E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
advancEd boot oPtions
INpUT MIDI CLOCk
Enables MIDI Clock in
6DB BOOST
Increases the MAX value of the MIX
knob to +6dB above the input signal.
NON-pITCHED MIDI
TRaCkING
Allows the MIDI
beat clock to change without
pitch shifting
COpY MIDI CLOCk
Copies
MIDI Clock In to MIDI Clock Out
FIRMWaRE vERSION
After the E2 initializes, it will
display a sequence of three
digits; this is its firmware
version. For example, after the
"-" you will see a sequence '1',
'0', '0'. This denotes firmware
version 100.
10 |
p i g t r o n i x . c o m
aDvaNCED BOOT OpTIONS
Specialty global settings that
can be toggled during power
up These settings are "sticky"
and will remain set even after
removing power from the E2.
GLOBaL Tap
Allows the user to change
presets while maintaining
FaCTORY RESET
the same Tap Tempo
Restores all 60 original Echolution 2 presets.
WARNING: Performing a factory reset will erase
all custom preset data stored to the Echolution 2.
E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
advancEd boot oPtions
MIDI THRU
Enable MIDI Thru signals
pHaSE INvERSION
Controls stereo output phase inversion
DRY kILL DURING BYpaSS
Enables Dry Kill when Engage is off
GENERaTE MIDI CLOCk
Allows the E2 to generate its own
MIDI Clock
TOGGLING
must be held during power
up to toggle the given sticky
flag.
REMOTE
SWITCH
SETTING
CURRENT STaTUS
Switches between
the sticky flag is displayed
Jump/Freeze and
during power up by the
Preset Select Mode
LEDs that the buttons used
to toggle them controls.
these buttons
of
| 11
