E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
aPPlication
A PC/MAC application has been developed to enable users to control every
function of the Echolution 2 via USB.
The application also enables firmware updates and extensive preset management
including the ability to import, export and audition presets.
PLEASE take a moment to download the E2 Application from our website at:
www.pigtronix.com/E2application
Starting the Application: To load and change presets on the E2, connect the via
USB. To change preset parameters without connecting the E2, Create a Virtual E2.
If you would like, you can change the view of the application to either the Filter
Pro or the Ultra Pro by the Display Type drop menu.
Note: The functionality does not differ with each view, and both are compatible
with any Echolution pedal.
Presets List: On the left of the screen, there is a list of all of the current presets
stored in the E2. This list is ordered in the same way of that at the end of this
manual. By DOUBLE-CLICkING, the selected preset loads on the E2. Once
a preset is selected, it will be displayed in bold in the Presets List.
30 |
p i g t r o n i x . c o m
Buttons for several options are displayed
allows the user to save to currently displayed settings to any preset. When Save
To is clicked, a window will pop up, addressing the user to highlight the preset
from the Preset List which he would like to overwrite these settings to. When the
desired preset is highlighted, click save. Save Preset/Bank to File: This saves
an individual preset or bank to a file Load Preset/Bank to File: This loads an
individual preset or bank to a file
aDvaNCED OpTIONS
To access this feature, click the 'Show Advanced Options' button, located under
the Echolution 2 logo on the application.
Each row represents a knob on the E2, named accordingly. The first and second
columns control parameters for the expression pedal, and the last four columns
control parameters for the envelope.
ENaBLE
By clicking a box in an
the envelope to control the designated knob.
When a parameter is assigned expression pedal control, pointers for the heel
and toe become visible around that parameters associated control knob, moving
these pointers set the range of control.
Note: When a parameter has any of these advanced mapping features enabled
EXpRESSION
for the pedal, the LED for that parameter dimly illuminates to
indicate the expression or envelope control; dimly lit LED's indicate Secondary
Controls. The brightly lit LED indicates the Primary Control. The Primary Control
E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
aPPlication
UNDER
the Presets List: Save To: This
column allow either the expression pedal or
p i g t r o n i x . c o m
| 31
