CDM-600 Satellite Modem
Front Panel Operation
INFO: CLOCKS
CLOCKS:TX=INT(SCT)RX=EXT-CLK REF=INT10
The TX Clock, RX Clock and Buffer information is displayed.
Note: The Clock (CLK) information is shown only if Rx Clock is set to EXT-CLK.
INFO: EDMAC
EDMAC FUNCTION= ON
EDMAC MODE= MASTER
This screen shows if EDMAC is enabled or not. If it is enabled, the EDMAC Mode and
Address are shown.
INFO: DROP TYPE
DROP TYPE=
E1-CCS
This screen shows the Drop Type. Pressing ENTER takes the user back to the previous
menu.
INFO: INSERT TYPE
INSERT TYPE=
E1-CCS
This screen shows the Insert Type. Pressing ENTER takes the user back to the previous
menu.
BUFFER-SIZE=00016 CLK=02048U
CH:1
TS:01
CH:1
TS:01
6–34
EDMAC ADDR= 0020
Revision 7
MN/CDM600.IOM
