Audionet MAP v2.0 User Manual page 13

Press key Digital Filter to select the digital filter. Use keys
between 4 different digital oversampling filters for Front channels L/R:
Audionet:
Lagrange:
Blackman:
Kaiser:
Note: This option is only available for sample rates up to 48kHz and not for DVD-
Audio.
Press key Load Setting to re-load previously saved user settings. Select the user setting
you want to load by using keys
current settings are overwritten during load.
You can choose a name up to 14 characters in length for each of the 30 user settings. To
change a name press key
or (see also 'Edit Channel Name'). Move cursor one position to the right
by pressing key. While cursor is active, you get to the names of the other user setting
with keys and
To save the current setting as user setting press key Save Setting, and choose one of the
30 memory spaces with
location is overwritten by the current settings after pressing key
You can simply assign the current setting to only one input channel or even to every
input channel at once. Press
press to transfer the current settings to that input channel.
Press again to enter the mode to assign current settings to all input channels. Press
to start the data transfer.
A user setting comprises: Trim and balance levels of all channels, 'PCM direct' mode,
dynamic range, Dolby Pro Logic IIx and DTS Neo:6 Mode, Listening Mode and Digital
Filter. 30 memory locations for storing user settings are available to the user. The user
can assign a name of up to 14 characters in length to each user setting. Additionally,
each of the 16 input channels saves automatically all current settings independently. The
30 memory locations can only be accessed by the user when using the 'Save
Setting' function. So they are independent from the channel settings.
Note: Current master volume, speaker settings, state of internal decoder, video options
etc. are saved automatically and independently changing a setting and/or switching off
the MAP.
Note: After adjusting the volume levels of all speaker channels we recommend to save
these settings to all input channels as a simple start up for further channel or source
dependent level settings. To save the current level settings to all input channel press the
following keys on the remote control: Save Setting à
Now all input channels have the same volume level settings. Of course, you can change
these settings easily for each input channel independently, if necessary.
special digital oversampling filter with short pre-ringing
short Lagrange filter
digital filter by Blackman
digital filter by Kaiser.
and
. A cursor marks the character to be changed by pressing
. To leave edit mode press Load Setting again.
and keys. All data at the corresponding memory
and select the input channel with
13
. Press to load selected user setting. All
à
and to choose
.
or . Then
