Summary of Contents for Advantech FPM-5191G Series

  • Page 1: User Manual

    FPM-5191G Series 19" SXGA Industrial Monitor with Resistive Touchscreen, Direct-VGA, DVI Ports and 10-30V Inputs User Manual...
  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time. Specifications are thus subject to change without notice.
  • Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or...
  • Page 4 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a residential environment.
  • Page 5 Additional Information and Assistance Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: •...
  • Page 6 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. FPM-5191G User Manual...
  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction ............. 2 Introduction ............... 2 Specifications ..............2 LCD Specifications ............3 Power Consumption ............3 Connectors................. 4 Dimensions................ 5 Figure 1.1:FPM-5191G Dimensions ......5 Chapter 2 Mounting............8 Mounting the Monitor ............8 2.1.1 Wallmounting ..............8 Figure 2.1:Wallmounting ..........
  • Page 8 C.2.10 Mode Information Menu ..........31 C.2.11 Memory Recall Menu ..........32 C.2.12 Exit Menu ..............33 C.2.13 Hot Keys ..............34 FPM-5191G User Manual viii...
  • Page 9 Introduction This chapter includes: • Introduction • Specifications • LCD Specification • Power Consumption • Connectors • Dimensions...
  • Page 10: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Introduction Advantech's FPM-5191G is a 19" color TFT LCD flat panel monitor built specifically for industrial applications. With the optional touchscreen, FPM-5191G is an excellent and user-friendly system control interface. In addition to its usual application as an LCD panel monitor, FPM-5191G comes standard with direct VGA and DVI control signal inputs, making it compatible with Industrial PCs and Workstations.
  • Page 11: Lcd Specifications

    Touchscreen (Optional) • Type: 5 wire, analog resistive • Resolution: 1280 x 1024 • Light Transmission: >80% (Gouge Hardness is greater tahn 4H per ASTM D3363-92 for HCC01, HCG10 and HCG12 • Operating Pressure: 30 ~ 45 gram for stylus pen contact bounce <...
  • Page 12: Connectors

    1.5 Connectors The following connectors are situated on the left hand side of the FPM-5191G Series: VGA Port (DB-15) This DB-15 connector can be connected to the system via the external 15-pin DB-15 connector locatd on the left side of the system unit.
  • Page 13: Dimensions

    1.6 Dimensions Figure 1.1: FPM-5191G Dimensions Chapter 1...
  • Page 14 FPM-5191G User Manual...
  • Page 15 Mounting • Wallmounting • Panel Mounting • Rack Mounting • Desktop Mounting • Swing Arm Mounting...
  • Page 16: Chapter 2 Mounting

    Chapter 2 Mounting 2.1 Mounting the Monitor The FPM-5191G Series can be mounted in many different ways. The versatility of the FPM-5191G mounts enable it to be mounted on your desk or anywhere else. 2.1.1 Wallmounting FPM-5191G can be mounted directly on a wall with panel mounting brackets.
  • Page 17: Panel Mounting

    2.1.2 Panel Mounting FPM-5191G can be mounted directly on a panel with additional mount- ing brackets. Please refer to figure 2-2 and follow the following steps: Fix 10pcs panel bracket around the industrial monitor Fix into the panel by screw the bracket Figure 2.2: Panel Mounting Chapter 2...
  • Page 18: Rack Mounting (Optional)

    2.1.3 Rack Mounting (Optional) If you need to install the FPM-5191G on a rack, you must order the rack mount kit for FPM-5191G (Part Number is FPM-5191G-RMKE). Attach the rack mounting brackets on FPM-5191G with the screws, then affix the monitor in the rack. Figure 2.3: Rack Mounting Brackets FPM-5191G User Manual...
  • Page 19: Desktop, Swing-Arm For Fpm-5191G

    2.2 Desktop, Swing-ARM for FPM-5191G The FPM-5191G Series can be mounted in other ways, such as desktop and swing-arm. 2.2.1 Desktop Stand FPM-5191G can be mounted as stand in the desk directly by a additional mounting brackets. Please refer to figure 2-4 and follow these steps: Figure 2.4: Desktop Stand...
  • Page 20: Swing-Arm (Vesa Compliant)

    2.2.2 Swing-ARM (VESA Compliant) FPM-5191G has been designed with support for the VESA Arm standard. Refer to figure 2.5. Supports both 75mm and 100mm VESA dimension. Figure 2.5: Swing-ARM FPM-5191G User Manual...
  • Page 21 SXGA2 Touchscreen...
  • Page 22: Appendix A Touchscreen

    Appendix A Touchscreen A.1 Introduction The FPM-5191G Series optional touchscreen uses advanced 8-wire resis- tive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards.
  • Page 23: Installing Driver For Windows Os

    4. Linearity 4.1 Linear Test Specifications Direction X: <1.5 % Direction Y: <1.5 % 4.2 Linearity Test Apply voltage (DC5V) to upper (or lower ) electrodes, output voltage Vx or Vy on the other electrodes is measured at every regular intervals. Linearity is the value of max.
  • Page 24 FPM-5191G User Manual...
  • Page 25 Setting Serial Data for Expansion...
  • Page 26: Appendix B Setting Serial Data For Expansion

    Appendix B Setting Serial Data for Expansion B.1 Setting Serial Data for Expansion The twelve kinds of timings below are already programmed in this mod- ule. The input synchronous signals are automatically recognized. VGA Port Resolution Support Resolution Vertical Frequencies 60Hz 70Hz 72Hz...
  • Page 27 OSD Operation Keypad...
  • Page 28: Appendix Cosd Operation Keypad

    Appendix C OSD Operation Keypad C.1 OSD Board Overview The OSD keypad, including six keys and a two color indicator, is designed as the OSD operation interface. Note: This sheet is only for reference, different models will has different styles, but the functionality is the same. C.1.1 OSD Button Description Buttons Descriptions...
  • Page 29: Osd Key Functions

    C.2 OSD Key Functions Each selected value is stored into LCD memory after SEL signal input or time out. The stored values are not affected if the power is turned off. But the selected value is not available in case a selected mode is changed before time out or power is turned off before time out.
  • Page 30: Input Source Select

    C.2.2 Input Source Select • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected...
  • Page 31: Contrast/ Brightness Setting

    Auto Select Input • ON start from default setting and scan the inputs by following sequence from ANALOG INPUT, DIGITAL INPUT, S-VIDEO INPUT, and CVBS INPUT. • OFF start from default setting C.2.3 Contrast/ Brightness Setting • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation...
  • Page 32: Geometry Menu - For Dvi Input

    • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. RECALL VALUE – User Define • Rec1 Pressed to record 1 setting as recall value followed by current screen setting •...
  • Page 33 • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Appendix C...
  • Page 34: Color Temperature Menu

    C.2.5 Color Temperature Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected...
  • Page 35: Rgb Color Menu

    C.2.6 RGB Color Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation Select by Left and Right Button, Press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN •...
  • Page 36: Language Menu

    • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Customization setting for RGB colors C.2.7 Language Menu •...
  • Page 37: Osd Manager

    • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.8 OSD Manager • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation •...
  • Page 38: Auto Configuration Menu

    • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last Selected to confirm menu Decrease the gauge value of the selected option. C.2.9 Auto Configuration Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation...
  • Page 39: Mode Information Menu

    • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Auto configuration can be set in menu and also can press the without any menu indication.
  • Page 40: Memory Recall Menu

    • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last Selected to confirm menu Decrease the gauge value of the selected option. C.2.11 Memory Recall Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation...
  • Page 41: Exit Menu

    • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.12 Exit Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation •...
  • Page 42: Hot Keys

    • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.13 Hot Keys OSD LOCK/UNLOCK HOT KEYS Press first then press for change this setting, Followed this sequence for the button press so that you can have OSD LOCK and...
  • Page 43 • Entry OSD UNLOCK MODE • Press HOT KEY, the screen will show this action first • Don’t remove the HOT KEY until the screen indicated this task is fin- ished. Appendix C...
  • Page 44 FPM-5191G User Manual...
