touch switchEs — lfo wavEforMs
SHORT pRESS
cycles between:
Triangle
Square
Ramp
Random (Sample & Hold)
Super Triangle
Super Square
Super Ramp
Super Random
The "Super" version of each waveform has 4 additional LFOs
superimposed onto the original LFO waveform.
LONG pRESS turns on LFO SYNC
the Delay Time as set by the delay time knob, tap tempo or MIDI
beat clock. When LFO Sync is turned on, the LFO SPEED knob
determines the LFO Speed to Delay Time ratio with minimum being
1 LFO Oscillation:8 Delay Cycles and maximum being 8 LFO
Oscillations:1 Delay Cycle for fifteen possible values (1:8, 1:7,
1:6, 1:5, 1:4, 1;3, 1:2, 1:1, 2:1, 3:1, 4:1, 5:1, 6:1, 7:1, 8:1)
MIDI THRU -
Enable MIDI Thru signals.
HOLDING the LFO WAVEFORMS switch during the power-up
procedure of the E2.
16 |
p i g t r o n i x . c o m
- this synchronizes the LFO to
This can be toggled by
touch switchEs — ExPrEssion control
SHORT pRESS cycles between EXP control of:
R - Delay Repeats
T - Delay Time
M - Delay Mix
S - LFO speed
D - LFO depth
Note: The Heel setting is fully counterclockwise by default, and
the knob position determines the toe setting.
LONG pRESS turns on ENV MAP to EXP - this sums the internal
envelope follower with the current expression pedal or on-board
knob value for the chosen parameter, allowing touch sensitive
control over every knob.
When using the ENv Map to EXP function, the position of the
expression pedal or onboard knob will be summed with the
envelope voltage.
aDvaNCED MappING
: The expression pedal and/or envelope
can be used to control any combination of the knobs on the E2.
See 'Echolution 2 Application' Section for more details on how
to implement this setting.
INpUT MIDI CLOCk -
Enables MIDI Clock in.
by HOLDING the EXPRESSION CONTROL switch during the
power-up procedure of the E2.
