E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e

PrEsEts

The PRESET knob is a rotary push button encoder that facilitates saving and loading
of presets. A complete list of all 60 default presets can be found at the end of this
manual.
On power up, the unit will load preset 0 in Bank 0. Turning the preset encoder
clockwise scrolls through preset numbers 1-9 in Bank 0. Going beyond preset 9
in Bank 0 takes you into preset 0-9 of Bank 1 and so forth. The current Bank is
indicated by the upper right light bar, where no lights indicates Bank 0, one light
indicates Bank 1, two lights indicates Bank 2 etc...
pRESET LOaDING
To Load a preset, turn the preset knob to select the desired number, the digit will
flash. When you have arrived at the desired destination, push down the preset
knob to load that preset.
Note: Upon switching presets, a new Tap Tempo will be loaded, associated with that
preset. In order to bypass this to keep a constant Global Tap, engage Global Tap. See
'Footswitches' for more information
pRESET SavING
To Save a preset you have created, push and HOLD the preset knob for 1 second,
until the digit begins flashing. Turn the preset knob to select the preset number where
you want to save the sound and then push down and HOLD the preset knob for 1
second to finalize the save.
The decimal point will illuminate to indicate that preset is present in any given
number/bank. When changes have been made but not saved, the decimal point will
flash. If you want to keep your changes, simply follow the save process explained
above without changing the selected bank.
pRESET COpY
To Copy a preset from one bank to another simply initiate the save process as
explained above and save to any slot you wish.
pRESET SELECT USING THE ON-BOaRD FOOTSWITCHES
Hold TAP TEMPO to enter PRESET SELECT mode. The preset digit will begin blinking. A
SHORT PRESS on the Tap Tempo switch moves up one preset. A LONG PRESS moves
down one preset. Pressing ENGAGE activates the chosen preset. When pressing
the ENGAGE switch to activate a new preset, the BYPASS status will not change.
Note: When switching between vastly different sounds, the Echolution 2 will automatically
"teleport" taps, making a seamless transition, instantly changing the Tap Tempo without
pitch changes.
FaCTORY RESET
Holding down both footswitches during power up will result in a factory reset,
restoring all 60 original Echolution 2 presets.
WARNING: Performing a factory reset will erase all custom preset data stored to the
Echolution 2.
20 |
p i g t r o n i x . c o m
.
The Echolution 2 remote switch port can be set up to work in two
different ways. When it is shipped from the factory, the Echolution
2 is programmed so that the Remote instantly switches between the
top four presets in each bank as detailed above, regardless of the
ENGAGE status.
Preset Load using the optional E2R Remote Switch
SHORT pRESS
on the left footswitch of the E2R will instantly load
preset 1 in the current bank.
SHORT pRESS
on the left footswitch again will instantly load preset
2 in the current bank.
LONG pRESS
on the left footswitch moves up one bank (indicated
by upper right light bar).
SHORT pRESS on the right footswitch of the E2R will instantly load
preset 3 in the current bank.
SHORT pRESS on the right footswitch again will instantly load preset
4 in the current bank.
LONG pRESS on the right footswitch moves down bank (indicated
by upper right light bar).
E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e

E2r rEMotE switch

| 21
