Display

While in RUN mode the first line of the display provides the number of the input
channel ('1' to '6' for Analog In 1 to 6, '1' to '5' for Digital In 1 to 5, 'E' for 8ch External
Input) followed by the (user definable) channel name (14 characters long). If the
monitor/effects loop is active, its name is only 12 characters long. To inform the user of
the activated monitor/effects loop an 'M' is printed in the upper right corner of the
display.
If the internal decoder is inactive ('Internal Decoder = disabled'), the
volume is displayed in the second line as 'LEVEL –xx+y dB' with xx = current
volume and y = offset adjust for the current input channel. If the internal decoder is
active, the second line changes to 'MASTER –xx dB' with xx = current master volume
of all channels. So the user can easily see, if the internal decoder is active or disabled.
If using a digital input, the second line of the display will show 'Out of lock' while
there is no valid digital signal at the current input. If a valid signal is detected by the
digital receiver, the second line changes to 'Receiver locked' for a moment. Is the
internal jitterkiller active, the display shows 'Jitterkiller engaged'. After that
information about program format, output and speaker configuration follows. Press
Show key at any time to force the display to show this information. After some seconds,
the display returns to showing volume information.
Every program format, the current decoding and output format is displayed as the
following:
Example:
Current decoder mode
Program format of
input signal
Current decoder mode
Dolby D+PLIIx Mov
2/0.0 48k
Sample
input signal
Dolby D+PLIIx Mov
LCR LSLBRBRS
26
448kb
Bitrate of input
rate of
signal
SUB
Speaker configuration
output format
and
