Audionet MAP v2.0 User Manual page 34

Connection diagram RGB video output with C-Sync:
If your video display has a video input for progressive RGB video signals with C-Sync
(= Composite Sync), connect the MAP according to the following diagram:
VGA
OUT OUT
Y/R C
OUT IN
R
Note: Please make sure, that for this video output mode the function 'Set Video
Out' is set to 'C-Sync' to provide the correct Sync signals at video output OUT2 7 (see
above 'Video outputs Progressive Scan Card').
OUT
IN 1
/G C /B
R B
IN IN
S-VIDEO 1
G B
to video input of video display (4x Cinch)
alternative connection to video input of video display
VGA
video display (VGA)
Pinning: Pin #1 = R
IN 2 IN 3 IN 4
VIDEO IN
S-VIDEO 2 S-VIDEO 3 S-VIDEO 4
ANALOG OUTPUTS
Pin #2 = G
Pin #3 = B
Pin #13 = C-Sync
34
OPTICAL
OUT 1 OUT 2
VIDEO OUT
DIGITAL
OUT
(OSD)
S-VIDEO 1 S-VIDEO 2
C-Sync
