FPM-40T/S
Flat Panel Monitor with
10.4" Color TFT/DSTN LCD
Display

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPM-40T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech FPM-40T

Summary of Contents for Advantech FPM-40T

  • Page 1 FPM-40T/S Flat Panel Monitor with 10.4" Color TFT/DSTN LCD Display...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time. Specifications are thus subject to change without notice.

  • Page 3: Packing List

    If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1. Visit the Advantech web sites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product.

  • Page 4: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 5 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.

  • Page 6: Table Of Contents

    Contents Chapter 1 Introduction ........1 1.1 Introduction ................2 1.2 Specifications ................3 1.3 Flat Panel Displays ..............5 1.4 Connectors ................6 1.5 Dimensions ................8 Chapter 2 System Setup ........9 2.1 Wall Mounting ..............10 2.2 Panel Mounting ..............11 2.3 Exploded Diagram ...............12 Appendix A Touchscreen Driver Installation ....

  • Page 7: Chapter 1 Introduction

    Introduction This chapter includes: • Introduction • Specifications • Flat Panel Displays • Connectors • Dimensions...

  • Page 8: Introduction

    TFT or DSTN LCD. The display card supports simultaneous use of LCD panels and analog CRT monitors. A shielded 1.8 meter cable connects the FPM-40T/S and the video display card, allowing remote operation. Add an optional touchscreen to create the ultimate user interface.

  • Page 9: Specifications

    1.2 Specifications General • Construction: Plastic panel and steel chassis • Front panel: NEMA 4/12 (IP 52/56) • Control: One contrast adjustment knob on rear side (FPM-40S only) • I/O port keyboard connector • Mounting: Panelmount or wallmount • Dimensions (W x H x D): 342 x 265 x 32 mm (13.5" x 10.4" x 1.3") •...

  • Page 10: Flat Panel Displays

    Luminance (cd/m Toshiba Kyocera LCD Model LTM10C029A KCB6448BSTT-X5 or compatibles or compatibles Temperature 0 ~ 50° C 0 ~ 45° C VR Controls Contrast Simultaneous Mode LCD MTBF 50,000 hours 50,000 hours Backlight MTBF 20,000 hours 25,000 hours FPM-40T/S User's Manual...

  • Page 11: Connectors

    The following connectors are situated on the left side of the FPM-40T/S: Video I/O Port (MDR-26) This connector links the FPM-40T/S to the PCA-6654 display card. Figure 1-1 shows how to make the connection. Note: The display card provides power to the FPM-40T/S;...
  • Page 12 Figure 1-1: Connectors FPM-40T/S User's Manual...

  • Page 13: Dimensions

    1.5 Dimensions Figure 1-2: Dimensions Chapter 1 Introduction...
  • Page 14 FPM-40T/S User's Manual...

  • Page 15: Chapter 2 System Setup

    System Setup • Wall Mounting • Panel Mounting • Exploded Diagram...

  • Page 16: Wall Mounting

    The screw holes are used to secure the large mounting bracket to the wall. Connect the FPM-40T/S to the bracket using the three screws included. After attaching the FPM-40T/S to the bracket, use the fix bracket to stabilize the unit. Figure 2-1: Wall mounting FPM-40T/S User's Manual...

  • Page 17: Panel Mounting

    2.2 Panel Mounting A cutout can be made to accommodate panel mounting. Four panel-mount brackets are included with the FPM-40T/S. Slide the unit backwards into the panel opening. Attach the four mounting brackets by inserting the screws into the keyhole slots on the flat panel monitor cover.

  • Page 18: Exploded Diagram

    2.3 Exploded Diagram Remove the six screws as shown, then lift the rear panel from the unit. The internal components are as shown below: Figure 2-3: Exploded diagram FPM-40T/S User's Manual...

  • Page 19: Touchscreen Driver Installation

    Touchscreen Driver Installation • Introduction • Windows 95 • Windows 3.1 and DOS • Windows NT • OS/2 (MonitorMouse)

  • Page 20: Introduction

    COM2. Both of these configurations are factory pre-settings. Note 3: The following illustrations of windows are examples only. You must follow this manual's flowchart instructions, and pay attention to the instructions which then appear on your screen. FPM-40T/S User's Manual...

  • Page 21: Windows 95

    A.2 Windows 95 a. Insert the ELO driver CD disc. b. Select "Start", "Run". c. Type the path eg. "d:\monmouse\ win95\setup.exe". a. Press the "Next" button. a. Set the path of the directory. a. Choose "Typical". Appendix A Touchscreen Driver Installation...
  • Page 22 Click "OK" to upgrade the driver. a. Click "OK" to make a backup copy. a. Click "OK" to start the wizard. a. Click "OK" to accept the default. FPM-40T/S User's Manual...
  • Page 23 a. Click "OK" but do not reboot. a. Exit and reboot. b. Select "Start", "Settings", "Control Panel". c. Double click "Elo touchscreen". a. Click "Calibrate". E N D Appendix A Touchscreen Driver Installation...

  • Page 24: Windows 3.1 And Dos

    DOS environment. b. Press <Enter> to continue. a. Type the installing path of the ELO directory. a. Select "Dos.." or "Windows..". Windows 3.1 a. Follow the on-screen instructions. D O S Windows 3.1 a. Choose the "Serial" item. FPM-40T/S User's Manual...
  • Page 25 COM1 COM2 COM3 a. Select the "COM1" COM4 item. COM2 COM2 COM3 COM3 COM4 COM4 a. Press <Enter> to install. Windows 3.1 a. Type the Windows 3.1 path. D O S Windows 3.1 a. Add "nomouse.com" to "autoexec.bat" if there is no mouse driver installed.
  • Page 26 Choose "Overwrite...". Windows 3.1 a. Press <Enter> to continue. D O S Windows 3.1 a. Choose "Overwrite...". Windows 3.1 a. Type "go" to run calibration. b. Touch fix points to calibrate. E N D FPM-40T/S User's Manual...

  • Page 27: Windows Nt

    A.4 Windows NT a. Insert the ELO driver CD disc. b. Select "Start", "Run". c. Type the path. eg. "d:\monmouse\ winnt\setup.exe". a. Press the "Next" button. a. Set the directory path. a. Choose "Typical". Appendix A Touchscreen Driver Installation...
  • Page 28 Press "OK" to accept the default. a. Click "OK". a. Exit and reboot. b. Select "Start", "Settings", "Control Panel". c. Double click "Elo touchscreen". a. Click "Calibrate". a. Test the calibration. E N D FPM-40T/S User's Manual...

  • Page 29: Os/2 (Monitormouse)

    A.5 OS/2 (MonitorMouse) BEFORE YOU BEGIN First be sure OS/2 is installed and operating properly with your mouse. As you will be modifying the CONFIG.SYS file, it is best to have the OS/2 installation disks or a bootable DOS disk readily available.
  • Page 30 DOS program for testing PC bus touchscreen controllers. SAWDUMP.EXE DOS program for testing IntelliTouch touch- screen controllers. Create a subdirectory on your hard disk and copy the files into it. For example: CD \ MD ELO COPY A:*.* ELO FPM-40T/S User's Manual...
  • Page 31 International versions of the touchscreen control panel software program are included in subdirectories on the MonitorMouse for OS/2 disk. Replace ELOCAL2.DLL and ELOCAL2.HLP on your hard disk with the versions from the appropriate subdirectory. STEP 3 - MODIFY CONFIG.SYS MonitorMouse for OS/2 is installed by commands in CONFIG.SYS. Use your system editor to make these changes.
  • Page 32 If only the touchscreen is using a COM port, move the DEVICE=COM.SYS and DEVICE=VCOM.SYS commands before the DEVICE=MONMOU02.SYS command in CONFIG.SYS. Then add the flag (<COM Port>,0,0) to COM.SYS, where <COM Port> is the same as on the DEVICE=MONMOU01.SYS command. For example: Device=c:\os2\com.sys (1,0,0) FPM-40T/S User's Manual...
  • Page 33 STEP 4 - INSTALL THE TOUCHSCREEN CONTROL PANEL The touchscreen control panel software program, ELOCAL2.EXE, is a presentation manager application for calibrating the touchscreen and setting various options. Add the \ELO\ELOCAL2.EXE program to the System Setup folder and label the icon “Touchscreen”. This is accomplished as follows: 1.
  • Page 34 FPM-40T/S User's Manual...
