Audionet MAP v2.0 User Manual page 14

Screen page 5:
Channel Setup
Global Setup
Video Setup
Bass Manager
Delay Manager
Please refer to chapter 'Preferences / Setup' for further details.
Screen 6:
All 8 keys are used to configure the digital equalizer. If the MAP is in any other mode
than the setup mode for the equalizer, pressing one of the 8 keys invokes the setup mode
for the equalizer. Then the keys have the following function:
MPE-
selects the previous MPE
MPE+
selects next MPE filter of current channel.
Freq-
decreases frequency of current selected MPE filter.
Freq+
increases frequency of current selected MPE filter.
Q-
decreases Q-factor of current selected MPE filter.
Q+
increases Q-factor of current selected MPE filter.
Gain-
decreases gain of current selected MPE filter.
Gain+
increases gain of current selected MPE filter.
*)
MPE = Minimum Phase Equalizer
Key selects the next, key
to control the master volume.
enters the menu "Channel Setup".
enters the menu "Options Setup".
enters the menu "Video Setup".
enters the menu "Bass Manager".
enters the menu "Delay Manager".
*)
filter of current channel.
selects the previous channel. Use the keys
14
and
