Audionet MAP v2.0 User Manual page 31

Note: The Progressive Scan Card will process only interlaced video signals!
Connection diagram 'YUV Video In':
If your video source has a Component or YUV video output, connect the three lines Y,
U and V to the MAP according to the diagram:
VGA
OUT OUT
Y/R C
R
OUT IN IN
Y
Connection diagram 'RGB Video In':
If your video source has a RGB video output, connect the four lines R, G, B and C-Sync
to the MAP according to the diagram:
VGA
OUT OUT
Y/R C
R
IN IN
OUT
R
Note: Many units use a SCART connector to provide the RGB video format. In this
case, please use a suitable adaptor from SCART to "RGB with Sync". The Sync signal
is at pin #19 of the SCART connector, the colour signals are at pin #15 = R, Pin #11 =
G and Pin #7 = B.
OUT IN 1
/G C /B
B
IN
S-VIDEO 1
U V
from video output of video source
OUT IN 1
/G C /B
B
IN
S-VIDEO 1
G B C-Sync
IN 2 IN 3 IN 4
VIDEO IN
S-VIDEO 2 S-VIDEO 3 S-VIDEO 4
ANALOG OUTPUTS
IN 2 IN 3 IN 4
VIDEO IN
S-VIDEO 4
S-VIDEO 2 S-VIDEO 3
ANALOG OUTPUTS
from video output of
video source (Cinch)
from video output of
video source (SCART)
