settings Stops the electronic signal transmission when you switch to the input source...
  • Page 123: Viewing Information About This Unit (information Menu)

    Types of information Viewing information about this unit (Information menu) ■ Audio Signal You can view information about this unit using the TV screen. Displays information about the current audio signal. Press ON SCREEN. Format Audio format of the input signal The number of source channels in the input signal (front/ surround/LFE) Use the cursor keys to select “Information”...
  • Page 124: Configuring The System Settings (advanced Setup Menu)

    ■ Network Configuring the system settings Displays the network information on this unit. (ADVANCED SETUP menu) IP Address IP address Subnet Mask Subnet mask You can configure the system settings of this unit using the front display. Default Gateway The IP address of the default gateway Set this unit to standby mode.
  • Page 125: Advanced Setup Menu Items

    Select the remote control ID of the main unit so that it matches to the ID of the remote control (default: ID1). When using multiple Yamaha AV receivers, you can set each remote control with a unique remote control ID for its corresponding receiver.
  • Page 126: Resetting The Parental Lock Code Number (sirius Lock)

    Press ENTER to confirm the setting. Settings Once the remote control ID is registered successfully, “OK” appears in the display window. Enables the monitor check function. (Outputs video signals with a YES (default) resolution supported by the TV only.) If “ERROR” appears, registration failed. Repeat from step 3. Disables the monitor check function.
  • Page 127: Restoring The Default Settings (initialize)

    Restoring the default settings (INITIALIZE) Checking the firmware version (VERSION) Check the version of firmware currently installed on this unit. SP IMP. - INITIALIZE DOCK STEREO TUNED PRE AMP PARTY MUTE VOLUME SP IMP. - VERSION DOCK ZONE ZONE ZONE ADAPTIVE CANCEL OUT 1...
  • Page 128: Controlling External Devices With The Remote Control

    SOURCE SOURCE RECEIVER RECEIVER Controlling external devices with the remote control By setting the code for external devices (BD/DVD players, etc.) or Setting remote control codes assigning a function to each key using the learning function, you can operate the external device with the remote control of this unit. V-AUX V-AUX AUDIO...
  • Page 129 Use the numeric keys or cursor keys to enter the INFO MEMORY • At the factory, Yamaha CD player code (5095) is set for AUDIO2 and Yamaha AV 4-digit remote control and press ENTER. receiver code (5098) is set for the other input selection keys.
  • Page 130: Programming From Other Remote Controls (learning)

    SOURCE SOURCE RECEIVER SOURCE/RECEIVER To exit from the setup menu, press SETUP. • These keys work only when the corresponding function is available on your playback device and is possible to be operated with an infrared remote control. • For details on how to register the input selection key applied the remote Programming from other remote controls V-AUX V-AUX...
  • Page 131: Editing Device Names

    SOURCE SOURCE SOURCE RECEIVER RECEIVER Note RECEIVER RECEIVER Aim the infrared transmitters of the remote controls • If you press RECEIVER in step 3, you can assign functions of an external at each other. receiver to the menu operation keys, external device operation keys or Remote control of external device numeric keys.
  • Page 132: Operating Multiple Functions At Once (macro)

    SOURCE SOURCE RECEIVER RECEIVER RECEIVER RECEIVER Press ENTER. Use the cursor keys ( / ) to select “MACRO” and press ENTER. Use the cursor keys to rename. MACRO To locate the position, use the cursor keys ( / ). V-AUX AUDIO Input selection keys To select a character (A to Z, a to z, 0 to 9, space,...
  • Page 133 ■ Programming macro operations SOURCE SOURCE RECEIVER RECEIVER RECEIVER Press the keys for functions (up to 10) you want to You can program up to 10 remote control commands for each SOURCE/RECEIVER include in the macro operations in sequence. macro operation key. If you press the corresponding macro operation key, the multiple operations will be carried out To switch the devices (this unit or external device) to sequentially according to the programmed remote control...
  • Page 134: Resetting The Remote Control Configurations

    Resetting the remote control configurations SOURCE SOURCE RECEIVER RECEIVER RECEIVER RECEIVER • When “RESET” is selected, all remote control configurations will be cleared. You cannot select a specific key. Proceed to step 5. ■ Clearing the remote control configurations Press a key to which the selected process is You can clear remote control configurations by selecting a type of V-AUX AUDIO...
  • Page 135 SOURCE SOURCE RECEIVER RECEIVER Press one of the following keys to select the device for which key assignments will be cleared. For playback device: press the input selection key. For TV: press TV V-AUX AUDIO Input selection keys Press ENTER. PHONO MULTI DOCK...
  • Page 136: Using The Simplified Remote Control

    Using the simplified remote control Remote control signal transmitter Switching the zones to operate with the simplified Transmits infrared signals. remote control NET/USB • Main zone: Hold down the cursor key ( ) and Press repeatedly to select a desired network source or SCENE1 together for 3 seconds.
  • Page 137: Updating The Firmware Of This Unit

    SOURCE SOURCE RECEIVER RECEIVER Updating the firmware of this unit If this unit is connected to the Internet, the corresponding message will be displayed on the TV when a newer firmware is available. In If “UPDATE SUCCESS PLEASE POWER OFF!” this case, follow the procedure below to update the firmware of this V-AUX V-AUX...
  • Page 138: Appendix

    I made HDMI connections but HDMI Control does not work at When using multiple Yamaha products, the supplied remote control may work on another Yamaha product or another remote control may work on this unit. In this case, all... set each remote control with a unique remote control ID for its corresponding receiver To use HDMI Control, you need to perform the HDMI Control link setup (p.150).
  • Page 139: Troubleshooting

    As a safety precaution, capability to turn on the power is disabled. Contact your The power does not turn on. The protection circuitry has been activated 3 times consecutively. nearest Yamaha dealer or service center to request repair. The internal microcomputer is hung-up due to an external electric Hold down MAIN ZONE on the front panel for more than 10 seconds to initialize The power does not turn off.
  • Page 140: Audio

    Audio Problem Cause Remedy Another input source is selected. Select an appropriate input source with the input selection keys Some digital audio formats cannot be played back on this unit. To check the No sound. Signals that this unit cannot reproduce are being input. audio format of the input signal, use “Audio Signal”...
  • Page 141: Video

    Problem Cause Remedy Only the front speakers work on multi- The playback device is set to output 2-channel audio (PCM, etc.) Change the digital audio output setting on the playback device. channel audio. only. This unit is too close to other digital or radio frequency device. Move this unit further away from such device.
  • Page 142: Fm/am Radio

    FM/AM radio Problem Cause Remedy There is multi-path interference. Adjust the FM antenna height or orientation, or place it in a different location. Press MODE to select “Mono” (monaural reception) (p.59). FM radio reception is weak or noisy. Your area is too far from the FM station transmitter. Use an outdoor FM antenna commercially available.
  • Page 143: Remote Control

    Problem Cause Remedy Configure the sharing setting and select this unit as a device to which music The media sharing setting is not correct. contents are shared (p.80). Some security software installed on your PC is blocking the access This unit does not detect the PC. Check the settings of security software installed on your PC.
  • Page 144: Error Indications On The Front Display

    Error indications on the front display Message Cause Remedy (alphabetical order) Access denied Access to the PC is denied. Configure the sharing setting and select this unit as a device to which music contents are shared (p.80). This unit cannot access the USB device. Turn off this unit and reconnect your USB device.
  • Page 145: Error Indications For Sirius Satellite Radio

    Error indications for SIRIUS Satellite Radio™ Message Cause Remedy (alphabetical order) Adjust the orientation of the antenna of the SiriusConnect tuner by checking the antenna reception level ACQUIRING SIG The signal is too weak. displayed in the front display (p.67) or TV (p.67). ANTENNA ERROR The antenna is not connected to the SiriusConnect tuner properly.
  • Page 146: Glossary

    Dolby Surround uses a 4-channel analog recording system to reproduce realistic and dynamic sound effects: 2 front left Based on a wealth of actually measured data, Yamaha CINEMA DSP uses Yamaha’s original DSP technology to and right channels (stereo), a center channel for dialog (monaural), and a surround channel for special sound effects combine Dolby Pro Logic, Dolby Digital, and DTS systems to provide the audiovisual experience of a movie theater in (monaural).
  • Page 147 CDs. The frequency is equal to or higher than 100 kHz, with a dynamic range of 120 dB. This unit can transmit or receive Yamaha has developed a Virtual CINEMA DSP algorithm that allows you to enjoy DSP surround effects even without any DSD signals via the HDMI jack.
  • Page 148: Video Information

    Video information Component video signal With the component video signal system, the video signal is separated into the Y signal for luminance and the Pb and Pr signals for chrominance. Color can be reproduced more faithfully with this system because each of these signals is independent.
  • Page 149: Video Signal Flow

    ■ Video signal flow Video conversion table Video signals input from a video device to this unit are output to a TV as shown below. • You can select a resolution and an aspect ratio applied to HDMI-output video processing. (solid line) is always available.
  • Page 150: Information On Hdmi

    To use HDMI Control, you need to perform the following HDMI Control link setup after Information on HDMI connecting the TV and playback devices. HDMI Control • This setup is required every time when you add a new HDMI Control-compatible device to your system. •...
  • Page 151: Hdmi Signal Compatibility

    HDMI signal compatibility Audio signals Audio signal type Audio signal format Compatible media (example) 2ch Linear PCM 2ch, 32 to 192 kHz, 16/20/24 bit CD, DVD-Video, DVD-Audio DVD-Audio, BD (Blu-ray disc), Multi-channel Linear PCM 8ch, 32 to 192 kHz, 16/20/24 bit HD DVD 2/5.1ch, 2.8224 MHz, 1 bit SACD...
  • Page 152: Reference Diagram (rear Panel)

    Reference diagram (rear panel) DOCK NETWORK HDMI RS-232C HDMI OUT AV 1 AV 2 AV 3 AV 4 AV 5 AV 6 AV 7 (1 BD/DVD) AV 1 AV 2 AV 3 AV 4 COMPONENT VIDEO TRIGGER AV OUT MONITOR OUT/ (1 BD/DVD) AV 3 ZONE OUT...
  • Page 153: Trademarks

    HD Radio Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trademarks of iBiquity Digital Corp. Bluetooth™ Bluetooth is a registered trademark of the Bluetooth SIG and is used by Yamaha in accordance with a license agreement.
  • Page 154: Specifications

    Specifications ❑ Input jacks • Digital Audio • Audio Format Optical x 1 (AV OUT) - Dolby Digital • Analog Audio - DTS • Video Audio x 10 (AV1~4, AUDIO1~4, PHONO, V-AUX) - DSD 6ch MONITOR OUT/ZONE OUT MULTI CH INPUT (8ch) x 1 - Dolby Digital Plus - Composite x 1 (FRONT L/R, CENTER, SURROUND L/R,...
  • Page 155: Audio Section

    ❑ Compatible Decoding Formats • Dynamic Power (IHF) • Volume Control Front L/R (8/6/4/2 Ω)........165/210/285/405 W Main Zone ....MUTE, -80 dB to +16.5dB (0.5 dB step) • Decoding Format Zone2, Zone3.....MUTE, -80 dB to +16.5dB (0.5 dB step) • Damping Factor - Dolby TrueHD, Dolby Digital Plus Front L/R, 1 kHz, 8 Ω...
  • Page 156 ❑ FM Section ❑ General • Tuning Range • Power Supply [U.S.A. and Canada models] ....87.5 MHz to 107.9 MHz [U.S.A. and Canada models] ......AC 120 V, 60 Hz [Asia and General models] [General model] ....AC 110-120/220-240 V, 50/60 Hz ........87.5/87.50 MHz to 108.0/108.00 MHz [China model]..........AC 220 V, 50 Hz [Other models].........87.50 MHz to 108.00 MHz...
  • Page 157 © 2011 Yamaha Corporation YD505A0/OMEN1...
  • Page 158 List of remote control codes Lijst met afstandsbedieningscodes Liste des codes de commande Liste over fjernbetjeningskoder Liste der Fernbedienungscodes Liste over fjernkontrollkoder Lista över fjärrstyrningskoder Elenco dei codici di telecomando Lista de códigos de mando a distancia Amtron 0058 Baur 0320, 0349 Cathay 0320, 0349, 0350...
  • Page 159 Crown 0058, 0161, 0171, 0179, Elcit 0339 Frontech 0282, 0323, 0337, 0343, Grunpy 0058, 0059, 0179 0320, 0323, 0343, 0349, Electa 0348 0346, 0347 Haier 0157, 0233 0350, 0351 ELECTRO TECH 0343 Fujitsu 0059, 0069, 0074, 0075, Halifax 0277, 0282, 0337, 0342 CS Electronics 0277, 0340, 0342 Electroband 0055, 0107...
  • Page 160 Infinity 0010 0039 Magnavox 0008, 0009, 0010, 0013, Motion 0171 InFocus 0250, 0327, 0363, 0479, Kloss Novabeam 0057, 0058 0026, 0032, 0033, 0048, Motorola 0052, 0178 0508 Kneissel 0161, 0168, 0320 0050, 0128, 0211, 0212, 0008, 0026, 0050, 0053, Ingelen 0347 Kolster 0320, 0350...
  • Page 161 Orion 0043, 0146, 0283, 0320, Phonola 0277, 0320, 0339, 0349, 0008, 0021, 0024, 0025, Schneider 0282, 0316, 0318, 0320, 0323, 0328, 0343, 0349, 0350 0026, 0027, 0042, 0049, 0333, 0340, 0342, 0349, 0350 Pilot 0007, 0008, 0050 0052, 0053, 0063, 0136, 0350, 0382 Orline 0320...
  • Page 162 0277, 0282, 0342, 0344, Trans Continens 0282, 0320 Xrypton 0320 Broksonic 1100 0346 Transtec 0277 Yamaha 0008, 0026, 0050, 0053, Bush 1008, 1009, 1024, 1025, Tatung 0052, 0177, 0282, 0320, Trident 0282 0080, 0081, 0082, 0083, 1029, 1049, 1051, 1063,...
  • Page 163 Catron 1030 Firstline 1008, 1024, 1029, 1031 iBUYPOWER 1016 Matsushita 1068 1026, 1027 Fisher 1065 Impego 1030 Media Center PC 1016 Cimline 1008, 1024, 1029 Flint 1024 Imperial 1026 Mediator 1028 CineVision 1104 Formenti/Phoenix 1028 Inno Hit 1008, 1009, 1025, 1028, Medion 1024 Citizen...
  • Page 164 1002, 1034, 1041, 1043, 1126 XR-1000 1068, 1069 Bush 2064, 2110, 2170, 2268, 1057, 1060, 1070, 1084, Symphonic 1008, 1069, 1126 Yamaha 1064, 1065 2290, 2346, 2358, 2367, 1110, 1116, 1122, 1124, Systemax 1016 Yamishi 1008, 1029 2383 1220, 1222...
  • Page 165 California Audio Labs Elta 2341, 2361, 2362 2260, 2262, 2263, 2321, Minowa 2367 2151 Emerson 2129, 2137, 2150 2324, 2326, 2327, 2343, Mintek 2131, 2245 Cambridge Audio 2354 Enterprise 2129 2464, 2465, 2468, 2469, Mitsubishi 2003 2352, 2353 Enzer 2380 2471, 2511 Mizuda 2358, 2359...
  • Page 166 2367 2507 Proceed 2130 Slim Art 2362 Trio 2362 Toshiba 2462 Proscan 2156 SM Electronic 2355 Trutech 2242 Yamaha 2064, 2448, 2449, 2474, Prosonic 2360, 2377 Sonic Blue 2133 TruVision 2359 2505 Protron 2202 Sontech 2366 2364 Provision 2358 Sony...
  • Page 167 2032, 2036, 2037, 2039, Freebox 3023 Pioneer 3001, 3006, 3094, 3098, 3127 2049, 2054, 2055, 2076 GC Electronics 3070 3114, 3116, 3120 Verizon Fios 3007 Yamaha 2056 3066, 3093 Popular Mechanics Videoway 3019 3105 3126 View Star 3074, 3077, 3079 Gemini...
  • Page 168 Astro 4004, 4008, 4010, 4015, Digital Stream 4105 FinnSat 4050, 4052 Intervision 4048, 4219 4024, 4213, 4218, 4219 DIRECTV 4056, 4064, 4067, 4068, Flair Mate 4217 ITT Nokia 4006 AudioTon 4004, 4048 4070, 4071, 4074, 4107, Foxtel 4222 Jerrold 4019 Aurora 4222 4116, 4119, 4121, 4122,...
  • Page 169 Medison 4217 Panasonic 4006, 4035, 4036, 4121, Samsung 4000, 4001, 4003, 4032, Tandy 4004 Mega 4053, 4055 4124, 4126, 4198, 4221 4064, 4069, 4071, 4120, Tantec 4006 Memorex 4127 Panda 4006, 4219 4123, 4196, 4200 4008 Metronic 4001, 4004, 4005, 4010, Pansat 4125 4007, 4218...
  • Page 170 Apple TV XSat 4217 DOCK Zehnder 4008, 4010, 4024, 4209, Yamaha 5084, 5087 Apple 2241 4215 Yamaha 5068, 5089 Zenith 4102, 4107, 4195 “Apple TV” is a trademark or registered mark Zodiac 4004 of Apple Inc. © 2011 Yamaha Corporation YD505A0/RC...

This manual is also suitable for:

Rx-a3010

Comments to this Manuals

Symbols: 0
Latest comments:
