2.2.1.3 Running the V2 Speaker with Auxiliary Power
In Figure
from an external source.
Operations Guide
2-6, the power for the V2 Speaker can either come from an 802.3af Network connection or
Figure 2-6. Running the V2 Speaker with Auxiliary Power
12-14 VDC
GND
AC adaptor
12-14 VDC @ 3 Amps
Speaker
POWER IN +
(+12VDC 500mA)
POWER GND
RELAY COM
RELAY NO
+5 VDC
BUTTON-SENSE
J10
930274B
Installing the VoIP V2 Speaker
Device Configuration
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT GND
LINE OUT (+)
BUTTON LED (-)
J9
