2
Description of the machine
2.1.2
Rear view
A2
B2
C2
Item
Symbol Description
A2
B2
0
C2
D2
E2
F2
G2
H2
I2
Fig. 2/2, Rear view
8-pole connection socket cooling unit control lead
Main switch
1
Welding machine and where appropriate cooling module "On/Off"
Mains connection cable
7-pole connection socket wire feed unit control lead
Connecting nipple G¼ shielding gas connection to the pressure reducer
Types of ignition changeover switch
HF
: Welding with HF ignition.
HF
: Welding with Liftarc.
Changeover switch characteristics
Changing between each of two characteristics in the welding processes
MMA:
rutile / basic
MIG/MAG: solid / cored wire
4-pole connection socket cooling unit voltage supply
Air outlet
2/2
D2
E2
F2
G2
H2
I2
