Audionet MAP v2.0 User Manual page 11

Note: Navigate through the menu using keys
and .
Press key Listening Mode to select desired Listening Mode. See chapter 'Preferences /
Setup', section 'Listening Mode' for further details.
Screen page 3:
Keys for level adjustment:
Press key Front to enter the level adjustment menu 'Level Setup'. The level of channel
Front Left is the point of reference for the level of all other channels. Use keys 'VOL+/-'
to adjust the master volume of the system (not just the level for Front Left alone) while
channel 'Front Left' is selected. In order to adjust all levels correctly you should
therefore always start with channel Front Left to set the reference level for the whole
system, especially if you are using an SPL meter to adjust volume levels. If this
reference level is set correctly, you are able to adjust the level of all other channels
easily. Use key
the previous channel. To change the volume use keys
You can also use the following keys to adjust the volume level of selected channels. These
keys access the setup of the corresponding channel directly.
Note: By selecting keys Surround or Back the level is adjusted for both channels of the
corresponding channel group. So these keys are mainly used for changing levels during
listening. You can increase or decrease the volume of the surround and back channel groups
without changing stereo balance of these channels. In any case you can always get to the
next/previous channel by using keys
Press key Center to adjust Center channel trim level using keys
Press key Surround to adjust Surround channel trim levels using keys
(+12...-18dB).
Press key Back to adjust Back channel trim levels using keys
(+12...-18dB).
Press key Subwoofer to adjust subwoofer channel trim level using keys
(+12...-24dB).
Press key LFE to adjust level of LFE channel using keys
function affects only the LFE channel before it is processed by the Bass Manager.
Press key TestTone to start internal test tone generator. The generator delivers a noise
signal to the Front Left channel. You can adjust the reference volume of the system now
to skip to the level setting of the next channel. Or use
/
and . Change option with keys
and
.
and
11
to select
.
and (+12...-18dB).
and
and
and
(+0...-10dB). This
