UBI EasyCoder 501 – Service Manual
2. FRONT AND KEYBOARD, cont'd.
2.4

Slides

The slide can be removed through a slot at the right side of the
keyboard using a small pair of pliers. The slide can be replaced by
another one, e.g. to adapt the printer for a certain language or
application. Presently, there are three different slides with English
text – one for each main model, as shown below.
Power Ready Error
EasyCoder 501
Keyboard of EasyCoder 501
Power Ready Error
EasyCoder 501 E
F1 F2 F3 F4
Keyboard of EasyCoder 501 E
Power Ready Error
EasyCoder 501 SA
| " # $
Q W E R
§ @ ~ £
A S D F
< > [
Z X C
Shift
Keyboard of EasyCoder 501 SA
7
Pause
4
Setup
1
Feed
.
F5 Enter
Alt Pause Save Feed
Caps Ins Del
% & / ( )
T Y U I O
' _ * ? –
G H J K L
] ^ ; : Ö
V B N M ,
Print
8 9
5 6
2 3
0 C
Print
µ
Ç Ñ
Esc 7 8 9
É È À
4 5 6
= Ü ß Ù
P 1 2 3
Å Æ
+ Clear 0 Enter
Ä Ø
. Print
Space
17
